Summary of Contents for Rosewill RXS-3323
- Page 1 Wired Internet Camera RXS-3323 Wireless Internet Camera RXS-4324 User Manual...
-
Page 2: Fcc Rf Radiation Exposure Statement
Internet Camera RXS-3323/RXS-4324 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 3: Table Of Contents
Internet Camera RXS-3323/RXS-4324 Chapter 1. Product Overview...5 Package Contents ...5 System Requirements...6 Product Features...6 - Highlights ...7 Introduction of Hardware...9 - Front View...9 - Rear View...10 Chapter 2. Installation...11 Hardware Installation:... 11 - Ceiling Mount: ... 11 - Wall Mount:...12 Software Installation: ...12... - Page 4 Internet Camera RXS-3323/RXS-4324 - System ...40 System:...40 Date & Time:...41 Maintenance...42 - Video ...44 Common...44 Video Profile...44 ROI:...45 - Audio ...47 - User ...47 - E-Mail ...48 - Object Detection...49 - Event Server ...50 FTP Server ...50 TCP Server...50 HTTP Server ...51 SAMBA Server...52...
-
Page 5: Chapter 1. Product Overview
Internet Camera RXS-3323/RXS-4324 Chapter 1. Product Overview Package Contents Item 1. RXS-3323 or RXS-432 Camera 2. Manual and Software Package CD 3. Quick Installation Guide 4. Detachable Wireless LAN Antenna (optional, only comes with Wireless Camera) 5. RJ 45 Cable 6. -
Page 6: System Requirements
CPU: 1.3GHz or above processor Product Features RXS-3323/RXS-4324 is the Day/Night, Pan/Tilt Internet Camera with two-way Audio provides you with a 24 hours security. You will be able to see, hear, and talk to people in your camera’s viewing field via Internet connection. -
Page 7: Highlights
Internet Camera RXS-3323/RXS-4324 ensuring seamless protection. Optimal Viewing With the pan/tile functions, the camera can monitor everywhere from the left/right (0~355 degrees) or up/down (-10~90 degrees). In addition, there is 128 preset points and 16 camera tours can be assigning to move the camera lens to cover the desired area quickly. - Page 8 Internet Camera RXS-3323/RXS-4324 User Manual easily Covers wider area than Wide and fast Pan range: 355 degree and 180 degree/sec Wide and fast Tilt range: 100 degree and 120 degree/sec H.264, MPEG4 and JPEG triple compression simultaneously Mega-pixel resolution up to 1280x1024...
-
Page 9: Introduction Of Hardware
Internet Camera RXS-3323/RXS-4324 Introduction of Hardware - Front View IR LEDs: These LEDs are used for night vision during night or dark environment to provide extra light source for the camera. Lens and Focus Ring: User can use this ring to make minor focus adjustment. -
Page 10: Rear View
Internet Camera RXS-3323/RXS-4324 - Rear View Audio Output Jack: The Audio Output Jack allows the camera to output audio or alerting sound. Connect with a 3.5Ø phone jack speaker or headphone (speaker or headphone don’t come with camera) Power Jack:... -
Page 11: Chapter 2. Installation
Internet Camera RXS-3323/RXS-4324 Chapter 2. Installation Hardware Installation: - Camera LAN and Power Installation: Once you have installed the camera well and powered it on, the power LED will turn on. It means the system is booting up successfully. Furthermore, if you have a proper network connection, and access to the camera, the LED will flash blue under wired mode. -
Page 12: Wall Mount
Cameras by IPWizard or UPnP discovery. First is the guide to install the IPWizard II: - IPWizard II Installation: IPWizard II is a software designed to help you search and link to the Rosewill’s Camera which connects under your network. Fix the camera to L-type bracket... - Page 13 Internet Camera RXS-3323/RXS-4324 A browser should automatically open up with “Software Package” info. 3. Please click on “IPWizard” under “Software & Tools” to continue 4. Click on “Run” to continue. 5. You may be prompt to this window depending on your Internet Browser’s security level, please click “Run”...
