Resolution RE212T Instructions

RE212T 2GIG-Compatible Smoke & Heat Alarm

Features

UL217 Self-Contained Fire Alarm Device
•
Senses and alarms to Smoke per UL217
•
Heat alarm at 144 degrees.
•
Sleek design.
•
Cover tamper.
•
Strong, reliable RF signal.
•
3-5 year battery life on Panasonic CR123A battery.
•
Low Battery indication.
•

Key Instructions

1. Attach the mounting plate
Locate on ceiling, as close to center as possible, away from corners.
Some local codes may allow wall mounting.
Mounting plate removes counter-clockwise
2. Insert battery with MINUS towards the RED lever. Close battery door.
3. Enroll sensor in panel:
Question
Q1:
Select RF sensor # (01-48)
Select RF sensor type
Select RF sensor equip type
Select RF sensor equip code
Select RF sensor serial number
Select RF sensor Age
Select RF sensor Loop number
4. Testing:
a) Place panel in Sensor Test mode
b) Press & hold TEST button until you hear the sounder beep.
c) Panel will go into alarm.
NOTE: Using Smoke-in-a-Can will cause an actual Fire Alarm.
RE212T_2GIG-Compat_Smoke_Instructions Page 1 of 4
24-Hour Tech Support Line: (715)808-0164
www.ResolutionProducts.com
Available for...
GE
Honeywell
2GIG
DSC
Answer
Zone number of your choice
[09] 24-Hour Fire, or [16] 24-Hour Fire w/
Verification (See Control Panel Installation
Manual)
[1] Contact
[0872] SMKE1-345 smoke detector
Press Shift, Press Learn
Press and hold the TEST Button for 5 seconds
[1] New
[1] Motion
22-Feb-16

Operation

Situation Sounder LED
Actual smoke Temporal 3 RED
(Loud) (pulsing)
Press & hold Temporal 3 RED
Test Button (Loud) (pulsing)
Removing Temporal 3 Yellow
Sensor from (Loud) (steady)
Mount
Low Battery Yellow
(pulsing)
Hourly Check
Maintenance Temporal 3 Yellow
Needed (Loud) (Pulsing)

Specifications

Approval: UL217 Self-Contained Fire Alarm Device
Smoke Sensitivity: 1.31 – 2.28 %/ft (UL 217)
0.11 – 0.165 dB/m (EN54-7)
Smoke Sensing Technology: Photoelectric
Heat Alarm Point: 135 – 149 F (UL 521)
Alarm Sound: Temporal Three
Replacement Battery: Panasonic CR123A
Temperature Range: 32 to 120 F (Long Term)
Humidity: 10 – 85% Relative Humidity
Housing dimensions: 4.7 inch diameter, 2.1 inch high
Design & Manufacture: Resolution Products, Inc.
Specifications subject to change without notice.
RE212T_2GIG-Compat_Smoke_Instructions Page 2 of 4
24-Hour Tech Support Line: (715)808-0164
www.ResolutionProducts.com
Wireless Signal Recovery
to Panel
Wireless Fire Silence an actual
Alarm Signal sent alarm with the TEST
to panel button. Sensor will
return to alarm if
smoke is still
present.
Sensor Alarm Sensor: Release
signal to panel button.
Panel: Restores after
alarm is cancled
Tamper/Trouble Restore by
signal to be sent remounting.
to panel.
Supervisories,
every hour
Supervisories Not Replace Unit
Sent
22-Feb-16
