8.4.1 LOADING THE SD CARD
1. Open the rubber cover on the left side of the base unit.
2. Insert the SD card into the slot with its gold electrical contacts facing
the screen, then close the rubber cover.
REMINDER
• The SD card is not properly aligned if it does not slide smoothly into the
slot. Please check the direction of the card and never use force.
• The file name will be automatically generated when saving images on the
SD card.
• For the filename extension, ".JPG" represents the still image file, and ".AVI"
represents the video file.
• File numbers are assigned sequentially from 0001 to 9999.
8.4.2 TAKING STILL IMAGES
8.4. 3 RECORDING VIDEO
20
1. When a real-time image is displayed,
press Live Camera/Video/Image
Preview toggle
camera (see Fig. 8-4).
2. Press the Camera/Video trigger button
under the handle grip or in the
lower center of the button array to
record a still image.
Fig. 8-4 Camera mode indicator
1. When a real-time image is displayed,
press Live Camera/Video/Image
Preview toggle
video (see Fig. 8-5).
2. Press the Camera/Video trigger button
to record video. Press it again to
stop recording.
Fig. 8-5 Video mode indicator
to switch the mode to
to switch the mode to