- Page 14 Internet Camera RXS-3323/RXS-4324 6. Click on “Next” to continue 7. Click on “Finish” to finish the installation. 8. After installation, you should be able to see a new icon “IPWizard II” on your desktop User Manual...
-
Page 15: Chapter 3. Connecting To The Camera
Internet Camera RXS-3323/RXS-4324 Chapter 3. Connecting to the Camera Using IPWizard II: After the installation of the IPWizard II, double click on the icon, this window popup as the basic management of the IPWizard II. Once it popup, the wizard will perform an auto search to see if you have any camera in the Network. -
Page 16: Lan
Internet Camera RXS-3323/RXS-4324 (One click to view the select the device you want to view and click the View button. Then you video from the could see the video from camera directly. IPWizardII directly) 8. LAN In case you want to change the IP related parameters of wired interface, please select the device you want to configure and click the LAN button. -
Page 17: Wireless
Internet Camera RXS-3323/RXS-4324 User Manual If you do not want to change username and/or password, then just click “Submit” button to perform your setting accordingly. Click “ ” button will go back to previous page. If you like << to change username and/or password of the device, just click the check button. Then, you will be able to change the username and password as below. - Page 18 Internet Camera RXS-3323/RXS-4324 User Manual Click on the SSID to select your wireless AP or router. We use WEP as an example here. Enter your SSID’s WEP key, then click “>>” Double check your WLAN setting (Default using DHCP IP as your wireless router...
- Page 19 Internet Camera RXS-3323/RXS-4324 User Manual You should see the confirmation Status Window popup as below. Please select “OK” to confirm these settings. The IPWizard II will start to configure this camera with your updated information.
- Page 20 Internet Camera RXS-3323/RXS-4324 User Manual Once this step finished, IPWizard II will prompt you to unplug the Ethernet cable to activate wireless access. Then IPWizard II will prompt you to test wireless setting or finish wireless procedure as below.
-
Page 21: Managing The Camera
1. If your default Web Browser is Internet Explorer: Note: Rosewill’s Cameras can be supported by all other web browsers, however, there are certain features requires to be manage under Internet Explorer. Therefore, we recommed using Internet Explorer when managing the Camera for the first time. - Page 22 Internet Camera RXS-3323/RXS-4324 Make sure that the UPnP icons are not hidden. If they're hidden, from the Network Tasks pane in My Network Places, click Show icons for UPnP networked devices, and click Yes to open Windows Firewall. Windows XP will automatically make the needed configuration changes.
- Page 23 3. Type in the IP address provided by the IPWizard II into the Internet Explorer directly. Click on View Network Computers and devices Once opened, you should see the Rosewill Camera model under the Other Device. Please double click this to start the web browser for management.
-
Page 24: Entering Into Camera's Management Page Via Ie
Internet Camera RXS-3323/RXS-4324 - Entering into Camera’s Management page via IE 1. You may be asking to enter the username and password when entering into the web browser on the computer. 2. If you are prompt to ask entering the username and password. Please type in “admin”... - Page 25 Internet Camera RXS-3323/RXS-4324 User Manual You may also be ask to install the Rosewill Media Control to load the video properly. Please click on the highlighted bar and select “Install This Add-on for All User on This Computer” Upon selecting the “Install This Add-on for All User on This Computer”, you will see an Security Warning Window asking your...
