Front Panel - RoyalTek RN2 User Manual

2.1.2

Front Panel

Figure 1: Top and Left/Rights side views
Table 2-1: Top and Left/Right side controls
NO Function
1 Power button
2 Power status LED
3
Micro SD
4 Earphone
USB port/Docking
5
connector
RN2 Users Manual
Standby mode by pressing the button for sleep/wake.
Indicated the battery charging status.
Green—fully charged or high battery.
Orange—charging Battery
Red—low Battery
Accepts Micro SD storage cards, allows you use audio, image files stored
in it for use with internal applications.
Standard stereo headphone jack.
For USB port: connects the device to computer running on the Microsoft
Windows platform. Also serves as the power connector for charging the
11
