Rosewill WIRED INTERNET CAMERA RXS-3211 User Manual

Rosewill WIRED INTERNET CAMERA RXS-3211 User Manual

Wired internet camera
Hide thumbs Also See for WIRED INTERNET CAMERA RXS-3211:
Table of Contents

Advertisement

Quick Links

Download this manual
Wired Internet Camera
RXS-3211
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WIRED INTERNET CAMERA RXS-3211 and is the answer not in the manual?

Questions and answers

Related Manuals for Rosewill WIRED INTERNET CAMERA RXS-3211

Summary of Contents for Rosewill WIRED INTERNET CAMERA RXS-3211

  • Page 1 Wired Internet Camera RXS-3211 User Manual...

  • Page 2: Table Of Contents

    Wired Internet Camera RXS-3211 Chapter 1 Knowing your IP Camera...3 1.1 Check your package...3 1.2 Basic Information...4 1.3 Product Highlights ...4 1.4 Camera Front and Rear View...5 1.5 LED Activities Description...6 1.6 Camera Hardware Installation ...7 1.7 Camera Software Installation...8 Chapter 2 Connecting your IP Camera ...14 2.1 Camera Installation ...14 2.1.1 IP Camera connects with Computer...14...
  • Page 3 Wired Internet Camera RXS-3211 3.10 Log ...48 Chapter 4 Using Surveillance Software...50 4.1 Installing Surveillance Software ...50 4.2 Using Surveillance Software...53 4.3 Configure Surveillance Software...56 4.3.1 Configure cameras ...56 4.3.2 General Options ...62 4.4 Change Display Layout...65 4.5 Full-Screen Mode...67 4.6 Scan...67 4.7 Zoom-in / Zoom-Out...68 4.8 Snapshot...69...

  • Page 4: Wall Anchors

    Camera Stand accessory kit Wall Mount Stand Wall Anchors Screws 39.3in (100cm) Category 5 Ethernet Cable Quick Installation Guide CD (Including User Manual/Utility/Driver) If any of the above items are missing, please contact Rosewill Support. RXS-3211 Figure 1.1-1 User Manual Quantity □ □...

  • Page 5: Basic Information

    Wired Internet Camera RXS-3211 1.2 Basic Information Thank you for purchasing this Internet IP camera! This IP camera is an ideal product for all kinds of video-surveillance purposes, like home/office safety, kid/pet monitoring, and remote video acquire etc. Unlike conventional close-circuit video camera, you’re not limited to the length of cable! Once this IP camera is connected to Internet, you can check video from anywhere in the world where Internet access is available.

  • Page 6: Camera Front And Rear View

    Wired Internet Camera RXS-3211  Configurable motion detection sensitivity (6 levels from most sensitive to least sensitive) with three adjustable areas support.  Built-in real-time clock, date and time information will be recorded with every captured picture / video clip (also supports auto time synchronization via network time protocol).

  • Page 7: Led Activities Description

    Wired Internet Camera RXS-3211 Stand Connector Reset to Default Stand Connector: Connects to any standard tripod / camera wall holder. WPS / Reset Button: Press and release this button to activate WPS mode (WPS mode is not available in Wired Camera); press and hold this button for 10 seconds to clear all settings of this camera and return to factory default.

  • Page 8: Camera Hardware Installation

    Wired Internet Camera RXS-3211 1.6 Camera Hardware Installation Please follow the following instructions to set your IP camera up. 1. Unpack the product package and check if anything missing. 2. Insert supplied LAN cable to “LAN” jack. You can choose to plug the other end onto one of the following: your computer, and your wired or wireless router.

