  • Page 1 UPER X7DB8 X7DBE USER’S MANUAL Revision 1.0a...
  • Page 2 Manual Revision: Rev. 1.0a Release Date: Aug. 8, 2006 Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not copy any part of this document. Information in this document is subject to change without notice. Other products and companies referred to herein are trademarks or registered trademarks of their respective companies or mark holders.

  • Page 3: About This Manual

    Preface About This Manual This manual is written for system integrators, PC technicians and knowledgeable PC users. It provides information for the installation and use of the X7DB8/X7DBE motherboard. The Intel Xeon 64-bit dual core processors at a front side bus speed of 1333/1066/667 MHz.

  • Page 4: Table Of Contents

    X7DB8/X7DBE User's Manual Table of Contents Preface About This Manual ... iii Manual Organization ... iii Conventions Used in the Manual ... iii Chapter 1: Introduction Overview ... 1-1 Checklist ... 1-1 Contacting Supermicro ... 1-2 X7DB8/X7DBE Image ... 1-3 X7DB8/X7DBE Layout ...
  • Page 5 Reset Button ... 2-13 Power Button ... 2-13 2-5 Connecting Cables ... 2-14 ATX Power Connector ... 2-14 Processor Power Connector ... 2-14 Universal Serial Bus (USB0/1) ... 2-15 Chassis Intrusion ... 2-15 Fan Headers ... 2-16 Keylock ... 2-16 ATX PS/2 Keyboard and Mouse Ports ...
  • Page 6 X7DB8/X7DBE User's Manual Parallel Port Connector ... 2-31 Floppy Connector ... 2-32 SIMLP IPMI Slot ... 2-32 IDE Connectors ... 2-33 Ultra 320 SCSI Connectors ... 2-34 Chapter 3: Troubleshooting Troubleshooting Procedures ... 3-1 Before Power On ... 3-1 No Power ... 3-1 No Video ...

  • Page 7: Chapter 1 Introduction

    Overview Checklist Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Check that the following items have all been included with your motherboard. If anything listed here is damaged or missing, contact your retailer.

  • Page 8: Contacting Supermicro

    X7DB8/X7DBE User's Manual Contacting Supermicro Headquarters Address: SuperMicro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: SuperMicro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...

  • Page 9: X7Db8/X7Dbe Image

    Chapter 1: Introduction Figure 1-1. X7DB8/X7DBE Image *Note: The drawings and pictures shown in this manual were based on the latest PCB Revision available at the time of publishing of the manual. The motherboard you’ve received may or may not look exactly the same as the graphics shown in the manual.)

  • Page 10: X7Db8/X7Dbe Layout

    X7DB8/X7DBE User's Manual Figure 1-2. X7DB8/X7DBE Motherboard Layout (not drawn to scale) 8-pin P W R S MB PS J 17 PSF J PW3 J PW1 J 3P J PW2 J A R GLAN1 J LAN1 GLAN2 J LAN2 S IMLP IPMI S E PC P C I-E xp P C I-E xp...

  • Page 11: Quick Reference

    Quick Reference ( X7DB8/X7DBE) Jumper Description J27, J28 C Bus to PCI-X/PCI-E Slots 3rd PWR Failure Detect JBT1 CMOS Clear JCF1 Compact Card Master/Slave Select JPA1 (*X7DB8) SCSI Controller Enable JPA2, JPA3 SCSI CHA(JPA2),CHB(JPA3)Term.En Off (Enabled) (*X7DB8) JPG1 VGA Enable JPL1/ JPL2 GLAN1/GLAN2 Enable Watch Dog...

  • Page 12: Motherboard Features

    X7DB8/X7DBE User's Manual Motherboard Features • Dual Intel ® 64-bit Xeon LGA 771 dual core processors at a front side bus speed of 1.333 GHz/1.066 GHz/667 MHz with a system clock speed of 333/267 MHz Memory • Eight 240-pin DIMM sockets with support up to 16 (32) GB DDR2 Fully Buff- ered (FBD) ECC 667/533 Memory (*See Section 2-3 in Chapter 2 for DIMM Slot Population.) Chipset...
  • Page 13 ACPI Features • Slow blinking LED for suspend state indicator • Main switch override mechanism • ACPI/ACPM Power Management • Keyboard Wakeup from Soft-off Onboard I/O • Adaptec 7902 dual channel Ultra 320 SCSI with ZCR option (*X7DB8 only) • Six SATA2 ports (supporting RAID0, RAID1,10 and 5) •...
  • Page 14 X7DB8/X7DBE User's Manual 6307 667/1067/ 1333 PC I - E XP x8 PC I - E XP x8 PCI - E XP x4 S CS I PCI -x 133A PCI -E XP x8 7902 PX H PCI - x133B PCI -X 133 VG A PC I 32/ 33 CONN...

  • Page 15: Chipset Overview

    Chapter 1: Introduction Chipset Overview Built upon the functionality and the capability of the 5000P (Blackford) chipset, the X7DB8/X7DBE motherboard provides the performance and feature set required for dual processor-based servers with confi guration options optimized for commu- nications, presentation, storage, computation or database applications. The 5000P (Blackford) chipset supports single or dual Xeon 64-bit dual core processor(s) with front side bus speeds of up to 1.333 GHz.