-
Page 26: Management Page
When you first entering into the management page, you should see your IE as below: 1. Video Profile RXS-3323 and RXS-4323 provide 13 Video Profiles. The default Profile is H.264 / VGA (640 x 480). Please refer to Appendix for more detail comparison of the video profiles. -
Page 27: Full Screen
Internet Camera RXS-3323/RXS-4324 6. Advance PTZ This will opens up PTZ advance control. You can adjust the speed, add preset points, or Camera tours, and etc. 7. Digital Zoom User can drag or scale the box over the video to adjust zoom ratio and position. -
Page 28: Chapter 4. Managing The Device
Use this menu to configure the network to connect the device and the clients. The Wireless function only supports RXS-4324, the wireless version of Rosewill’s Network Camera. You will not see this function in RXS-3323. Network: This section provides the menu for connecting the device through Ethernet cable. -
Page 29: Mac Address
Internet Camera RXS-3323/RXS-4324 1. MAC address: Displays the Ethernet MAC address of the device. Note that user can not change it. 2. Obtain IP address DHCP: Dynamic Host Configuration Protocol. automatically (DHCP): Enable this checked box when a DHCP server is installed on the network to issue IP address assignment. -
Page 30: Wireless
WAN, then the HTTP Port can be assigned as the virtual server port mapping to support multiple devices Wireless: This function only supports RXS-4324, the wireless version of Rosewill’s Network Camera. You will not see this function in RXS-3323. 1. Setting (Easy... - Page 31 Internet Camera RXS-3323/RXS-4324 6. SSID: This is the name of the wireless network the device is configured for. The field accepts up to 32 alphanumeric characters. The name must be exactly the same as that used in the wireless access point, or the connection will not be established.
- Page 32 Internet Camera RXS-3323/RXS-4324 DDNS: DDNS: Stands for Dynamic Domain Name Server Your Internet Service Provider (ISP) provides you at least one IP address which you use to connect to the Internet. The address you get may be static, meaning it never changes, or dynamic, meaning it’s likely to change periodically.
-
Page 33: Pppoe
Internet Camera RXS-3323/RXS-4324 PPPoE: PPPoE: Stands for Point to Point Protocol over Ethernet A standard builds on Ethernet and Point-to-Point network protocol. It allows your device with xDSL or cable connects with broadband network directly, then your device can dial up and get a dynamic IP address. - Page 34 Internet Camera RXS-3323/RXS-4324 1. RTSP Port: Choose the RTSP port. The RTSP protocol allows a connecting client to start a video stream. Enter the RTSP port number to use. The default value is 554. 2. RTP Port: Specify the range of transmission port number of video stream. The default range is 50000 to 50999.
-
Page 35: Friendly Name
Internet Camera RXS-3323/RXS-4324 1. UPnP: To enable or disable the UPnP service here. 2. Friendly Name: Shows the friendly name of this device here. 3. UPnP NAT When enabled, the device will attempt to configure port mapping in a NAT router on Traversal: your network, using UPnP™. -
Page 36: Ip Notification
Internet Camera RXS-3323/RXS-4324 IP Notification: In case the IP address is changed, system is able to send out an email to alert someone if the function is enabled. 1. SMTP Notification If enable this function, then the “Send to“ and “Subject” fields need to be filled. You (e-mail): will also need to set the “E-Mail“... -
Page 37: Camera
Internet Camera RXS-3323/RXS-4324 4. TCP Notification: If enable this function, then the “TCP Server“, “TCP Port”, and “Message” fields need to be filled. 5. TCP Server: Type the server name or the IP address of the TCP server. 6. TCP Port: Set port number of TCP server. -
Page 38: Exposure Control
Internet Camera RXS-3323/RXS-4324 2. White Balance: Auto: will adjust the white balance automatically. Hold: will hold the white balance. 3. Exposure Control: Auto: will adjust the internal gain automatically. Hold: will hold the internal gain. 4. Color Level: Larger value will increase the colorfulness of the video. -
Page 39: Preset Setting