  • Page 9: Camera Software Installation

    Wired Internet Camera RXS-3211 4. Connect your stand to the connector or place the camera in a secure place, and point the camera to the place you wish to monitor. 1.7 Camera Software Installation Follow the simple steps below to run the Install Wizard to guide you quickly through the Installation process.
  • Page 10 Wired Internet Camera RXS-3211 16 Chan Camera Viewer“. “Install the Administrator Utility” provides the driver and Admin Utility . Administrator Utility helps your computer to search, configure, and view the camera through IE browser. 3. First click “Install Administrator Utility“ and when the following window appears, click “Next”.
  • Page 11 Wired Internet Camera RXS-3211 4. You can specify the destination folder of software installation; you can just use the default folder, and click “Next” to continue. 5. If you need installation program to create a desktop icon or a quick launch icon for you, click all items you need here, and click “Next”...
  • Page 12 Wired Internet Camera RXS-3211 6. Here lists all options you chose in previous steps, if everything is correct, click “Install” to start installing procedure, or click “Back” to go back to previous step to modify installing settings. 7. The installing procedure will take some time, please be patient. Figure 1.7-5 Figure 1.7-6 User Manual...
  • Page 13 Wired Internet Camera RXS-3211 8. When you see this window, it means the software installing procedure is complete. Please click “Finish” to finish the procedure (IP camera surveillance software will start after you click “Finish” button, if you want to start it later, uncheck “Launch IP Cam Surveillance Software”...
  • Page 14 Wired Internet Camera RXS-3211 10. When the “Administrator Utility” and “Surveillance Software” installed completely. You should see both Icons on your desktop.  Administrator Utility  Surveillance Software (16 Channels Camera Viewer) You have completed the installation process for RXS-3211’s software. Please follow Chapter 2 for details on Connecting your IP Camera with your computer or router.

  • Page 15: Chapter 2 Connecting Your Ip Camera

    Wired Internet Camera Chapter 2 Connecting your IP Camera There are two ways to connect up the RXS-3211 IP camera:  Connect directly to your computer through LAN port  Connect directly to your router or wireless router Connecting Device Time to Install Setup Process 2.1 Camera Installation...
  • Page 16 Wired Internet Camera RXS-3211 3. This window Connection as “Limited or no connectivity”. This is because IP camera cannot assign IP to your computer. Therefore, you will need to manually assign your computer’s IP to connect to the IP Camera. 2.1.1.1 Manually Assign IP for Camera 1.
  • Page 17 Wired Internet Camera RXS-3211 User Manual Figure 2.1.1-4 3. Right-click “Local Area Connection”, and click “Properties” Figure 2.1.1-5...
  • Page 18 Wired Internet Camera RXS-3211 4. Select “Internet Protocol (TCP/IP)”, then click “Properties”. 5. In “IP address” field, please fill in any IP address begins with “192.168.2”, and ends with a value greater than 2 and less than 254 (You can use the example in the picture “192.168.2.239”).
  • Page 19 Wired Internet Camera RXS-3211 6. Open your Internet Explorer and type “http://192.168.2.3” in the address tab. 7. You should see a login window popup. The default login name and password is “Admin” and “1234”. (You should change the Login name and password after your first login.) Click “OK”...
  • Page 20 Wired Internet Camera RXS-3211 2.1.1.2 Install Active X for Camera 1. After logged on, you should see the following messages at the top of Internet Explorer. This will install Active X into your computer. This IP camera requires a special ActiveX control (A.K.A. ‘Plugin’) to work. Please click on the message, and select ‘Install ActiveX Control…’: 2.

  • Page 21: Ip Camera Connects With Router/Wireless Router

    Wired Internet Camera RXS-3211 2.1.2 IP Camera connects with Router/Wireless Router You can also connect the camera through your current router/wireless router. 1. Simply plug your camera onto the current working rouer/wireless router like figure 2.1.2-1. 2. After connect, please run the “Administrator Utility” program to search the camera’s IP address.
  • Page 22 Wired Internet Camera RXS-3211 “192.168.2.3” as figure 2.1.2-2. If not, please click “1. Search Camera”, and you should be able to see the IP address of Camera. 3. Once your camera has the IP address, you can continue to view the camera by click on the info bar at “2.”.
  • Page 23 Wired Internet Camera RXS-3211 operate and manage your camera. Please enter the User name and Password. (Default User name and Password is Admin and 1234) You should see the image from camera now. You have entered the Camera’s management page! Figure 2.1.2-4 Figure 2.1.2-5 User Manual...

