F,1 - Enter Fast data mode, end configuration immediate.
I,<time>,<cod> - Device Scan Inquiry, time in seconds, optional cod = class of device filter, 0=all
IN<time>,<cod>- Device Scan Inquiry, returns NAMEs.
IR<time> - Device Scan Inquiry, fixed cod=0x001F00 to find SerialIO.com devices.
IS<time> - Device Scan Inquiry, fixed cod =0x0055AA to find instant cable pairs.
K, - Kill (disconnect) from current connection
Q - Turn off Discovery and Connectability
R,1 - Reboot
T,<0,1> - Pass receive data (from uart or BT) while in command mode.
U,<rate>,<E,O,N> - Temporary UART change of baud rate and parity (Even, Odd, None)
& - return the value of the DIP Switches
Z - Enter low power Sleep mode
6. Factory Default Power up Settings
Bluetooth Service Profile = Serial Port Profile (SPP)
Device Mode = 0 (Slave)
Baud Rate = 115200bps,Parity=None, Data bits = 8 bits(fixed), Stop bits 1 (fixed).
Power Mode = Auto low power discoverable mode
Name of Device (local name) = BlueSnap-XXXX last 2 bytes of BT address
Service Name = SPP
Service Class=0000 (undefined service type)
Major & Minor Class Of Device (COD) = 0x1F00 (unknown device type)
Authentication Disabled
Encryption Disabled
Discovery Enabled (0x0200 = windowl, fixed interval of 0x800= 1.28 Seconds )
Connection Enabled (0x0200=window, fixed interval of 0x800 = 1.28Seconds)
Bonding Disabled
Config Timer=60 seconds
SNIFF mode disabled
Default PIN = "1234"
Note: PIO(4) Switch 1, Set ON at power up time, and then toggled 3 times will change all
settings above back to their factory values. (except the Device name). Device will reboot
immediately upon detection of this mode.

7. COMMON PROBLEMS and QUESTIONS:

My Bluetooth client can see the
is most likely caused by a security setting on your client.
authentication by default if the client requires it (using default pincode of "1234",) but for
ease of use, you may want to turn security off on your client. Some clients have these setting
off by default, others have them on. To check and disable security:
Cedar Park, TX, USA
BlueSnap Commands Version 4.81SIO,
BlueSnap
• •
(512) 994-3630 sales@serialio.com
and its serial service, but I can't connect: This
BlueSnap
1/20/2016 Page 18 of
does support