Internet Camera RXS-3323/RXS-4324 reference to set LED ON/OFF Threshold. 10. De-Noise: De-Noise can remove or lower unwanted noise and preserve fine details and edges. Preset Setting: This page provides the edit tool to modify or delete the Preset points where you set under Advanced PTZ. -
Page 40: System
Internet Camera RXS-3323/RXS-4324 1. Tour Name: The group name of the sequence of camera tour. The maximum number of camera tour is 2. Running: Enable or disable this camera tour. 3. Preset: Set the sequence of the tour. Maximum 16 points can be assigned. The selected preset position is added in the Sequence list from 1 to 16. -
Page 41: Date & Time
Internet Camera RXS-3323/RXS-4324 3. Device Title: You can enter the name of this unit here. It’s very useful to identify the specific device from multiple units. The information will be shown on IPWizard II once the device is found. 4. Software Version: This information shows the software version of the device. -
Page 42: Daylight Saving
Internet Camera RXS-3323/RXS-4324 4. NTP Server: Type the host name or IP address or domain name of the NTP server. 5. NTP Sync. Interval: Select an interval between 1 and 23 hours at which you want to adjust the device’s time referring to NTP server 6. -
Page 43: Firmware Upgrade Procedure
Internet Camera RXS-3323/RXS-4324 5. Firmware Upgrade The device supports new firmware upgrade (the software that controls the operation in procedure: the device). Please contact your dealer for the latest version if necessary. Download the latest firmware file from our website or your dealer. Unzip this firmware file to binary file and store it into your PC. -
Page 44: Video
Internet Camera RXS-3323/RXS-4324 - Video This device provides 2 modes of video profile. The first one is Mega-pixel mode which supports video resolution up to Mega-pixel. However the maximum frame rate of this mode is up to 15fps only. The second one is VGA mode which supports video resolution up to VGA but frame rate can be up to 30fps. -
Page 45: Roi
Internet Camera RXS-3323/RXS-4324 fps, then the image will be updated for 15 frames per second as possible. User need to set reasonable max frame rate versus video quality under the limited bandwidth. 4. GOP Control: This defines the Intra/Inter-frame (I/P) ratio of this profile. For example, set the GOP to 30, then the video stream will have one Intra-frame every 30 frames. - Page 46 Internet Camera RXS-3323/RXS-4324 User Manual Once set ROI, you can select ROI in the Video Profile; you can then see the focus image of the ROI area: ROI 0: The area size of ROI 0 is H.264 / VGA, 640 x 480.
-
Page 47: Audio
Internet Camera RXS-3323/RXS-4324 - Audio 1. Audio: To enable or disable audio function 2. Audio Mode: To select Simplex or Full duplex (2-way audio) mode 3. Input Gain: To adjust gain of input audio 4. Output Gain: To adjust gain of output audio... -
Page 48: E-Mail
Internet Camera RXS-3323/RXS-4324 3. Add, update, and Manage the user’s account of viewer user. remove of Users account: - E-Mail You may setup SMTP mail parameters for further operation of Event Schedule. That’s, if users want to send the alarm message out, it will need to configure parameters here and also add at least one event schedule to enable event triggering. -
Page 49: E-Mail Subject
Internet Camera RXS-3323/RXS-4324 Authentication: 5. Authentication User Type the user name for the SMTP server if Authentication is Enable. name: 6. Authentication Type the password for the SMTP server if Authentication is Enable. Password: 7. E-mail To: Type the receiver’s e-mail address. -
Page 50: Event Server
Internet Camera RXS-3323/RXS-4324 objects trigger motion detection. The lower object size will even small objects trigger motion detection too. Generally speaking, the smaller size will be easier to trigger event. 5. Sensitivity: Defines the sensitivity value of motion detection. The higher value will be more sensitivity. -
Page 51: Http Server
Internet Camera RXS-3323/RXS-4324 1. Name: User can specify multiple TCP servers as wish. Therefore, user needs to specify a name for each TCP server setting. 2. TCP Server: Type the server name or the IP address of the TCP server. -