  • Page 24: Chapter 3 Camera's Management Interface

    Wired Internet Camera RXS-3211 User Manual Chapter 3 Camera’s Management Interface 3.1 Camera Settings The default page after you logged onto web management interface is “Camera”, and this is the page where you can see the real-time image from camera. Figure 3.1-1 You can always come back to this menu by clicking “Camera”...
  • Page 25 Wired Internet Camera RXS-3211 Item Video Format Specifies video encoding format. You can choose MPEG4 or MJPEG (Motion-JPEG). MPEG4 mode also supports motion detection (see chapter OOXX). Snapshot Take a snapshot picture and save the picture to your computer’s hard drive.

  • Page 26: Lan Settings

    Wired Internet Camera RXS-3211 Check ‘Enable’ box to enable digital zoom, and you can set the percentage of zoom from 100% (no magnification) to 400%. You can also drag the green square by mouse and put it on the area you wish captured image to be magnified.

  • Page 27: Lan

    Wired Internet Camera RXS-3211 User Manual 3.2.1 LAN You can define IP address and select the port number you wish to use here.
  • Page 28 Wired Internet Camera RXS-3211 Item Network Type This camera can obtain the IP address from DHCP server automatically (if you have one), or set a fixed IP address. Select “DHCP” to obtain IP address automatically or “Static IP Address” to assign this IP camera with a fixed IP address.

  • Page 29: Rtsp

    Wired Internet Camera RXS-3211 HTTP Port Specify the port number of web management interface here. If it’s not 80, you’ll have to add: ”port” after the IP address / hostname of this IP camera. For example, if the HTTP port number you specified here is 90 and the IP address of IP camera is 10.20.20.30, then you have to input “http://10.20.20.30:90”...

  • Page 30: Dynamic Dns

    Wired Internet Camera RXS-3211 3.2.3 Dynamic DNS If your ISP does not give you a fixed Internet IP address (i.e. the Internet address you’re using when you access the Internet is not always the same – ask your ISP for detailed information), you can use this function to help you locate the IP address of this IP camera when you’re away from home or office.
  • Page 31 Wired Internet Camera RXS-3211 This function is useful and you don’t have to remember the IP address of this IP camera. Simply open “Network neighbor”! Item Enable UPnP Select “Enable” to activate UPnP function of this IP camera, select “Disable” to disable it. Click “Apply”...

  • Page 32: Loginfree

    Wired Internet Camera RXS-3211 3.2.5 LoginFree This function is for user to specify a filename here so everyone who knows this filename can gain access to the picture captured by the IP camera with this name with .jpg file extension. For example, if the filename you specified here is “temp”...

  • Page 33: Dual Mode

    Wired Internet Camera RXS-3211 3.3.1 Dual Mode IP camera supports two video encoding formats: MPEG4 and MJPEG. You can select the encoding format from one of them. Item Default Video Specify default video encoding format of this IP camera Format here.

  • Page 34: Mjpeg

    Wired Internet Camera RXS-3211 Item Video Specify video resolution of MPEG4 video encoder. Available Resolution options are VGA and QVGA resolution. VGA resolution provides more details than QVGA, but requires more network bandwidth. Video Quality Specify video quality. There are two video quality types: CBR (Constant Bit Rate), and VBR (Variable Bit Rate);...

  • Page 35: E-Mail/Ftp Settings

    Wired Internet Camera RXS-3211 Item Video Specify video resolution of MJPEG video encoder. Available Resolution options are VGA, QVGA, and QQVGA resolution. VGA resolution provides more details than QVGA and QQVGA, but requires more network bandwidth. Video Quality Specify video encoding quality of MJPEG video encoder. There are five levels of video quality from highest to lowest.