  • Page 16: Special Features

    X7DB8/X7DBE User's Manual Special Features Recovery from AC Power Loss BIOS provides a setting for you to determine how the system will respond when AC power is lost and then restored to the system. You can choose for the system to remain powered off (in which case you must hit the power switch to turn it back on) or for it to automatically return to a power- on state.

  • Page 17: Acpi Features

    CPU Fan Auto-Off in Sleep Mode The CPU fan activates when the power is turned on. It continues to operate when the system enters Standby mode. When in sleep mode, the CPU will not run at full power, thereby generating less heat. CPU Overheat LED and Control This feature is available when the user enables the CPU overheat warning function in the BIOS.

  • Page 18: Power Supply

    X7DB8/X7DBE User's Manual Main Switch Override Mechanism When an ATX power supply is used, the power button can function as a system suspend button to make the system enter a SoftOff state. The monitor will be suspended and the hard drive will spin down. Pressing the power button again will cause the whole system to wake-up.

  • Page 19: Super I/O

    Chapter 1: Introduction NOTE: The + 12V 8-pin Aux. Power Connector is also required to support Intel 64-bit CPUs. Failure to provide this extra power will result in CPU PWR Failure. See Section 2-5 for details on connecting the power supply. It is strongly recommended that you use a high quality power supply that meets ATX power supply Specifi...
  • Page 20 X7DB8/X7DBE User's Manual Notes 1-14...

  • Page 21: Chapter 2 Installation

    Static-Sensitive Devices Electric-Static-Discharge (ESD) can damage electronic com ponents. To prevent damage to your system board, it is important to handle it very carefully. The following measures are generally suffi cient to protect your equipment from ESD. Precautions • Use a grounded wrist strap designed to prevent static discharge. •...

  • Page 22: Processor And Heatsink Installation

    X7DB8/X7DBE User's Manual Processor and Heatsink Fan Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. (*Notes: 1. Always connect the power cord last and always remove it before adding, removing or changing any hardware components. Make sure that you install the processor into the CPU socket before you install the CPU heatsink.
  • Page 23 3. Use your thumb and your index fi nger to hold the CPU at the North Center Edge and the South Center Edge of the CPU. 4. Align CPU Pin1 (the CPU corner marked with a triangle) against the socket corner that is marked with a triangle cutout.
  • Page 24 X7DB8/X7DBE User's Manual Installation of the Heatsink CEK Heatsink Installation 1. Do not apply any thermal grease to the heatsink or the CPU die-the required amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the retention mechanism.
  • Page 25 1. Unscrew and remove the heatsink screws from the motherboard in the sequence as show in the picture on the right. 2. Hold the heatsink as shown in the picture on the right and gently wriggle the heatsink to loosen it from the CPU. (Do not use excessive force when wriggling the heatsink!!) 3.

  • Page 26: Installing Dimms

    X7DB8/X7DBE User's Manual Installing DIMMs Note: Check the Supermicro web site for recommended memory modules. Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Also note that the memory is interleaved to improve performance (see step 1). DIMM Installation (See Figure 2-2) 1.
  • Page 27 Figure 2-2. Installing and Removing DIMMs To Install: Insert module vertically and press down until it snaps into place. Pay attention to the alignment notch at the bottom. To Remove: Use your thumbs to gently push the release tabs near both ends of the module.

  • Page 28: Control Panel Connectors/Io Ports

    X7DB8/X7DBE User's Manual Control Panel Connectors/IO Ports The I/O ports are color coded in conformance with the PC 99 specifi cation. See Figure 2-3 below for the colors and locations of the various I/O ports. A. Back Panel Connectors/IO Ports Figure 2-3.

  • Page 29: Front Control Panel

    B. Front Control Panel JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifi - cally for use with Supermicro server chassis. See Figure 2-4 for the descriptions of the various control panel buttons and LED indicators.

  • Page 30: Front Control Panel Pin Defi Nitions

    X7DB8/X7DBE User's Manual C. Front Control Panel Pin Defi nitions NMI Button The non-maskable interrupt button header is located on pins 19 and 20 of JF1. Refer to the table on the right for pin defi nitions. Power LED The Power LED connection is located on pins 15 and 16 of JF1.

  • Page 31: Nic1/Nic2 Leds

    HDD LED The HDD LED connection is located on pins 13 and 14 of JF1. Attach the hard drive LED cable here to display disk activity (for any hard drives on the system, including SAS, Serial ATA and IDE). See the table on the right for pin defi...

  • Page 32: Overheat/Fan Fail Led

    X7DB8/X7DBE User's Manual Overheat/Fan Fail LED (OH) Connect an LED to the OH/Fan Fail connection on pins 7 and 8 of JF1 to provide advanced warning of chassis overheating or fan failure. Refer to the table on the right for pin defi ni- tions.