Page 52: Samba Server
Internet Camera RXS-3323/RXS-4324 for each HTTP server setting. 2. URL: Type the server name or the IP address of the HTTP server. 3. Test: Check the HTTP server whether it is available or not. 4. HTTP Login name: Type the user name for the HTTP server. -
Page 53: Event Schedule
Internet Camera RXS-3323/RXS-4324 Password: 6. SAMBA Path: Set working directory path of SAMBA server. - Event Schedule Setting This menu is used to specify the schedule of Event or Schedule Trigger and activate the some actions provided by this device. Where the Schedule Trigger will be activated by user-define interval without event happened. -
Page 54: Record
Internet Camera RXS-3323/RXS-4324 Example 2: Send file to E-Mail server by motion triggered from Friday 18:00 to Saturday 06:00 1. Select event trigger. 2. Enable time: start from Friday 18:00 and keep work in 12 hous, so it will stop on Saturday 06:00. -
Page 55: Advance Ptz
Internet Camera RXS-3323/RXS-4324 Advance PTZ Advance PTZ allows you to set the Camera movement and speed. You can also set Preset points and enable Tour (combine by different Preset Points) here. - Adding Preset point: 1. When selecting “Add”, you may see a scripted enable bar appear; depending on the security level set on your Web browser. - Page 56 Internet Camera RXS-3323/RXS-4324 2. Please right click on it and select “Temporarily Allow Scripted Windows” 3. Click the arrow until your desired area appear, then click “Add”. You will be asking to enter the name of the Preset point you want to call. Please enter your desired name, and then click “OK”.
-
Page 57: Selecting Tour
Internet Camera RXS-3323/RXS-4324 User Manual 4. Whenever you move your camera to, you can always return to your Preset point by selecting it and then click “Go”. - Selecting Tour: 1. You will need to set Tour under Setting -> Camera -> Tour Setting. -
Page 58: Record
Internet Camera RXS-3323/RXS-4324 User Manual selecting Browse, the pop-up window allows you to select the save path and file name, select OK to continue. If you like to retrieve the saved image, select the file to display the saved image by using any one of graph editing tools. -
Page 59: Appendix A: Restore Factory Default Settings
Internet Camera RXS-3323/RXS-4324 User Manual Appendix A: Restore Factory Default Settings There is a button hidden in the pinhole near to the RJ-45 connector. This button is used to restore the all factory default settings. Sometimes restarting the device will make the system back to a normal state. -
Page 60: Appendix B: Troubleshooting & Faq
Internet Camera RXS-3323/RXS-4324 Appendix B: Troubleshooting & FAQ Question The video and audio The device utilizes H.264, MPEG4 and JPEG triple compression to providing high codec is adopted in the quality images. Where H.264 and MPEG4 are standards for video compression and device. - Page 61 Internet Camera RXS-3323/RXS-4324 the device. IPWizard II program • Re-power the device if cannot find the unit within 1 minutes. cannot find the device. • Do not connect device over a router. IPWizard II program cannot detect device over a router.
- Page 62 Internet Camera RXS-3323/RXS-4324 Network Camera’s private IP address. • The port number assigned in your Network Camera might not be available via Internet. Check your ISP for available port. • The proxy server may prevent you from connecting directly to the Network Camera, set up not to use the proxy server.
- Page 63 Internet Camera RXS-3323/RXS-4324 changed in order for the device to be accessible outside your LAN. • Make sure that the device isn’t conflicting with any other web server running on your LAN. • Check the configuration of the router settings allow the device to be accessed outside your local LAN.
- Page 64 Internet Camera RXS-3323/RXS-4324 •The configuration on the device image display is incorrect. You need to adjust the image related parameters such as brightness, contrast, hue and sharpness properly. Image flickers. • Wrong power line frequency makes images flicker. Make sure the 50 or 60Hz format of your device.
