Table 10-2
LOCATION 242 – 336 (EVEN LOC)
Segment 1 is used to select the particular event that will trigger the output. Refer to Table 10-3 for the specific events that can be
selected.
Segment 2 is used to select the amount of time an output will remain activated when an output triggers. If this location is programmed as
a zero, the output will follow the particular event.
Table 10-3
# Event
0 Always On
AC Fail (control or exp.) does not
1
follow AC Fail delay time
2 Low Battery (control or exp.)
3 Dynamic Battery Test Time
4 Listen In
5 Line Seizure
6 Telephone Line Fault
7 Program Mode
8 Over-current (control or exp.)
9 Box Tamper (control or exp.)
10 Siren Tamper (control or exp.)
♦ If set to follow condition, these events will be one second.
LOCATION 243 – 337 (ODD LOC)
Segment 1 selects the following special conditions:
1 =
"On" if output should time in minutes; "Off" if output times in seconds.
2 =
"On" if output should latch until a code is entered; "Off" for timed.
3 =
"On" if output should stop time when a code is entered.
4 =
"On" for inverted output.
5 =
"On" disables output during listen-in (only events 12-16).
6 =
Reserved.
7 =
Reserved.
8 =
Reserved.
Segment 2 selects the following partitions:
1 =
"On" if the event should activate when it occurs in Partition 1.
2 =
"On" if the event should activate when it occurs in Partition 2.
3 =
"On" if the event should activate when it occurs in Partition 3.
4 =
"On" if the event should activate when it occurs in Partition 4.
5 =
"On" if the event should activate when it occurs in Partition 5.
6 =
"On" if the event should activate when it occurs in Partition 6.
7 =
"On" if the event should activate when it occurs in Partition 7.
8 =
"On" if the event should activate when it occurs in Partition 8.
6
ERROR CODE
1 Node is missing.
2 Multiple node responded.
3 Communication error.
4 Device type mismatch.
5 Auto enroll error.
6 Reserved.
7 Output programmed to non-output device.
8 Output programmed but node not enabled.
#
11 Smoke Power Reset
12 Yelping Siren
13 Steady Siren
14 Any Siren
15 Steady Siren (temporal)
16 Any Siren (temporal)
17 Alarm Memory
18 Entry
19 Exit
20 Entry or Exit
21 Armed
SPECIAL FEATURES FOR
NX-2192E PINPOINT SYSTEM
DESCRIPTION
EVENT & TIME FOR
OUTPUTS 1 - 48
Event
OUTPUTS 1 - 48
2 segments of numerical data
# Event
22 Disarmed
23 Ready to Arm
24 Not Ready to Arm
25 Fire
26 Fire Trouble
27 Chime
28 Beeping Keypad
29♦ Aux 1 Keypad Function
30♦ Aux 2 Keypad Function
31♦ Panic Keypad Function
32♦ Code Entry (set in locs 338 - 481)
2 segments of feature selection data