  • Page 33: Reset Button

    Reset Button The Reset Button connection is located on pins 3 and 4 of JF1. Attach it to the hardware reset switch on the computer case. Refer to the table on the right for pin defi nitions. Power Button The Power Button connection is located on pins 1 and 2 of JF1.

  • Page 34: Connecting Cables

    X7DB8/X7DBE User's Manual Connecting Cables ATX Power Connector There are a 24-pin main power sup- ply connector(JPW1) and an 8-pin CPU PWR connector (JPW3) on the motherboard. These power connec- tors meet the SSI EPS 12V specifi ca- tion. The 4-pin 12V PWR supply is required to provide adequate power to the system.

  • Page 35: Universal Serial Bus (Usb0/1)

    Universal Serial Bus (USB) There are fi ve USB 2.0 (Universal Serial Bus) ports/headers on the motherboard. Two of them are Back Panel USB ports (USB#0/1:JUSB1), and the other three are Front Panel USB headers (USB#2/3:JUSB2, USB#4: JUSB3). See the tables on the right for pin defi...

  • Page 36: Fan Headers

    X7DB8/X7DBE User's Manual Fan Headers The X7DB8/X7DBE has eight chassis/system fan headers (Fan1 to Fan8) and two CPU Fans (Fans 7/8). (*Note: all these fans are 4-pin fans. However, Pins 1-3 of the fan headers are backward compatible with the traditional 3-pin fans.) See the table on the right for pin defi...

  • Page 37: Atx Ps/2 Keyboard And Mouse Ports

    ATX PS/2 Keyboard and PS/2 Mouse Ports The ATX PS/2 keyboard and the PS/2 mouse are located at JKM1. See the table on the right for pin defi nitions. (The mouse port is above the key- board port. See the table on the right for pin defi...

  • Page 38: Wake-On-Ring

    X7DB8/X7DBE User's Manual Wake-On-Ring The Wake-On-Ring header is desig- nated JWOR. This function allows your computer to receive and be "waken up" by an incoming call to the modem when the system is in the suspend state. See the table on the right for pin defi...

  • Page 39: Glan (Ethernet Ports)

    GLAN 1/2 (Giga-bit Ethernet Ports) Two G-bit Ethernet ports are desig- nated JLAN1 and JLAN2 on the IO backplane. This port accepts RJ45 type cables. Power LED/Speaker On the JD1 header, pins 1-3 are for a power LED and pins 4-7 are for the speaker..

  • Page 40: Power Fault

    X7DB8/X7DBE User's Manual Power Fault (PWR Supply Failure) Connect a cable from your power supply to the Power Fail (PSF) header to provide warning of power supply failure. This warning signal is passed through the PWR_LED pin to indicate of a power failure on the chassis. See the table on the right for pin defi...

  • Page 41: Overheat Led/Fan Fail

    Overheat LED/Fan Fail (JOH1) The JOH1 header is used to connect an LED to provide warning of chassis overheating. This LED will blink to in- dicate a fan failure. Refer to the table on right for pin defi nitions. A System Management Bus header is located at J18.

  • Page 42: Power Smb

    X7DB8/X7DBE User's Manual Power SMB (I C) Connector Power SMB (I C) Connector (J17) monitors the status of PWR Supply, Fan and system temperature. See the table on the right for pin defi nitions. VGA Connector A VGA connector (JG1) is located next to the COM1 port on the IO backplane.

  • Page 43: Compact Flash Card Pwr Connector

    Compact Flash Card PWR Connector Compact Flash Card Power Connector is located at JWF1. For the Compact Flash Card or the Compact Flash Jumper (JCF1) to work properly, you will need to connect the Compact Flash Card power cable to JWF1 fi rst. Refer to the board layout below for the location.

  • Page 44: Jumper Settings

    X7DB8/X7DBE User's Manual Jumper Settings Explanation of Jumpers To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identifi ed with a square solder pad on the printed circuit board.

  • Page 45: Cmos Clear

    CMOS Clear JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads to prevent the accidental clearing of CMOS. To clear CMOS, use a metal object such as a small screwdriver to touch both pads at the same time to short the connection.

  • Page 46: Scsi Controller Enabled/Disabled

    X7DB8/X7DBE User's Manual SCSI Controller Enable/ Disable Jumper JPA1 is used to enable or disable the LSI SCSI controller. The default set- ting is on pins 1-2 to enable SCSI. See the table on the right for jumper settings. SCSI Termination Enable/ Disable Jumpers JPA2/JPA3 are used to enable or disable termination for SCSI Channel...

  • Page 47: 3Rd Pwr Supply Pwr Fault

    3rd PWR Supply PWR Fault Detect (J3P) The system can notify you in the event of a power supply failure. This feature available when three power supply units are installed in the chassis with one act- ing as a backup. If you only have one or two power supply units installed, you should disable this (the default setting) with J3P to prevent false alarms.

