- Page 1 ® Pressure Side Pool Cleaner Installation Guide IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS LEGEND® INSTALLATION MANUAL...
- Page 2 10951 West Los Angeles Ave., Moorpark, CA 93021 • (800) 831-7133 • (805) 553-5000 Trademarks and Disclaimers. Pentair Water Pool and Spa and Legend are trademarks and/or registered trademarks of Pentair Water Pool and Spa, Inc. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Pentair Water Pool and Spa, Inc.
- Page 3 1-1/2" line, dedicated to our Universal Booster Pump. Also, if you have a chlorinator, solar system or other air inducing equipment, please contact our Technical Support Department at 1-800-831-7133, before you install the Legend ®...
-
Page 4: Table Of Contents
TABLE OF CONTENTS I. Introduction ..........................1 ® A. Thank You for Choosing the Legend ................1 ® B. What to Expect from the Legend ..................1 II. Installation Instructions ......................2 A. Legend ® Components ....................... 2 B. Pool Connections ......................2 C. -
Page 5: Introduction
® the Legend will go into a back up mode. At this that protects against defects in parts and time the Back Up Valve will pull the Legend® away construction. from it’s current location increasing it’s random pattern. ®... -
Page 6: Installation Instructions
The booster pump is not self-priming and needs to be fed with water taken from the pool filter before any type of in-line chlorinator. See figure below. FROM FILTER POOL HEATER POOL PUMP FILTER BOOSTER PUMP SOLAR CHLORINATOR POOL SYSTEM LEGEND® INSTALLATION MANUAL... -
Page 7: Installing The Twist Lock Pressure Relief Valve (Wall Fitting)
(soft) hose. Wall Fitting with ease from the Wall Adapter. Telepole / Clear (Soft) Hose Measure and Mark the Water Level Deepest End of Pool Main Drain LEGEND® INSTALLATION MANUAL... - Page 8 (CLEANER SIDE) FIGURE 1 WHITE OR GREY MARKED SWIVEL HARD HOSE SECTION SOFT HOSE END OF (Cut to your pool depth) SOFT HOSE (End remains 30 in.) BACK UP VALVE FURTHEST POINT OF POOL PERIMETER FROM WALL FITTING LEGEND® INSTALLATION MANUAL...
- Page 9 Marked Swivel. (Example: Half of 6 ft. = 3 ft. each). If you are cutting more than 2 ft. off the hoses, remove the floats next to the Marked Swivel from both hoses. See figures on page LEGEND® INSTALLATION MANUAL...
- Page 10 Be sure to slide the floats out of pool carefully. It should look like figure below. the way when cutting hose. 9. Put extra mender nut on the Legend ® mast and FIRST...
-
Page 11: Checking Operation
The Legend ® comes with a Twist Lock Pressure ® Relief Valve (Wall Fitting). If the Legend is receiving G. Fine Tuning the Legend ® too much water pressure, the Relief Valve in the Wall Fitting will release the excess water pressure. -
Page 12: Checking Wheel Rpm
Have someone turn on pool pump and the booster ® pump while you place the Legend in the pool just beneath the water surface. (Be sure to hold onto "U" SHAPED the Sweep Hose to avoid getting wet). -
Page 13: Periodic Maintenance
"U" SHAPED SNAP LOCK secondary filter. This screen is to keep debris that is CLOSURE ® passed by the pool filter out of the Legend . Running the Cleaner without the filter screen can damage the Legend ® and will void the warranty. -
Page 14: Tires & Bearings
After cleaning or back washing, let the pool filtration 4. Debris Bags system run for a minimum of five minutes to flush out ® the return lines before reconnecting the Legend Fine Mesh Sand & Silt Bag F. Storage and Winterizing ®... -
Page 15: Accessories
(Part # for Hose Weight is EH09C) 2. Leaf Bag (See previous page) ® 3. New Legend Suction Cup Tires Designed to climb in problem areas, fiberglass, tile and smooth surfaces. For other applications, please contact our Technical Service Department at 1-800-831-7133. -
Page 16: Troubleshooting
Legend ® doesn't move or moves sluggishly or hangs ® A Reminder: The climbing ability of the Legend is dependent on up on steps. the pool's shape and available water pressure. It will climb better in pools without sharp angles or curves in the transition from the Solution: 1. -
Page 17: Legend ® Parts List
EC70 Axle Plate 370258Z Axle Screw w/Lock Washer 360006 Wheel w/o Bearings EC60 Wheel Bearings - Only EC55 Wheel Screw - Plastic Back-up Valve 360007 Wheel - Rubber Tire EB15 Hose Clamp EC40 Screw 360005 Hub Cap LEGEND® INSTALLATION MANUAL... - Page 18 EU79 Nut & Bolt - Feed Mast to Vac Tube LLU8 Venturi Jets EU80 Screw - Top and Bottom Cover 360008 Clip Hose for 360002 FIRST 10' SECOND 10' HOSE HOSE 30" CLEAR 7.5' CLEAR HOSE HOSE LEGEND® INSTALLATION MANUAL...
-
Page 19: Legend ® Exploded View
® LEGEND EXPLODED VIEW 23 33 SAVE THESE INSTRUCTIONS. LEGEND® INSTALLATION MANUAL... - Page 20 P/N 370270 REV. A00 12/13/07 © Pentair Water Pool and Spa, Inc. All rights reserved. LEGEND® INSTALLATION MANUAL...
