Casio 5519 Quick Reference Manual

MA1704-EB © 2016 CASIO COMPUTER CO., LTD.
Quick Reference Manual 5519
Congratulations upon your selection of this CASIO watch.
To ensure that this watch provides you with the years of service for which it is designed,
carefully read and follow the instructions in this manual, especially the information under
"Operating Precautions" and "User Maintenance".
Be sure to keep all user documentation handy for future reference.
®
Bluetooth is a registered trademark or trademark of Bluetooth SIG, Inc. of the United
States.
Your watch has a Mobile Link function that allows it to communicate with a Bluetooth
mobile phone and adjust its time settings to match those of the mobile phone.
•
This product complies with or has received approval under radio laws in various
countries and geographic areas. Use of this product in an area where it does not
conform to or where it has not been approved under applicable radio laws may be
punishable under local laws. For details, visit http://world.casio.com/ce/BLE/.
•
Use of this product inside of an aircraft is restricted by the aviation laws of each
country. Be sure to obey instructions provided by flight personnel concerning use of
devices such as this product.
For details about functions, go to the website
below and select your language for the EQB-
501.
http://support.casio.com/wat/bs/
Using the Watch
Charging
Remove the watch from your wrist and place it in a brightly lit area.
•
The watch may become hot when exposed to light for charging. Take care to avoid
burn injury.
•
Avoid charging in locations where it is very hot.
Power Saving
•
Leaving the watch in a dark location for about one hour between the hours of 10 p.m.
and 6 a.m. will cause the second hand to stop at 12 o'clock.
•
Leaving the watch in a dark location for about one week will cause all hands to stop at
12 o'clock.
Battery Alerts
•
Low Battery
Second hand jumps every two seconds (Low Battery Alert).
•
Dead Battery
All hands stopped at 12 o'clock.
General Guide
1 2 3
4 5 6 7
* Hold down C for about 1.5 seconds to connect via Bluetooth.
Setting the Time
1. Rotate the crown towards you to loosen it.
2. Pull the crown out to the second click.
•
This enables setting of the hour and minute.
3. Rotate the crown to change the current hour and minute setting.
4. Press A.
•
This enables the month and day setting.
5. Use B to change the month setting.
6. Rotate the crown to change the day setting.
7. Press A.
•
This enables the year 10's digit setting.
8. Rotate the crown to change the year 10's digit
setting.
1. : Bluetooth Connection
2. Hour and minute hands: Current
Click 2
time
3. AL: AL mark
Click 1
4. Dial (9 o'clock): Dual Time
5. R: Bluetooth connection standby
6. Day of the week
Crown
7. 0·100·200·300: Speedometer
Month Setting
12
11
10
9
8
7
Month 6
Year 10's Digit Setting
00
90
80
70
60
9. Press A.
•
This enables the year 1's digit setting.
10. Rotate the crown to change the year 1's digit
setting.
11. After the settings are the way you want, push
the crown back in and then screw it securely
into place.
®
Changing the Dual Time Setting
1. Rotate the crown towards you to loosen it.
2. Pull the crown out to the first click.
3. Rotate the crown to move the hands to the time
you want to set.
4. After the setting is the way you want, push the
crown back in and then screw it securely into
place.
Specifications
Accuracy at normal
temperature
Timekeeping
Stopwatch
Alarm
Mobile Link
Functions
Other
Power Supply
Approximate
Battery Life
1
2
3
4
5
Day
10
20
30
40
50
9
±
: 15 seconds a month
: Hour, minute (hands move at 10-second intervals), second; 24-hour
timekeeping, date, day of the week
Calendar system: Full-auto calendar from 2000 to 2099
Others: Dual time (hour, minute; 24-hour timekeeping; Swapping
with Home Time)
: Measuring unit: 1 second
Measuring capacity: 23:59'59" (24 hours)
Measurement functions: Elapsed time, split times
Speed Display: 0 to 300 units/hour
: Setting units: Hour, minute
Beeper: 10 seconds
: Auto Time Correction
Time setting adjusted automatically at preset time.
Auto summer time switching
Automatic switching between standard time and summer time.
Mail checking
Check for incoming mail from the watch
Phone finder
Watch operation sounds the alert sound of the mobile phone.
Stopwatch data transfer
Lap/Split time display measured in 1/1000 second for up to
100 entries
Hand position correction
Data Communication Specifications
®
Bluetooth
Frequency Band: 2440MHz-2480MHz
Maximum Transmission: 0 dBm (1 mW)
Communication range: 2 meters max. (depends on environment)
: Power Saving; Low battery alert; Airplane Mode (disables data
communication)
: Solar panel and one rechargeable battery
: 8 months
Conditions
•
Mobile Link: 4 times (40 seconds)/day
•
Alarm: Once (10 seconds)/day
•
Power Saving: 6 hours/day
Year 1's Digit Setting
0
1
2
3
8 4
7 5
6
Dual Time
1