  • Page 48: Compact Flash Master/Slave Select

    X7DB8/X7DBE User's Manual Compact Flash Master/Slave Select A Compact Flash Master (Primary)/ Slave (Secondary) Select Jumper is located at JCF1. Close this jumper to enable Compact Flash Card. For the Compact Flash Card or the Compact Flash Jumper (JCF1) to work properly, you will need to connect the Compact Flash Card power cable to JWF1 fi...

  • Page 49: Onboard Indicators

    Onboard Indicators GLAN LEDs There are two GLAN ports on the motherboard. Each Gigabit Ether- net LAN port has two LEDs. The green LED indicates activity, while the power LED may be green, am- ber or off to indicate the speed of the connection.

  • Page 50: Onboard Scsi Activity Led

    X7DB8/X7DBE User's Manual Onboard SCSI Activity LED Indicators (*X7DB8 only) There are two Onboard SCSI Activity LED indicators on the X7DB8. DA1 indicates the activity status of SCSI Channel A, and DA2 indicates the activity status of SCSI Channel B. Onboard Power LED There is an Onboard Power LED located on the motherboard.

  • Page 51: Parallel Port Connector

    Parallel Port, Floppy Drive, Hard Disk Drive, SIMLP IPMI and SCSI Connections Note the following when connecting the fl oppy and hard disk drive cables: • The fl oppy disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1. •...

  • Page 52: Floppy Connector

    X7DB8/X7DBE User's Manual Floppy Connector The fl oppy connector is located next to the compact fl ash card slot. See the table below for pin defi nitions. SIMLP IPMI Slot There is a SIM Low Profile IPMI Slot on the motherboard. Refer to the layout below for the IPMI Slot location.

  • Page 53: Ide Connectors

    IDE Connectors There are two IDE Connectors (JIDE1: Blue, JIDE2: White) on the mother- board. The blue IDE connector (JIDE1) is designated as the Primary IDE Drive. The white IDE connector (JIDE2) is des- ignated as the Secondary IDE Drive, reserved for Compact Flash Card use only.

  • Page 54: Ultra 320 Scsi Connectors

    X7DB8/X7DBE User's Manual Ultra 320 SCSI Connectors (*X7DB8 only) There are two SCSI connectors on the motherboard. SCSI Channel A is located at JA1, and SCSI Channel B is located at JA2. Refer to the table below for the pin defi nitions of the Ultra 320 SCSI connectors located at JA1 and JA2.

  • Page 55: Chapter 3: Troubleshooting

    Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Note: Always disconnect the power cord before adding, changing or installing any hardware components.

  • Page 56: Memory Errors

    X7DB8/X7DBE User's Manual ~3VDC. If it does not, replace it with a new one. 3. If the above steps do not fi x the Setup Confi guration problem, contact your vendor for repairs. If you are a system integrator, VAR or OEM, a POST diagnostics card is recommended.

  • Page 57: Frequently Asked Questions

    3. If you still cannot resolve the problem, include the following information when contacting Super Micro for technical support: • Motherboard model and PCB revision number • BIOS release date/version (this can be seen on the initial display when your system fi...

  • Page 58: Returning Merchandise For Service

    X7DB8/X7DBE User's Manual Returning Merchandise for Service A receipt or copy of your invoice marked with the date of purchase is required be- fore any warranty service will be rendered. You can obtain service by calling your vendor for a Returned Merchandise Authorization (RMA) number. When returning to the manufacturer, the RMA number should be prominently displayed on the outside of the shipping carton, and mailed prepaid or hand-carried.

  • Page 59: Chapter 4: Bios

    Chapter 4 4-1 Introduction This chapter describes the Phoenix BIOS™ Setup utility for the X7DB8/X7DBE. The Phoenix ROM BIOS is stored in a fl ash chip and can be easily upgraded using a fl oppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 60: Running Setup

    X7DB8/X7DBE User's Manual Running Setup *Default settings are in bold text unless otherwise noted. The BIOS setup options described in this section are selected by choosing the appropriate text from the main BIOS Setup screen. All displayed text is described in this section, although the screen display is often all you need to understand how to set the options (see next page).

  • Page 61: Main Bios Setup Menu

    Chapter 4: BIOS Main BIOS Setup Menu Main Setup Features System Time To set the system date and time, key in the correct information in the appropriate fi elds. Then press the <Enter> key to save the data. System Date Using the arrow keys, highlight the month, day and year fi...
  • Page 62 X7DB8/X7DBE User's Manual IDE Channel 0 Master/Slave, IDE Channel 1 Master/Slave, SATA Port2 and SATA Port3 These settings allow the user to set the parameters of IDE Channel 0 Master/ Slave, IDE Channel 1 Master/Slave, IDE Channel 2 Master, IDE Channel 3 Master slots.

  • Page 63: Multi-Sector Transfers

    Chapter 4: BIOS CHS Format The following items will be displayed by the BIOS: TYPE: This item displays the type of IDE or SATA Device. Cylinders: This item indicates the status of Cylinders. Headers: This item indicates the number of headers. Sectors: This item displays the number of sectors.
  • Page 64 X7DB8/X7DBE User's Manual Parallel ATA This setting allows the user to enable or disable the function of Parallel ATA. The options are Disabled, Channel 0, Channel 1, and Both. Serial ATA This setting allows the user to enable or disable the function of Serial ATA. The options are Disabled and Enabled.

