27
S?,<0,1>
S+,<num>
Example : "S+,3600"
S|,<hex>
Example: S|,2001 // cycle ON for one second and OFF for 32 seconds (HEX
GET COMMANDS
D
Display basic settings. Address, Name, Uart Settings, Security, Pin code, Bonding,
Remote Address. This command is an easy way to check the configuration.
E
Display extended settings. Service Name, Service Class, Device Class, Config Timer.
M
Display remote side modem signal status.
O
Display other settings. Config character, IOport values, debug mode.
G<X>
Display stored settings . These commands correspond to the SET commands above.
Cedar Park, TX, USA
BlueSnap Commands Version 4.81SIO,
Role Switch. Enables and disables Role Switch. If set, when an incoming connection is
occurs to a slave mode device, an attempt will be made to force a role switch, allowing
the slave to become the master. This is useful in situations where high speed data is being
sent from the local device up to the remote host, and can result in better performance.
However this may create a situation whereby the connecting host will not be able to make
additional outbound connections (multipoint) while connected to this device. Disabled by
default.
Sleep timer settings. The default sleep time setting is set to 180, which is 3 minutes. In
Order to
Low power connect mode. Disables the Bluetooth radio and LED timers while not
connected. When set, the module will cycle between active (discoverable and
connectable) and low power deep sleep. This can save considerable power when the
module is waiting for long periods of time without a connection. The trade off is
additional latency when connecting or pairing. The value is a four digit number made up
of two one byte intervals. The first interval is the OFF period and the
second the ON period. Both are in Hex seconds (not decimal). The maximum value
is 20 seconds for either of the periods. Default is 0000 always actively waiting for a
connection.
20=Decimal 32).
•
•
(512) 994-3630
To set the sleep time to one hour
sales@serialio.com
1/20/2016
Page 10 of
www.serialio.com