-
Page 65: Appendix C: Ping Ip Address
Internet Camera RXS-3323/RXS-4324 Appendix C: Ping IP Address The PING (stands for Packet Internet Groper) command is used to detect whether a specific IP address is accessible by sending a packet to the specific address and waiting for a reply. It’s also a very useful tool to confirm the device installed or if the IP address conflicts with any other devices over the network. -
Page 66: Appendix D: Bandwidth Estimation
Internet Camera RXS-3323/RXS-4324 Appendix D: Bandwidth Estimation The frame rate of video transmitted from the device depends on connection bandwidth between client and server, video resolution, codec type, and quality setting of server. Here is a guideline to help you roughly estimate the bandwidth requirements form your device. -
Page 67: Appendix E: Specifications
Internet Camera RXS-3323/RXS-4324 Appendix E: Specifications Camera Specifications Camera Image Device 1.3 Mega-pixel image sensor Max Resolution 1280 x 1024 pixels Lens f:4.3mm / F:1.8 Sensitivity 1.0V/lux-sec (550nm) Video / Image / Audio H.264, MPEG4 and Motion JPEG simultaneously Video Format... - Page 68 128 preset points Camera Tour 16 tours Communication Network LAN: 10/100Mbps Auto-MDIX (RXS-3323) Wireless LAN: B/G/N (RXS-4324) Connection Protocol TCP, UDP, HTTP, SMTP, FTP, NTP, DNS, DDNS, DHCP, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, PPPoE, 3GPP, ICMP, Samba System Requirement (via Web Configuration)
-
Page 69: Appendix F: Configure Port Forwarding Manually
Internet Camera RXS-3323/RXS-4324 Appendix F: Configure Port Forwarding Manually If you want to access the Camera over the internet, you will need to use it together with a router / wireless router. The Camera’s IP address needs to be setup as fixed IP address. You will also need to set up the port forwarding or Virtual Server function of router. - Page 70 Internet Camera RXS-3323/RXS-4324 Your WAN IP will be listed here Note: Because a dynamic WAN IP can change from time to time depending on your ISP, you may want to obtain a Static IP address from your ISP. A Static IP address is a fixed IP address that will not change over time and will be more convenient for you to use to access your camera from a remote location.
- Page 71 Internet Camera RXS-3323/RXS-4324 Port section, click Apply. Scheduling should be set to Always so that the camera images can be accessed at any time. A check mark appearing before the entry name will indicate that the ports are enabled. Important: Some ISPs block access to port 80. Be sure to check with your ISP so that you can open the appropriate ports accordingly.
-
Page 72: Appendix G: Ddns Configuration
Internet Camera RXS-3323/RXS-4324 Appendix G: DDNS Configuration If you have a Cable modem or xDSL, this is a great way to host your own Networked Device or other TCP/IP Service. Get your own domain like www.yourname.com, www.yourname.org etc. Your domain name's dynamic IP address is automatically tracked by a DDNS server. - Page 73 Internet Camera RXS-3323/RXS-4324 (3). After the columns show up at the left side, click (4). Fill the application agreement and necessary information. a. Username b. E-mail address and confirmation c. Password and confirmation d. Submit all the input information and finish creating an account “Create Account”.
- Page 74 Internet Camera RXS-3323/RXS-4324 User Manual (5). Check your e-mail mailbox. There will be an e-mail with a title “Your DynDNS Account Information“. Click the hyperlink address to confirm the DDNS service that you just applied. Then DDNS you applied activated.
- Page 75 Internet Camera RXS-3323/RXS-4324 User Manual (6). Enter the web page http://www.dyndns.org/ again. Input your username and password that you just applied to login administration interface of DDNS server. (7). If the correct username and password are input, you can see the following picture at the top-right of the login page.
- Page 76 Internet Camera RXS-3323/RXS-4324 (10). Click the “Get Started”. (11). We could create a domain name without any charge at this step. First, we input the host name. (Pink No.1) Then we pick a domain that is easy to remember. (Pink No.2) The 3 is to click “Offline Hostname”...
-
Page 77: Appendix H: 3Gpp And Iphone
For iPhone, please enter the IP address or the DDNS website address into Safari to start viewing. Thank you for purchasing a quality Rosewill Product. Please register your product at: www.rosewill.com for complete warranty information and future support for your product. User Manual...
