How to Charge the Battery:
Connect the audio recorder to a PC or USB power supply
•
1.5 hours to fully charge
•
A flashing light = Fully charged
•
Solid light = Charging
•
How to Record an audio file:
On top of the device is a toggle wheel with a divot
•
Underneath the Divot on the opposite side of USB & MQ U300 are two hard to see symbols (-) & (...)
•
The Divot can be turned towards either of these symbols
•
If the Divot is in the middle position the the device is OFF
•
If the Divot is turned towards the (-) symbol the device is in Continuous recording mode
•
If the Divot is turned towards the (...) symbol the device is in Voice Activated recording mode
•
When finished recording slide Divot to the middle position to end the recording and turn off the device
•
Wait 5 seconds before making another recording
•
NOTE: If the device runs out of power during the recording, it will finalize and save the file before the battery dies
•
How to Playback files on a PC:
Connect to the USB port of the computer
•
When connected the PC will recognize the device as a removable disk
•
Open VOICE folder
•
Double click the file you wish to play
•
How to Delete the files on a PC:
Open the VOICE folder
•
Right click on the file you wish to delete and select Delete in the pop up menu
•
Files can only be deleted through a PC
•
How to Delete the files on a Mac
Open the VOICE folder
•
Right click on the file you wish to delete and select Delete in the pop up menu
•
While the device is still plugged into the Mac go to your trash folder and empty trash.
•
Note: If the above step is not completed the files will not be fully deleted from the device and you will have a phantom
•
folder that will contain the deleted files that can only be seen by a Windows Computer
Specifications:
Memory capacity: 4GB
•
Recording format: .MP3
•
Recording capacity: 144 hours
•
Battery power consumption: 15hours (continuous) or 25 days (standby)
•
NOTE: if a folder does not automatically open when connected to PC, disconnect the device and preform the following
1.
Open Control Panel by typing "control panel" in the Search bar
2.
Select Programs
3.
Under Default Programs, Click "Change default settings for media or devices"
4.
Under Removable Devices, select "Open folder to view files"
5.
Save
6.
Reconnect the device to the PC
USB FLASH DRIVE AUDIO
RECORDER QUICK START GUIDE