  • Page 36: E-Mail (With Gmail And Hotmail Setup Examples)

    Wired Internet Camera RXS-3211 3.4.1 E-Mail (with Gmail and hotmail setup examples) These settings are used to send the captured picture via Email: Item Recipient Input the email recipient’s Email address here. If you have E-Mail more than one Email recipient, please use a “;” Address (semicolon) mark between every Email address.
  • Page 37 Wired Internet Camera RXS-3211 Example of hotmail setup: xxxxx@hotmail.com SMTP Server Input the IP address or host name of the SMTP server (the server that delivers the Email for you) here. If you don’t know, please refer to the SMTP server you’re using in your Email software (like Outlook, Outlook Express etc.), or ask your network administrator or ISP.
  • Page 38 Wired Internet Camera RXS-3211 ‘Disable’ to disable it. If you don’t know, please refer to the SMTP server you’re using in your Email software (like Outlook, Outlook Express etc.), or ask your network administrator or ISP. Example of Gmail setup: Enable Example of hotmail setup: Enable User Name Please input the user name of SMTP server here, if your...

  • Page 39: Ftp Configuration

    Wired Internet Camera RXS-3211 3.4.2 FTP Configuration Item FTP Server Input the IP address or host name of the FTP server you wish to use here. FTP Port Input the port number of the FTP server you wish to use here.

  • Page 40: Motion Detection Settings

    Wired Internet Camera RXS-3211 3.5 Motion Detection Settings There are two sections of the Motion Detection: Basic Setting and Region Setting. 3.5.1 Motion Detection Basic Setting Motion detection function makes this IP camera become your non-stop guard. You don’t have to waste all the time monitoring the images from the camera, and camera will detect all motions for you.

  • Page 41: Motion Detection Region Setting

    Wired Internet Camera RXS-3211 E-Mail Subject Set the subject of Email being sent here. This will help you to distinguish the Email sent by this IP camera from others. Send snapshot file to Select “Yes” to send a picture to the FTP server you specified in “E-Mail &...

  • Page 42: Schedule Settings

    Wired Internet Camera RXS-3211 Motion detection region settings can be found at the bottom of this page: Item Region1 / Check the box to enable / disable a certain motion Region2 / detection area. Region3 Sensitivity Control the detection sensitivity of motion detection of respective motion detection region.

  • Page 43: System Settings

    Wired Internet Camera RXS-3211 Item Enable FTP You can select whether to “Enable” or “Disable” Schedule sending files to FTP server Time Interval Once you enable the FTP schedule, you can select how often to upload the image file to the server by per frame time or per second frame.

  • Page 44: Camera Information

    Wired Internet Camera RXS-3211 3.7.1 Camera Information Camera information allows you to set the name and administrator’s password of this camera. Item Camera Name Please specify the name of this IP Camera here. This can be used to identify your camera on the network when you have more than one IP camera in the same network.

  • Page 45: Date / Time Setting

    Wired Internet Camera RXS-3211 Confirm Password Please input the same password again, to make sure there’s no typo. Click “Apply” to save settings and make the new settings take effect. 3.7.2 Date / Time Setting This setting allows you to change the date and time of the real time clock in this IP camera.
  • Page 46 Wired Internet Camera RXS-3211 time setting. Click “Apply” to save settings and make the new settings take effect. 3.7.3 Utilities This menu allows you to upgrade firmware, clear all settings, reboot the camera, and switch LED lights on/off. Item Upgrade If you downloaded latest firmware file from our Firmware website, you can click “Browse”...

  • Page 47: Status

    Wired Internet Camera RXS-3211 in case you don’t want other people know the camera is transferring data. You can click this button again to switch LED lights on again. 3.8 Status This menu provides all information about this IP camera, like firmware version, system uptime, date / time, and network information.
  • Page 48 Wired Internet Camera RXS-3211 not change any system setting. When they want to click menus other than “Camera”, they will see the following message informing that they don’t have permission to do that: This IP camera supports setting up to maximum up to total of 16 operators and guests.

  • Page 49: Log

    Wired Internet Camera RXS-3211 Login as Guest: You can select to save the snapshot and record video. Add/Modify/Remove Add: After enter the above info, you can click “Add” to create new account. Modify: You can click your current account to change the Login account name, password, and authority, and then click “Modify”...
  • Page 50 Wired Internet Camera RXS-3211 User Manual Click “Refresh” to get latest update.

