Low Voltage Signal

1. The vehicle requires 12.7V DC to operate in the AUTO mode. If the voltage is too low, the screen will
display LOW VOLTAGE. If voltage drops below 12.7V DC, the system will only operate in the MANUAL
MODE and continue to display LOW VOLTAGE.
2. Minimum Voltage - If voltage drops below 9.5V DC during AUTO or MANUAL operation LOW VOLTAGE
will appear in the screen and the system will cease operating.

Error Mode

Excess Angle

1.
The control will not operate at extreme slopes, i.e. 3.5 degrees fore and aft and 3.5 degrees side to
side.
2.
If the coach indicates "EXCESS ANGLE" or "JACKS STROKED OUT" during an auto level cycle, move the
coach to a more level spot.
Error Mode
NOTES:
• If an error occurs before or during operation, the error will be displayed in the LCD and an alarm will
sound. To reset all error or service displays, push RETRACT and ENTER at the same time.
• All normal functions will be disabled when the system is in Error Mode.
• Auto Level can only commence if running voltage is 12.7V DC or above.
• Auto Level operation will halt if running voltage drops to 9.5V DC.
• Manual Level operation can be performed at all running voltages above 9.5V DC.
Error Text
Excess Angle
Feature Disabled
External Sensor
Out of Stroke
Low Voltage
Function Aborted
Jack Timeout
Auto Level Fail
Not Configured
Zero Not Set
Battery Voltage
Apply Park Brake to Auto Level
Unit has retracted for longer
than 50 seconds
Unable to Finish Leveling
Check Wiring
Caution, Excess Run Time
Latched Retract / Service
Rev: 06.29.18
Description
Excess slope for auto leveling
Control not zeroed
Remote sensor short or disconnected
Check campsite for even, level ground and turn engine
on - Check battery voltage under load.
Turn engine on - Check battery voltage under load.
Panic stop
Auto mode/Retract timeout
Unable to level
Control not zeroed
Control not zeroed
Turn engine on - Check battery voltage under load
Set parking brake
Retract timeout, return leveling jacks for service.
Latched retract mode
Move coach to a more level site
Touch Pad is powered, but not communicating with
the controller. Check pin 1 and 2 of touch pad harness.
Pump run too long in manual mode
Check for leaking jack hose or fitting, reset by pressing
retract and enter at the same time.
Page 9