  • Page 65: System Memory

    Chapter 4: BIOS System Memory This display informs you how much system memory is recognized as being present in the system. Extended Memory This display informs you how much extended memory is recognized as being present in the system. Advanced Setup Choose Advanced from the Phoenix BIOS Setup Utility main menu with the arrow keys.
  • Page 66 X7DB8/X7DBE User's Manual Boot Features Access the submenu to make changes to the following settings. Quick Boot Mode If enabled, this feature will speed up the POST (Power On Self Test) routine by skipping certain tests after the computer is turned on. The settings are Enabled and Disabled.

  • Page 67: Cache Video Bios Area

    Chapter 4: BIOS Memory Cache Cache System BIOS Area This setting allows you to designate a reserve area in the system memory to be used as a System BIOS buffer to allow the BIOS write (cache) its data into this reserved memory area.
  • Page 68 X7DB8/X7DBE User's Manual Select "Uncached" to disable this function. Select "Write Through" to allow data to be cached into the buffer and written into the system memory at the same time. Select "Write Protect" to prevent data from being written into the base memory area of Block 0-512K.
  • Page 69 Slot1 PCI-X 100 MHz ZCR, Slot2 PCI-X 133MHz, Slot3 PCI-X 133MHz, Slot4 PCI-Exp x4, Slot5 PCI-Exp x8, and Slot6 PCI-Exp x8 Access the submenu for each of the settings above to make changes to the following: Option ROM Scan When enabled, this setting will initialize the device expansion ROM. The options are Enabled and Disabled.
  • Page 70 X7DB8/X7DBE User's Manual Memory Branch Mode This option determines how the two memory branches operate. System address space can either be interleaved between the two branches or Sequential from one branch to another. Mirror mode allows data correction by maintaining two copies of data in two branches.

  • Page 71: Advanced Processor Options

    Chapter 4: BIOS Advanced Processor Options Access the submenu to make changes to the following settings. CPU Speed This is a display that indicates the speed of the installed processor. Frequency Ratio (*Available when supported by the CPU.) The feature allows the user to set the internal frequency multiplier for the CPU. The options are: Default, x12, x13, x14, x15, x16, x17 and x18.
  • Page 72 X7DB8/X7DBE User's Manual Adjacent Cache Line Prefetch (*Available when supported by the CPU.) The CPU fetches the cache line for 64 bytes if this option is set to Disabled. The CPU fetches both cache lines for 128 bytes as comprised if Enabled. The options are Disabled and Enabled.
  • Page 73 Chapter 4: BIOS Interrupt This setting allows you to select the IRQ (interrupt request) for serial port A. The options are IRQ3 and IRQ4. Serial Port B This setting allows you to assign control of serial port B. The options are Enabled (user defi...
  • Page 74 X7DB8/X7DBE User's Manual DMI Event Logging Access the submenu to make changes to the following settings. Event Log Validity This is a display to inform you of the event log validity. It is not a setting. Event Log Capacity This is a display to inform you of the event log capacity. It is not a setting. View DMI Event Log Highlight this item and press <Enter>...
  • Page 75 Chapter 4: BIOS Console Redirection Access the submenu to make changes to the following settings. COM Port Address This item allows you to specify to redirect the console to Onboard COM A or Onboard COM B. This setting can also be Disabled. BAUD Rate This item allows you to select the BAUD rate for console redirection.

  • Page 76: Hardware Monitor Logic

    X7DB8/X7DBE User's Manual Hardware Monitor Logic *Note: The Phoenix BIOS will automatically detect the type of CPU(s) and hardware monitoring chip used on the motherboard and will display the Hardware Monitoring Screen accordingly. Your Hardware Monitoring Screen may look like the one shown on this page, on P. 4-19, or on P. 4-20, depending on the type of CPU(s) and HW Monitoring chip you are using.
  • Page 77 Chapter 4: BIOS Hardware Monitor Logic CPU Temperature Threshold (*See the Note on Page 4-18.) This option allows the user to set a CPU temperature threshold that will activate the alarm system when the CPU temperature reaches this pre-set temperature threshold.

  • Page 78: Temperature Monitoring

    X7DB8/X7DBE User's Manual Hardware Monitor Logic (*See the Note on Page 4-18.) CPU Temperature Threshold This option allows the user to set a CPU temperature threshold that will activate the alarm system when the CPU temperature reaches this pre-set temperature threshold.

  • Page 79: Ipmi Specifi Cation Version

    IPMI (The option is available only when an IPMI card is installed in the system.) IPMI Specifi cation Version: Firmware Version: This item displays the current Firmware Version. System Event Logging Select Enabled to enable IPMI Event Logging. When this function is set to Disabled, the system will continue to log events received via system interface.

