27
SS,<text>
Example : "SS,SerialPort"
ST,<num>
Example : "ST,0"
Example : "ST,255"
SU,<rate>
Example : "SU,96"
SW,<hex word>
Example: "SW,0050"
SX,<1,0>
SZ,<num>
S$,<char>
S~,<0,1>
See Section 4.2 for more details on Profiles.
S~,<6>
Cedar Park, TX, USA
BlueSnap Commands Version 4.81SIO,
NOTE: 2 special characters can be used here:
"SR,Z" will erase any stored address.
"SR,I" will write the last address seen by using the Inquiry command.
This can be helpful when you just have 1 other device in range and want to
quickly store and connect to it.
Service Name (1 to 16 characters ).
Config Timer, # of seconds ( range= 0 to 255 decimal,, default = 60 decimal) to allow
remote configuration over Bluetooth after power up in Slave Mode. In all Master modes,
the remote config timer is set to 0 (no remote configuration). In Trigger Master Mode,
this Timer is used as an Idle timer to Break the connection after the timer expires with no
characters being received.
disables remote configuration
enables remote configuration forever
Baudrate, {1200, 2400, 4800, 9600, 19.2, 38.4, 57.6, 115K, 230K, 460K, 921K }, only
the first 2 characters are needed.
sets the baudrate to 9600 buad.
Enable low power SNIFF mode. Default is 0000=disabled. SNIFF mode allows extreme
low power operation. Device goes into a deep sleep, and wakes up every
every 625us * <hex word> to send/receive chars.
enables Sniff mode and sets the interval time to 50 hex * .625 = 50
milliseconds. This will cause the module to enter low power sleep, and
wake once every 50 milliseconds to check for RF activity. See Section
4.1 for more details on Sniff.
Bonding enabled, which creates a single stored connection pair with a remote device.
Raw Baudrate (decimal) allows entering of non-standard baudrates. Based on the
formula num = Baudrate * 0.004096.
Configuration detect character. This allows a change from the default $$$ to some other
character. Factory defaults returns the device to $$$.
Profile to use. 0=SPP (default), 1 = DUN DCE, 2 = DUN DTE, 3 = MDM.
Profile to use. 6=HID (Bluetooth keyboard), sets to HID mode when it has HID/SPP
firmware (version 6.10). Must reboot (r,1) after.
(512) 994-3630
sales@serialio.com
1/20/2016
Page 9 of
www.serialio.com