  • Page 51: Chapter 4 Using Surveillance Software

    Wired Internet Camera Chapter 4 Using Surveillance Software 4.1 Installing Surveillance Software The IP camera surveillance software provides various functions like video recording, after this software is installed, you can use your IP camera to safeguard your property. Please follow the following instructions to install the surveillance software.
  • Page 52 Wired Internet Camera RXS-3211 3. If you need installation program to create a desktop icon or a quick launch icon for you, click all items you need here, then click “Next” to continue. 4. Here lists all options you chose in previous steps, if everything’s correct, click “Install”...
  • Page 53 Wired Internet Camera RXS-3211 5. The installing procedure will take some time, please be patient. 6. When you see this window, it means the software installing procedure is complete. Please click “‘Finish” to finish the procedure (IP camera surveillance software will start after you click “Finish” button, if you want to start it later, uncheck “Launch IPCam Surveillance Software”...

  • Page 54: Using Surveillance Software

    Wired Internet Camera RXS-3211 User Manual 4.2 Using Surveillance Software You can click ‘IPCam Surveillance Software’ icon from desktop, quick launch bar, or start menu to start the IP camera surveillance software. Before you start: IP camera surveillance software will only work when your monitor’s resolution is ‘1024 x 768’.
  • Page 55 Wired Internet Camera RXS-3211 You can put the mouse cursor on a certain component and see its button name, and here’re detailed descriptions of all buttons: Item Video displaying The image of all connected cameras will be displayed area here. Language Select a language from this drop-down menu to change display language.
  • Page 56 Wired Internet Camera RXS-3211 once to activate scan function (scan icon will become blue become white Zoom out Zoom-out (To see more objects). This function is only available for supported cameras. Zoom In Zoom-in (Too see more details). This function is only available for supported cameras. PTZ control There are 8 directions in PTZ control ring.

  • Page 57: Configure Surveillance Software

    Wired Internet Camera RXS-3211 Minimize window Minimizes IP camera surveillance software window. Video displaying Displays the image of all cameras by the display area layout you selected. 4.3 Configure Surveillance Software 4.3.1 Configure cameras Before you use this IP camera surveillance software, you must configure the camera(s) you wish to connect.
  • Page 58 Wired Internet Camera RXS-3211 4.3.1.1 “Camera” tab In this tab you can configure all cameras you wish to connect. Up to 16 cameras can be connected simultaneously: Item Channel Select the channel number you wish to set. Camera Search All cameras found on your local network will be displayed in “Camera Search”...
  • Page 59 Wired Internet Camera RXS-3211 Input the IP address of camera. Username Input the user name of camera. Web Port Input the web port of the camera. By default it’s “80”. Password Input the password of camera. Default value is “1234”. You should change the password if you changed the password of selected camera.
  • Page 60 Wired Internet Camera RXS-3211 In “Schedule Recording” tab, provides you options with setup scheduled video recording, you can record the video captured by all cameras at a pre-defined schedule. Item Channel Select the channel number you wish to set. One Time You can specify the one-time schedule for selected camera;...
  • Page 61 Wired Internet Camera RXS-3211 Please specify the time duration of this one-time schedule (the date and time of “From” and “To”), then click “OK” to save settings. Please note you must set a schedule that will be happened in the future, you can not set a schedule in the past. Edit You can modify a scheduled recording item.
  • Page 62 Wired Internet Camera RXS-3211 in “From” field. You can set the duration of video recording in “Period” field (format is HH:MM:SS), and the end time will be calculated automatically and displayed in “To” field. You can also click “All Time Record” button to define a recording schedule that will be executed every weekday, from 12:00:00AM to 11:59:59PM.

