GE Interlogix NetworX NX-2192E-EUR Installation Manual page 7

Table 10-4
TABLE 10-4
IS USED TO
PROGRAM
LOCATIONS
338 - 481
LOCATIONS 338 - 361
When activating outputs with a user code (event #32), locations 338 - 361 can be used to restrict certain codes from activating certain
outputs. Each location contains 10 segments. Location 338 / segment 1 corresponds to user 1; segment 10 corresponds to user 10; and
finally location 361 / segment 1 corresponds to user 231; Segment 10 corresponds to user 240. The LEDs correspond to outputs 1 - 8.
Refer to Table 10-4 for descriptions.
LOCATIONS 362 - 385
When activating outputs with a user code (event #32), locations 362 - 385 can be used to restrict certain codes from activating certain
outputs. Each location contains 10 segments. Location 362 / segment 1 corresponds to user 1; segment 10 corresponds to user 10; and
finally location 385 / segment 1 corresponds to user 231; Segment 10 corresponds to user 240. The LEDs correspond to outputs 9 - 16.
Refer to Table 10-4 for descriptions.
LOCATIONS 386 - 409
When activating outputs with a user code (event #32), locations 386 - 409 can be used to restrict certain codes from activating certain
outputs. Each location contains 10 segments. Location 386 / segment 1 corresponds to user 1; segment 10 corresponds to user 10; and
finally location 409 / segment 1 corresponds to user 231; Segment 10 corresponds to user 240. The LEDs correspond to outputs 17 -
24. Refer to Table 10-4 for descriptions.
LOCATIONS 410 - 433
When activating outputs with a user code (event #32), locations 410 - 433 can be used to restrict certain codes from activating certain
outputs. Each location contains 10 segments. Location 410 / segment 1 corresponds to user 1; segment 10 corresponds to user 10; and
finally location 433 / segment 1 corresponds to user 231; Segment 10 corresponds to user 240. The LEDs correspond to outputs 25 -
32. Refer to Table 10-4 for descriptions.
LOCATIONS 434 - 457
When activating outputs with a user code (event #32), locations 434 - 457 can be used to restrict certain codes from activating certain
outputs. Each location contains 10 segments. Location 434 / segment 1 corresponds to user 1; segment 10 corresponds to user 10; and
finally location 457 / segment 1 corresponds to user 231; Segment 10 corresponds to user 240. The LEDs correspond to outputs 33 -
40. Refer to Table 10-4 for descriptions.
LOCATIONS 458 - 481
When activating outputs with a user code (event #32), locations 458 - 481 can be used to restrict certain codes from activating certain
outputs. Each location contains 10 segments. Location 458 / segment 1 corresponds to user 1; segment 10 corresponds to user 10; and
finally location 481 / segment 1 corresponds to user 231; Segment 10 corresponds to user 240. The LEDs correspond to outputs 41 -
48. Refer to Table 10-4 for descriptions.
LED
1 "On" if code will activate output; "Off" if it will not.
2 "On" if code will activate output; "Off" if it will not.
3 "On" if code will activate output; "Off" if it will not.
4 "On" if code will activate output; "Off" if it will not.
5 "On" if code will activate output; "Off" if it will not.
6 "On" if code will activate output; "Off" if it will not.
7 "On" if code will activate output; "Off" if it will not.
8 "On" if code will activate output; "Off" if it will not.
OUTPUTS 1 – 8 ENABLE
OUTPUTS 9 - 16 ENABLE
OUTPUTS 17 - 24 ENABLE
OUTPUTS 25 - 32 ENABLE
OUTPUTS 33 - 40 ENABLE
OUTPUTS 41 - 48 ENABLE
NX-2192E PINPOINT SYSTEM
DESCRIPTION
CODES 1 – 240
CODES 1 – 240
CODES 1 – 240
CODES 1 – 240
CODES 1 – 240
CODES 1 – 240
OUTPUTS
1, 9, 17, 25, 33, 41
2, 10, 18, 26, 34, 42
3, 11, 19, 27, 35, 43
4, 12, 20, 28, 36, 44
5, 13, 21, 29, 37, 45
6, 14, 22, 30, 38, 46
7, 15, 23, 31, 39, 47
8, 16, 24, 32, 40, 48
10 segments of feature selection data
10 segments of feature selection data
10 segments of feature selection data
10 segments of feature selection data
10 segments of feature selection data
10 segments of feature selection data
