- Page 1 Wired Internet Camera RXS-3211 Quick Installation Guide...
-
Page 2: Knowing Your Ip Camera
Wall Mount Stand Wall Anchors Screws 39.3in (100cm) Category 5 Ethernet Cable Quick Installation Guide CD (Including User Manual/Utility/Driver) If any of the above items are missing, please contact Rosewill Support. RXS-3211 Figure 1.1-1 Quick Installation Guide Quantity □ □... -
Page 3: Camera Front And Rear View
Wired Internet Camera RXS-3211 Quick Installation Guide Camera Front and Rear View Power LED Camera status Lens LAN LED Figure 1.4-1 Front View Power LED: Indicates power and WPS status LAN LED: Indicates LAN activity Camera: Video camera with lens LED activity for LAN / Power LED will be given later. -
Page 4: Led Activities Description
Wired Internet Camera RXS-3211 Stand Connector: Connects to any standard tripod / camera wall holder. WPS / Reset Button: Press and release this button to activate WPS mode (WPS mode is not available in Wired Camera); press and hold this button for 10 seconds to clear all settings of this camera and return to factory default. - Page 5 Wired Internet Camera RXS-3211 3. Plug the power adapter to wall socket, and connect the power connector to the power jack located at the back of the IP camera. 4. Connect your stand to the connector or place the camera in a secure place, and point the camera to the place you wish to monitor.
-
Page 6: Camera Software Installation
Wired Internet Camera RXS-3211 Camera Software Installation Follow the simple steps below to run the Install Wizard to guide you quickly through the Installation process. The following installation is implemented in Windows XP. The installation procedures in Windows 2000/XP/Server 2003/Vista/Win7 are similar. - Page 7 Wired Internet Camera RXS-3211 3. First click “Install Administrator Utility“ and when the following window appears, click “Next”. 4. You can specify the destination folder of software installation; you can just use the default folder, and click “Next” to continue.
- Page 8 Wired Internet Camera RXS-3211 5. If you need installation program to create a desktop icon or a quick launch icon for you, click all items you need here, and click “Next” to continue. 6. Here lists all options you chose in previous steps, if everything is correct, click “Install”...
- Page 9 Wired Internet Camera RXS-3211 previous step to modify installing settings. 7. The installing procedure will take some time, please be patient. 8. When you see this window, it means the software installing procedure is complete. Please click “Finish” to finish the procedure (IP camera Quick Installation Guide Figure 1.7-5...
- Page 10 Wired Internet Camera RXS-3211 surveillance software will start after you click “Finish” button, if you want to start it later, uncheck “Launch IP Cam Surveillance Software” box). 9. After finished the installation of Administrator Utility, please go back to wizard page and click “Install Surveillance Software“, the system will start running viewer installation and the procedures are similar to the installation of administration utility.
- Page 11 Administrator Utility Surveillance Software (16 Channels Camera Viewer) You have completed the installation process for RXS-3211’s software. Please follow the user manual: Chapter 2 lists the details of how to connect your IP Camera with your computer or router Chapter 3 lists the details of Camera’s Web Management via IE...