  • Page 80: System Event Log/System Event Log (List Mode)

    X7DB8/X7DBE User's Manual OS Boot Watch Dog Set to Enabled to enable OS Boot Watch Dog. The options are Enabled and Disabled. Timer for Loading OS (Minutes) This feature allows the user to set the time value (in minutes) for the previous item: OS Boot Watch Dog by keying-in a desired number in the blank.

  • Page 81: Realtime Sensor Data

    Chapter 4: BIOS Realtime Sensor Data This feature display information from motherboard sensors, such as temperatures, fan speeds and voltages of various components. 4-23...

  • Page 82: Set Supervisor Password

    X7DB8/X7DBE User's Manual Security Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. Security setting options are displayed by highlighting the setting using the arrow keys and pressing <Enter>. All Security BIOS settings are described in this section.

  • Page 83: Password On Boot

    Password on Boot This setting allows you to require a password to be entered when the system boots up. The options are Enabled (password required) and Disabled (password not required). Boot Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display.

  • Page 84: Exit

    X7DB8/X7DBE User's Manual Exit Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. All Exit BIOS settings are described in this section. Exit Saving Changes Highlight this item and hit <Enter> to save any changes you made and to exit the BIOS Setup utility.

  • Page 85: Appendix Abios Post Messages

    Appendix A: BIOS POST Messages Appendix A BIOS POST Messages During the Power-On Self-Test (POST), the BIOS will check for problems. If a prob- lem is found, the BIOS will activate an alarm or display a message. The following is a list of such BIOS messages.
  • Page 86 X7DB8/X7DBE User's Manual System CMOS checksum bad - Default confi guration used System CMOS has been corrupted or modifi ed incorrectly, perhaps by an application program that changes data stored in CMOS. The BIOS installed Default Setup Values. If you do not want these values, enter Setup and enter your own values.
  • Page 87 Appendix A: BIOS POST Messages System cache error - Cache disabled RAM cache failed and BIOS disabled the cache. On older boards, check the cache jumpers. You may have to replace the cache. See your dealer. A disabled cache slows system performance considerably. CPU ID: CPU socket number for Multi-Processor error.
  • Page 88 X7DB8/X7DBE User's Manual Fixed Disk n Fixed disk n (0-3) identifi ed. Invalid System Confi guration Data Problem with NVRAM (CMOS) data. I/O device IRQ confl ict I/O device IRQ confl ict error. PS/2 Mouse Boot Summary Screen: PS/2 Mouse installed. nnnn kB Extended RAM Passed Where nnnn is the amount of RAM in kilobytes successfully tested.
  • Page 89 Appendix A: BIOS POST Messages Parity Check 2 nnnn Parity error found in the I/O bus. BIOS attempts to locate the address and display it on the screen. If it cannot locate the address, it displays ????. Press <F1> to resume, <F2> to Setup, <F3> for previous Displayed after any recoverable error message.
  • Page 90 X7DB8/X7DBE User's Manual Notes...

  • Page 91: Appendix Bbios Post Codes

    Appendix B BIOS POST Codes This section lists the POST (Power On Self Test) codes for the PhoenixBIOS. POST codes are divided into two categories: recoverable and terminal. Recoverable POST Errors When a recoverable type of error occurs during POST, the BIOS will display an POST code that describes the problem.
  • Page 92 X7DB8/X7DBE User's Manual POST Code Description 8254 timer initialization 8237 DMA controller initialization Reset Programmable Interrupt Controller 1-3-1-1 Test DRAM refresh 1-3-1-3 Test 8742 Keyboard Controller Set ES segment register to 4 GB Auto size DRAM Initialize POST Memory Manager Clear 512 kB base RAM 1-3-4-1 RAM failure on address line xxxx* 1-3-4-3 RAM failure on data bits xxxx* of low byte of...
  • Page 93 POST Code Description Test RAM between 512 and 640 kB Test extended memory Test extended memory address lines Jump to UserPatch1 Confi gure advanced cache registers Initialize Multi Processor APIC Enable external and CPU caches Setup System Management Mode (SMM) area Display external L2 cache size Load custom defaults (optional) Display shadow-area message...

  • Page 94: Enter Setup

    X7DB8/X7DBE User's Manual POST Code Description Check for SMART Drive (optional) Set up Power Management Initialize security engine (optional) Enable hardware interrupts Determine number of ATA and SCSI drives Set time of day Check key lock Initialize typematic rate Erase <ESC> prompt Scan for <ESC>...
  • Page 95 POST Code Description Unknown interrupt Check Intel Branding string Alert Standard Format initialization Late init for IPMI Log error if micro-code not updated properly The following are for boot block in Flash ROM POST Code Description Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O...
  • Page 96 X7DB8/X7DBE User's Manual Notes...

