Installation instruction
TWEETER X P 30
6 206 43 12
= N
177mm
7"
350°
424mm
16"-11/16
8mm
5/16"
Ø95mm
Ø3"-3/4
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
Ø134mm
Ø5"-5/16
Application
Floor surface mounted
For indoor & outdoor use
Color Finish
N - Dark Grey
Light source
1x POWERLED WHITE 7W / 3000K
Product description
Corrosion protected, powder coated aluminum construction
Electronic power supply included. 120V input, 350 mA current controlled class 2 output.
5' SJ00W cable included for easy installation
Suitable for wet, damp or dry locations
Dust-tight - Protected against water jets
Weight: 3,1lbs 1,4kg
Accessories not supplied (option)
PIN 11
IP68 CONNECTOR 3P
NORTH AMERICAN EDITION
IP65
229 01 11
6 216 12 02
6 216 12 00
TWEETER X P 30
Conforms to ANSI/UL Std. 1598
Cert. to CAN/CSA Std. 22.2 No. 250.0
Last Update 28/11/2014
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Delta Light TWEETER X P 30
Summary of Contents for Delta Light TWEETER X P 30
- Page 1 TWEETER X P 30 Installation instruction TWEETER X P 30 6 206 43 12 177mm 7” Ø134mm Ø5”-5/16 350° 424mm 16”-11/16 Application Floor surface mounted 5/16” For indoor & outdoor use Ø95mm Ø3”-3/4 Color Finish N - Dark Grey Light source...
- Page 2 77mm 3”-1/32 38mm 38mm 1”-15/32 1”-15/32 52mm 2”-1/32 EXAMPLE: TWEETER X P 30 / 6 206 43 12 Use 1/2” conduit or any other local code compliant method! OPTION Use 1/2” conduit or any Use 1/2” conduit or any JUNCTION BOX...