  • Page 63: General Options

    Wired Internet Camera RXS-3211 Item Channel Select the channel number you wish to set. Enable Enable motion record function. Disable Disable motion record function. Recording Time Select the time duration that camera will record when a motion has been detected from dropdown menu in seconds. Save settings in this tab.
  • Page 64 Wired Internet Camera RXS-3211 Item Data Directory Set the directory (folder) you wish to store the recorded video and captured image. You can click “Browse” button to pick a directory in your hard disk. Free Recording Displays remaining storage space. Space Max Video File Defines the maximum file size of every video file.
  • Page 65 Wired Internet Camera RXS-3211 4.3.2.2 “Security” Tab If you don’t want other people to access this IP camera surveillance software, you can set a password to protect it. You’ll need to input the password every time you wish to use this IP camera surveillance software: Item Enable...

  • Page 66: Change Display Layout

    Wired Internet Camera RXS-3211 User Manual time you use this software: 4.3.2.3 “About” Tab This tab shows the version number of the IP camera surveillance software you are using. 4.4 Change Display Layout This IP camera surveillance software provides 8 kinds of display layout:...
  • Page 67 Wired Internet Camera RXS-3211 Every layout displays different number of camera and camera arrangement, you can click the icon that presents a specific kind of layout, and the video displaying area will change accordingly. Layout style 1: 1 Camera only Layout style 2: 4 Cameras Layout style 3: 6 Cameras Layout style 4: 8 Cameras...

  • Page 68: Full-Screen Mode

    Wired Internet Camera RXS-3211 User Manual 4.5 Full-Screen Mode If you want to use all available spaces on your monitor to display surveillance image, you can click “Full Screen” button to switch display mode to full-screen mode. To exit full-screen mode, press “ESC” key. 4.6 Scan If you have more than one camera configured, and you wish to switch the displaying image between cameras, you can click “Scan”...

  • Page 69: Zoom-In / Zoom-Out

    Wired Internet Camera RXS-3211 User Manual displayed in a scan sequence (you’ll see nothing and you’ll see “Disconnected” text displayed at the upper-left corner of display image). Click ‘Scan’ button once to activate scan function (scan icon will become blue ), click again to stop scanning (scan icon will become white 4.7 Zoom-in / Zoom-Out For cameras that support zoom-in / zoom-out function, you can use this...

  • Page 70: Snapshot

    Wired Internet Camera RXS-3211 Please select a camera in video displaying area by clicking on its image, then click button to see more objects that fall in the scope of camera’s view, or click to enlarge the image size of a certain object to see its detail. 4.8 Snapshot You can take a snapshot of selected camera and save it to ‘Snapshot’...

  • Page 71: Recording

    Wired Internet Camera RXS-3211 User Manual Click snapshot button once to take a snapshot; you can take as much snapshot as you want before hard disk is full. 4.9 Recording You can start video recording of selected camera manually by clicking “Start Recording”...
  • Page 72 Wired Internet Camera RXS-3211 User Manual A new window will appear: You have to search the video file before you can play it. There are two kinds of video search: Time Search (search all videos file that falls in a specific period of time) and Motion Search (search all videos recorded by motion detection function and falls in a specific period of time).

  • Page 73: Chapter 5 Appendix

    Wired Internet Camera Chapter 5 Appendix 5.1 Product Specification Product Image Sensor Sensor Resolution Fixed Lens Viewing Angle Minimum Illumination Video/Image Setting Video Format Image Frame Rate Frame Rate Setting Zoom Resolution Video Quality Setting Motion Detected Communication Protocol Hardware Specification Flash Image Sensor Lens...

  • Page 74: Faq / Troubleshooting

    Wired Internet Camera RXS-3211 Consumption 2 Watt (maximum) Dimension 92mm x 60mm x 23mm Operating Operation: 0ºC ~45ºC (32ºF ~ 113ºF) Temperature Storage : -15ºC ~ 60ºC (14ºF ~ 140ºF) Humidity 10~90% (Non-Condensing) Certification FCC Class B, CE Mark 5.2 FAQ / Troubleshooting If the IP camera is not working properly, before you contact the customer service for help, please check the troubleshooting list here, this may help you to solve the problem by yourself and saves your valuable time.