  • Page 97: Appendix C: The Intel Hostraid Setup Guidelines

    Appendix C: The Intel HostRAID Setup Guidelines Appendix C The Intel HostRAID Setup Guidelines After all the hardware has been installed, you must fi rst confi gure Intel's ESB2 SATA RAID* before you install the Windows Operating System and other software drivers.
  • Page 98 X7DB8/X7DBE User's Manual The Intel HostRAID Confi gurations The following types of Intel's HostRAID confi gurations are supported: RAID 0 (Data Striping): this writes data in parallel, interleaved ("striped") sections of two hard drives. Data transfer rate is doubled over using a single disk. RAID1 (Data Mirroring): an identical data image from one drive is copied to another drive.
  • Page 99 Using the Intel ESB2 SATA RAID Utility Program 1. Creating, Deleting and Resetting RAID Volumes: a. After the system exits from the BIOS Setup Utility, the system will automatically reboot. The following screen appears after Power-On Self Test. b. When you see the above screen, press the <Ctrl> and the <I> keys simultane- ously to have the main menu of the SATA RAID Utility appear: (*Note: All graphics and screen shots shown in the manual are for refer- ence only.

  • Page 100: Creating A Raid 0 Volume

    X7DB8/X7DBE User's Manual Creating a RAID 0 Volume: a. Select "Create RAID Volume" from the main menu and press the <Enter> key. The following screen will appear: b. Specify a name for the RAID 0 set and press the <Tab> key or the <Enter> key to go to the next fi...

  • Page 101: Creating A Raid 1 Volume

    Appendix C: The Intel HostRAID Setup Guidelines Creating a RAID 1 Volume: a. Select "Create RAID Volume" from the main menu and press the <Enter> key. The following screen will appear: b. Specify a name for the RAID 1 set and press the <Tab> key or the <Enter> key to go to the next fi...
  • Page 102 X7DB8/X7DBE User's Manual Creating a RAID 10 (RAID 1+ RAID 0): a. Select "Create RAID Volume" from the main menu and press the <Enter> key. The following screen will appear: b. Specify a name for the RAID 10 set and press <Enter>. c.

  • Page 103: Creating A Raid 5 Set (Parity)

    Appendix C: The Intel HostRAID Setup Guidelines Creating a RAID 5 Set (Parity): a. Select "Create RAID Volume" from the main menu and press the <Enter> key. The following screen will appear: b. Specify a name for the RAID 5 set and press <Enter>. c.

  • Page 104: Deleting Raid Volume

    X7DB8/X7DBE User's Manual Deleting RAID Volume: (Warning: Be sure to back up your data before deleting a RAID set. You will lose all data on the disk drives when deleting a RAID set.) a. From the main menu, select item2-Delete RAID Volume, and press <Enter>. b.

  • Page 105: Exiting The Intel Matrix Storage Manager Utility

    Resetting to Non-RAID and Resetting a RAID HDD (Warning: Be cautious when you reset a RAID volume HDD to non- RAID or Resetting a RAID HDD. Resetting a RAID volume HDD or Resetting a RAID HDD will reformat the HDD and delete the internal RAID structure on the drive.) a.
  • Page 106 X7DB8/X7DBE User's Manual C-2 Installing the Windows XP/2000/2003 for systems with RAID Functions New Operating System-Windows XP/2000/2003 Installation a. Insert Microsoft Windows XP/2000/2003 Setup CD in the CD Driver, and the system will start booting up from CD. b. Press the <F6> key when the message-" Press F6 if you need to install a third party SCSI or RAID driver"...

  • Page 107: Appendix D: The Adaptec Hostraid Setup Guidelines

    Appendix D The Adaptec HostRAID Setup Guidelines After all the hardware has been installed, you must fi rst confi gure the Adaptec Embedded Serial ATA RAID before you install the Windows operating system. The necessary drivers are all included on the Supermicro bootable CDs that came packaged with your motherboard.
  • Page 108 X7DB8/X7DBE User's Manual To confi gure the Adaptec SATA RAID for Operating Systems that support RAID functions(--Windows, Red Hat & SuSe, Linux) 1. Press the <Del> key during system bootup to enter the BIOS Setup Utility. Note: If it is the fi rst time powering on the system, we recommend you load the Optimized Default Settings.

  • Page 109: Using The Adaptec Raid Confi Guration Utility (Arc)

    Appendix D: The Adaptec HostRAID Setup Guidelines The Adaptec Embedded Serial ATA with HostRAID Controller Driver The Adaptec Embedded Serial ATA RAID Controller adds SATA/RAID functional- ity and performance enhancements to a motherboard. RAID striping (RAID 0) allows data to be written across multiple drives, greatly improving hard disk I/O performance.

  • Page 110: Managing Arrays

    X7DB8/X7DBE User's Manual Managing Arrays Select this option to view array properties, and confi gure array settings. To select this option, using the arrow keys and the <enter> key, select "Manag- ing Arrays" from the main menu as shown above.

  • Page 111: Confi Guring Disk Drives

    Appendix D: The Adaptec HostRAID Setup Guidelines Confi guring Disk Drives You may need to confi gure a disk drive before you can use it. Caution: Confi guring a disk may overwrite the partition table on the disk and may make any data on the disk inaccessible. If the drive is used in an array, you may not be able to use the array again.
  • Page 112 X7DB8/X7DBE User's Manual 2. From the "Select Drives for Confi guring" List (shown below,) select the drives you want to confi gure and press <Insert>. 3. The drive you've selected will appear in the "Selected Drives Dialog Box" on the right (as shown below.) Repeat the same steps until all drives that you want to confi...
  • Page 113 Appendix D: The Adaptec HostRAID Setup Guidelines 5. Read the warning message as shown in the screen below. 6. Make sure that you have selected the correct disk drives to confi gure. If cor- rect, type Y to continue.

