- Page 1 Wired Internet Camera RXS-3323 Wireless Internet Camera RXS-4324 Quick Installation Guide...
-
Page 2: Product Overview
Internet Camera RXS-3323/RXS-4324 Product Overview Package Contents Item 1. RXS-3323 or RXS-432 Camera 2. Manual and Software Package CD 3. Quick Installation Guide 4. Detachable Wireless LAN Antenna (optional, only comes with Wireless Camera) 5. RJ 45 Cable 6. 12V/1A Power Adapter 7. -
Page 3: System Requirements
Internet Camera RXS-3323/RXS-4324 System Requirements Windows 2000, XP, Vista, or Windows 7. At least 256 MB of memory (512MB recommended) A wireless (802.11n or 802.11g) or Ethernet network. Internet Explorer 6.x or higher, Firefox 2.0 or later/ Safari Internet Web Browser VGA card resolution: 800 x 600 or above CPU: 1.3GHz or above processor Introduction of Hardware... -
Page 4: Rear View
Internet Camera RXS-3323/RXS-4324 - Rear View Audio Output Jack: The Audio Output Jack allows the camera to output audio or alerting sound. Connect with a 3.5Ø phone jack speaker or headphone (speaker or headphone don’t come with camera) Power Jack: The input power is 12VDC which is provided by the power adapter included in package Note: Improper power adapter may damage the camera and result in... -
Page 5: Ceiling Mount
Internet Camera RXS-3323/RXS-4324 Installation Hardware Installation: - Camera LAN and Power Installation: Once you have installed the camera well and powered it on, the power LED will turn on. It means the system is booting up successfully. Furthermore, if you have a proper network connection, and access to the camera, the LED will flash blue under wired mode. -
Page 6: Wall Mount
Cameras by IPWizard or UPnP discovery. First is the guide to install the IPWizard II: - IPWizard II Installation: IPWizard II is a software designed to help you search and link to the Rosewill’s Camera which connects under your network. Quick Installation Guide... - Page 7 Internet Camera RXS-3323/RXS-4324 Quick Installation Guide A browser should automatically open up with “Software Package” info. 3. Please click on “IPWizard” under “Software & Tools” to continue 4. Click on “Run” to continue. 5. You may be prompt to this window depending on your Internet Browser’s security level, please click “Run”...
- Page 8 Internet Camera RXS-3323/RXS-4324 Quick Installation Guide 6. Click on “Next” to continue 7. Click on “Finish” to finish the installation. 8. After installation, you should be able to see a new icon “IPWizard II” on your desktop...
- Page 9 Internet Camera RXS-3323/RXS-4324 Connecting to the Camera Using IPWizard II: After the installation of the IPWizard II, double click on the icon, this window popup as the basic management of the IPWizard II. Once it popup, the wizard will perform an auto search to see if you have any camera in the Network. The window below is an example of what this may look like: 1.
- Page 10 Internet Camera RXS-3323/RXS-4324 7. View If IPWizard II finds network devices, View button will be available. Please (One click to view the select the device you want to view and click the View button. Then you video from the could see the video from camera directly. IPWizardII directly) 8.
- Page 11 Internet Camera RXS-3323/RXS-4324 Quick Installation Guide If you do not want to change username and/or password, then just click “Submit” button to perform your setting accordingly. Click “ ” button will go back to previous page. If you like << to change username and/or password of the device, just click the check button.
- Page 12 Internet Camera RXS-3323/RXS-4324 Quick Installation Guide Click on the SSID to select your wireless AP or router. We use WEP as an example here. Enter your SSID’s WEP key, then click “>>” Double check your WLAN setting (Default using DHCP IP as your wireless router provides IP address for the Camera) then click “Submit”.
- Page 13 Internet Camera RXS-3323/RXS-4324 Quick Installation Guide You should see the confirmation Status Window popup as below. Please select “OK” to confirm these settings. The IPWizard II will start to configure this camera with your updated information.
- Page 14 Then IPWizard II will prompt you to test wireless setting or finish wireless procedure as below. Thank you for purchasing a quality Rosewill Product. Please register your product at: www.rosewill.com for complete warranty information and future support for your product.
