Motherboard Layout and Features

7 6
X7SLM/X7SLM+
JPL2
8
LAN
LAN2
CTRL
9
Battery
10
Super I/O
SPI BIOS
11
Intel ICH 7
34
12
TPM CTRL
13
35
JBT1
JPT1
14
JWD
JL1
JD1
15
IDE
JP3
16
Speaker
SP1
PWR Extension
JOH1
I-SATA0 I-SATA1 I-SATA2 I-SATA3
JF1
Fan2
LE1
17 18 19 20 21 22 23 24 25

CPU Installation

Heatsink Installation

1. Open
socket
cover
2. Set heatsink
2. Insert CPU (Align
on CPU
Notches)
Lock
3. Close and
secure lever.
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this guide.
C I
ONTACT NFORMAT ION
5 4 3 2 1
VGA
COM1
USB 0/1
KB/Mouse
LAN1
JPL1
LAN
CTRL
31
30
Intel 945GC
29
MCH
CPU
28
Fan5
J41
27
= mounting hole
26

Front Panel Control (JF1)

20 19
1. Apply Ground
NMI
thermal
X
X
grease
Power LED Vcc
HDD LED Vcc
NIC1 LED Vcc
Vcc
NIC2 LED
OH/Fan Fail LED Vcc
Power Fail LED
Vcc
Reset Reset Button
Ground
3. Twist to lock
Power Button
fasteners Ground PWR
2 1
P C
ACKAGE ONTENTS
(Applies to individual-pack only)
• One (1) Supermicro Motherboard
• Two (2) SATA Cables
• One (1) Floppy Drive Ribbon Cable

Jumpers, Connectors and LED Indicators

Jumpers
Item # Jumper Description
12 JBT1 CMOS Clear
7, 31 JPL2, JPL1 GLAN 2 and GLAN 1 Enable
34 JWD Watch Dog Timer Enable
35 JPT1 TPM Support Enable (X7SLM+ only)
Connectors
Item # Connector Description
KB/Mouse PS/2 Keyboard and Mouse
1
USB 0/1 Back Panel Universal Serial Bus Ports
2
COM1, COM2 COM Port 1, COM 2 Header
3, 8
VGA Video Graphics Port
4
LAN1, LAN2 Ethernet RJ45 (Gigabit LAN) Connectors 1 and 2
5, 6
9 Floppy Floppy Disk Connector
10 Battery Onboard Battery
SPI BIOS SPI BIOS Chip
11
JL1 Chassis Intrusion Header
13
USB 2 Internal USB Port
14
USB 3/4 Front Panel USB Connections
15
I-SATA 0~3 SATA Headers
17
PWR EXTENSION (JP3) Power Extension Connector for Add-on card
18
IDE IDE Hard Drive Connector
19
JD1 Power LED/External Speaker Header
20
SP1 Internal Speaker/Buzzer
21
Fans 3, 2, 1, 5, 4 System Cooling Fans 1~4 & CPU Fan (Fan5)
16, 22, 26, 28, 30
JF1 FP Control Panel Header
23
JOH1 Overheat LED Header
25
8-Pin PWR (J41) 12V 8-pin Power Connector (Required)
27
24-Pin PWR (JPW1) ATX 24-pin Power Connector (Required)
29

LED Indicators

Item # LED Description Color/State
24 LE1 Power LED Green: On
Note: Refer to Chapter 2 of the User Manual for detailed information on jumpers, connectors, and LED indicators.
• One (1) IDE Hard Drive Cable
• One (1) I/O Shield
• One (1) Quick Reference Guide

Memory Support

This motherboard supports up to 2 GB of Unbuffered (UDIMM) Non-ECC DDR2
Default
400/533/667 MHz memory in 2 memory slots.
See Chapter 2 in User Manual
Pins 1-2 (Enabled)
Note: For memory optimization, use only DIMM modules that have been
Pins 1-2 (Reset)
validated by Supermicro. For the latest memory updates, please refer to our
Pins 1-2 (Enabled) website at http://www.supermicro.com/products/motherboard.

DIMM Installation

Towards the CPU
DIMM1A
DIMM1B
Towards the PCI slot
Installing DDR2 Memory
1. Insert the desired number of DIMMs into the memory slots, starting with
DIMM1A. Insert each DIMM module vertically into its slot. Pay attention
to the notch along the bottom of the module to prevent incorrect DIMM
module installation.
2. Gently press down on the DIMM module until it snaps into place in the
slot. Repeat step 1 to install DIMM1B if needed.

Back Panel IO Connectors

B
D
Status
System On
A C E
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
A. PS/2 Keyboard
B. PS/2 Mouse
C. USB Port 1
D. USB Port 2
E. COM 1
F. VGA
G. LAN 1
F G H
H. LAN 2