  • Page 75: Image Refreshes Very Slow

    Wired Internet Camera RXS-3211 User Manual f. Contact Rosewill’s customer service for help, if above solutions does not work. 5.2.2 Image refreshes very slow a. Try a higher frame rate setting, if it’s not set to 30. b. Try a lower resolution.

  • Page 76: Ip Camera Is Not Responding

    If IP camera is correctly powered (“Power” LED is on), but you still can not connect to the camera when you’re sure that IP address is correct, please contact Rosewill’s customer service for help). 5.2.4 Image is fuzzy a. Use a soft cloth to clean the lens on the camera. (You can use cloth with water, but DO NOT use alcohol or other chemical solution to apply on the lens.)

  • Page 77: I Set The Ip Camera To Send Image By Email Or Ftp, But Nothing Is Received

    Wired Internet Camera RXS-3211 c. If there’s any light at the place where IP camera is located, switch it on and see if image looks better. 5.2.5 I set the IP camera to send image by Email or FTP, but nothing is received a.

  • Page 78: Additional Setup Guides

    Wired Internet Camera RXS-3211 5.3 Additional Setup guides 5.3.1 Obtain a free Dyndns account to view while away If your ISP is issuing dynamic (non-static) IP address to you and you can’t connect to your IP camera when you’re away from it, you can follow the following steps to obtain a free Dyndns account, which will provide you free IP address to host name mapping service: 1.
  • Page 79 Wired Internet Camera RXS-3211 5. When you see this image, you’ll receive an e-mail confirmation at the e-mail box you registered with dyndns.org. 6. Check your e-mail box and you should be able to get confirmation e-mail. Click the link to connect to dyndns.org website and complete registration procedure.
  • Page 80 Wired Internet Camera RXS-3211 7. When you see “Account Confirmed” webpage, indicates your dyndns.org account has been confirmed and activated. Now you can click “Create a dynamic DNS host within our Free domains” link to continue. 8. Click “Create Hostname” button. User Manual...
  • Page 81 Wired Internet Camera RXS-3211 9. In the “Create Hostname” page:  Input the hostname of your choice in “Hostname” field,  Select a domain name in dropdown menu,  Select “Host with IP address” for “Service Type”,  Input current IP address in “IP Address” field (or click the link below to use detected IP address to fill this field).

  • Page 82: Using This Ip Camera With A Router Or Firewall

    Wired Internet Camera RXS-3211 12. Click “Activate Services” to continue. 13. When you see this message, indicates your free dyndns.org hostname mapping service has been activated. You can go to your dyndns.org username, password, and hostname + domain name to locate your IP camera on Internet even you’re using dynamic IP address! 5.3.2 Using this IP Camera with a router or firewall If this IPCAM is not directly connected to Internet (behind router or firewall),...
  • Page 83 Wired Internet Camera RXS-3211 other computers on Internet. The following instruction describes how to configure your router or firewall device so your IPCAM can work with them. These instructions are based on a commonly-available residential router and these setup techniques should be easy to apply on any other similar devices as well.
  • Page 84 Wired Internet Camera RXS-3211 5.3.2.2 Open Ports Required by IP CAM To access IP CAM located behind router or firewall, you must open ports on router or firewall so you can access IP CAM from Internet. 1. Go to your router’s setup page, and locate “NAT”, “Firewall”, “Port Mapping”, “Port Forwarding”, or similar setup item.

  • Page 85: Using Cell Phone As Ip Camera's Image Viewer

    Wired Internet Camera RXS-3211 3. If IP CAM is the only service you wish to access from Internet, you can also use “DMZ” function to access IP CAM: Simply fill the IP address of IP CAM and you can access IP CAM from the IP address of your router directly.
  • Page 86 Wired Internet Camera RXS-3211 User Manual 4. You’ll see the image of connected camera displayed on upper-left corner of quad-split screen. If you have more than one IP CAM, you can add other 3 IP CAMs to the quad-split screen. Click an unused corner and a yellow square will appear to indicate it’s being marked, then click “Setting”.
