UEi EM152 Instruction Manual

Dual Differential Digital Manometer
INSTRUCTION MANUAL
ENGLISH
psi
REC/MAX
MIN/AVG
WARRANTY
The EM152 is warranted to be free from defects in materials
and workmanship for a period of one year from the date
of purchase. If within the warranty period your instrument
should become inoperative from such defects, the unit will
be repaired or replaced at UEi's option. This warranty covers
normal use and does not cover damage which occurs in
shipment or failure which results from alteration, tampering,
accident, misuse, abuse, neglect or improper maintenance.
Batteries and consequential damage resulting from failed
batteries are not covered by warranty.
Any implied warranties, including but not limited to implied
warranties of merchantability and fitness for a particular
purpose, are limited to the express warranty. UEi shall not
be liable for loss of use of the instrument or other incidental
or consequential damages, expenses, or economic loss,
or for any claim or claims for such damage, expenses or
economic loss.
A purchase receipt or other proof of original purchase date
will be required before warranty repairs will be rendered.
Instruments out of warranty will be repaired (when
repairable) for a service charge.
1.800.561.8187
Copyright © 2016 UEi. All Rights Reserved.
EM152
• Range of -60 to +60 inH
• Differential Pressure
• Dual input differential measurement to ±80.27 inches of .
water column
• Measures in 11 scales; inH
mmHG, ozin, FtH
• Magnetic Mount
• Auto Ranging
• Backlit Display
• Data Hold
• Max/Mn
EM152
• Zero Button
• Operating Temperature:
• Storage Temperature:
• Backlight:
• Over-range:
P
• Dimensions:
HOLD
• Item Weight:
ZERO
• Calibration:
SCALE
• Battery Type:
WARNING
• Read entire Safety Notes section regarding potential hazards
and proper instructions before using this manometer. In this
manual the word "WARNING" is used to indicate conditions
or actions that may pose physical hazards to the user. The
word "CAUTION" is used to indicate conditions or actions
that may damage this instrument.
• To avoid false readings, replace batteries if a low battery
indicator appears.
WARNING
• WARNING Do not exceed Maximum Over Pressure of 10 psi.
• Do not use the manometer if it operates abnormally.
• Always test the manometer before use to ensure it is
operating properly.
• Always ensure that the connecting hoses you are using are
free from kinks, blockage or splits.
• Always double-check all connections before testing.
• While using the manometer, if you suspect gas is leaking, or
if you can smell gas, close off gas supply and ventilate the
occupied space. Identify and repair the source of the leak
before continuing with the test.
• Never connect the manometer to an unknown pressure
source if the source is twice the working pressure of the
instrument; the sensor may be damaged and it may
cause injury to the user.
• Never open the manometer or attempt to modify it in any
way. Otherwise, accident and injury may occur. And the
warranty is voided.
• These manometers do not measure water pressures; under
these conditions they will fail.
WARNING
• This manometer is designed for trained trade professionals
who are familiar with the hazards of their trade. Observe all
recommended safety procedures and use of personal
protective equipment.
www.
FEATURES
O
2
O, PSI, Bar, mBar, kPa, inHG, .
2
O, cmH O and kgcm.
2 2
GENERAL SPECIFICATIONS
32˚ to 104˚F (0˚ to 40˚C)
14˚ to 140˚F (-1˚ to 60˚C)
Display Backlight
ERR1 or ERR2 is displayed
5.27" X 3" X 1.5"
6.2 oz.
Calibration
9V X 1
IMPORTANT SAFETY WARNINGS
SYMBOLS
Hold/Capture Value
Maximum measured value displayed
Minimum measured value displayed
Warning or Caution
Negative Pressure
.com
OVERVIEW
A
EM152
I
B
psi
C
D
P
E
REC/MAX F
HOLD
MIN/AVG ZERO
G
H
SCALE
J
A. Pressure Sensor Inputs:
• Left Connection: Negative pressure port.
• Right Connection: Positive pressure port.
B. Display: with Backlight.
1. Hold: Values are captured/held.
2. Dif: Pressure Differential.
3. Record: The manometer will record the Maximum
Pressure, Minimum Pressure and Average Pressure.
4. MAX/MIN/AVG:
- MAX: Maximum value captured is displayed.
- MIN: Minimum value captured is displayed.
- AVG: Timed mean value calculation displayed.
NOTE: REC/MAX/MIN/AVG function does not work
when in ∆P/Pressure Differential test mode.
5. Battery: When battery is too low for safe operation,
the Low Battery indicator will display (BAT). See
Battery Replacement section of this manual.
6. Time (H/M/S): Hours/Minutes/Seconds.
C. Power Button (Green): Press to turn on manometer.
Press to turn off manometer.
D. ∆P/Pressure Differential Button: Used to start and stop
pressure differential test.
E. REC/MAX/MIN/AVG Button: Press to record Max/Min/
Avg values.
F. HOLD/ZERO Button: Press to capture displayed value or
zero meter.
• Auto power off after 25 minutes of inactivity.
• To disable Auto power off: with the meter off, press the
POWER button, then press and hold the HOLD/ZERO
button until a 'n' displays.
G. Backlight Button: Press to turn on Backlight. Press again
to turn off.
• Provides easy reading of Display in dark work environments.
• Backlight duration is 50 seconds.
H. Scale Button: 11 Selectable Units of measurement.
I. Magnetic Mount: For hands-free work.
J. Battery Cover: Easy access for replacing batteries.
SPECIFICATIONS
Function Ranges Resolution
Bar ± 0.200 0.001
Ounces/
± 46.60 0.01
Sq. Inch
PSI ± 2.900 0.001
inHg ± 5.904 0.001
mBar ± 200.0 0.1
mmHg ± 150.0 0.1
kPa ± 20.00 0.01
Kg/Sq. cm ± 0.204 0.001
In H2O ± 80.27 0.01
Ft H2O ± 6.689 0.001
cm H2O ± 203.9 0.1
information@itm.com
Accuracy (77˚F)
± 0.3% Full
Scale Ouput
17240 • 1015