  • Page 114: Creating Arrays

    X7DB8/X7DBE User's Manual Creating Arrays Before you create arrays, make sure that the disks for the array are connected and installed in your system. Note that disks with no usable space, or disks that are un-initialized or not formatted are shown in gray and cannot be used. (*Note: It is recommended that you confi...
  • Page 115 Assigning Array Properties Once a new array is completed, you can assign properties to the array. *Caution: Once the array is created and its properties are assigned, and you cannot change the array properties using this utility. To assign properties to the new array: 1.
  • Page 116 X7DB8/X7DBE User's Manual 5. When you are fi nished, press <Done> (as the screen shown below). Notes: 1. Before adding a new drive to an array, be sure to back up any data stored on the new drive; otherwise, all data will be lost. 2.
  • Page 117 Appendix D: The Adaptec HostRAID Setup Guidelines Adding a Bootable Array To make an array bootable: 1. From the Main menu, select Manage Arrays. 2. From the List of Arrays, select the array you want to make bootable, and press <Ctrl>...
  • Page 118 X7DB8/X7DBE User's Manual Adding/Deleting Hotspares To add a Hotspare: (*Note: In order to rebuild a RAID (RAID 0 or RAID 1), you would need to add a new HDD as a hotspare.) 1. From the main menu (shown on Page D-4), select Add/Delete Hotspares. 4.
  • Page 119 Appendix D: The Adaptec HostRAID Setup Guidelines Viewing Array Properties To view the properties of an existing array: 1. From the main menu, select Manage Arrays and hit <Enter> (as shown on the previous page.) 2. From the List of Arrays dialog box (shown below), select the array you want to view and press Enter.

  • Page 120: Rebuilding Arrays

    X7DB8/X7DBE User's Manual Rebuilding Arrays *Note 1: Rebuilding applies to Fault Tolerant array (RAID 1) only. If an array Build process is interrupted or when one critical member is missing, you must perform a Rebuild to restore its functionality. For a critical array rebuild operation, the optimal drive is the source drive.
  • Page 121 Appendix D: The Adaptec HostRAID Setup Guidelines Deleting Arrays *Warning: Back up the data on an array before you delete it to prevent data loss Deleted arrays cannot be restored. To delete an existing array: 1. From the main menu (shown on Page D-4), select Manage Arrays. 2.

  • Page 122: Using The Disk Utilities

    X7DB8/X7DBE User's Manual Using the Disk Utilities The Disk Utilities enable you to format or verify the media of your Serial ATA hard disks. To access the disk utilities: 1. From the Adaptec RAID Confi guration Utility Menu, select Disk Utilities (as shown above) and press <Enter>.
  • Page 123 Appendix D: The Adaptec HostRAID Setup Guidelines To format a disk: *Note: The operation of Formatting Disk allows you to perform a low-level formatting of a hard drive by writing zeros to the entire disk. Serial ATA drives are low-level formatted at the factory and do not need to be low-level formatted again.
  • Page 124 X7DB8/X7DBE User's Manual To verify disk media: 3 When the screen shown above displays, select Verify Disk Media and press <Enter>. 4 A message will display, indicating that the selected drive will be scanned for media defects. Select Yes and hit <Enter> to proceed with disk verifying; other- wise, select No and hit <Enter>.
  • Page 125 Appendix D: The Adaptec HostRAID Setup Guidelines To Exit Adaptec RAID Confi guration Utility 1. Once you have completed RAID array confi gurations, press ESC to exit. The following screen will appear. 2. Press Yes to exit the Utility. D-19...
  • Page 126 X7DB8/X7DBE User's Manual D-2 Installing Intel's ESB2 Driver by Adaptec and Installing the OS a. Insert Supermicro's bootable CD that came with the package into the CD Drive during the system reboot, and the screen: "Super Micro Driver Diskette Maker" will appear.

  • Page 127: Appendix E: Installing Other Software Programs And Drivers

    Appendix E: Installing Other Software Programs and Drivers Appendix E Installing Other Software Programs and Drivers A. Installing Drivers other than the Adaptec Embedded Serial ATA RAID Controller Driver After you've installed Windows Operating System, a screen as shown below will appear.
  • Page 128 X7DB8/X7DBE User's Manual B. Confi guring Supero Doctor III The Supero Doctor III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to moni- tor the environment and operations of your system.
  • Page 129 Appendix E: Installing Other Software Programs and Drivers Supero Doctor III Interface Display Screen-II (Remote Control) (*Note: SD III Software Revision 1.0 can be downloaded from our Web site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/Manuals/SDIII/UserGuide. pdf.
  • Page 130 X7DB8/X7DBE User's Manual Notes...

This manual is also suitable for:

Supero x7dbe

Table of Contents
