MICA ML-600 User Manual

OPERATING TIMES
The operating times here refer to a fully loaded battery and full brightness:
With a 2.4 W bulb With a 4W bulb
4h20min 2h40min
The signalling LEDs will remain in operation for more than 12 hours with
a fully charged battery.
ACCESSORIES FOR MLC
1. Wire for connecting to a cigarette lighter (01112)
2. IL-1 AC/DC adapter 230 VAC / 12VDC (11270)
3. IL-4 AC/DC adapter 230 VAC / 12VDC for five charging stands (11322)
4. IL-5 automatic exchanger for five charging stands (11311)
TECHNICAL DATA FOR ML LAMPS
Bulbs: 6.0V / 2.4 W or 4W / PX13.5
Battery: (ML-600) NiMH 6 V 1800mAh
Battery: (ML-601/602) NiMH 6V 1350mAh
Electronics: 8-bit microcontroller
Lens: 41.5x 3 mm, toughened glass
Reflector: Aluminum
Operation temperature: –20...+45°C (lamp)
Operating time: > 4h @ 2.4W full power
Enclosure class: IP 54, splash-proof
Dimensions (h x w x d): 120 x 64 x 55mm with belt clip
Weight: ca. 315g (ML-600) & ca. 275g (ML-601/602)
TECHNICAL DATA FOR MLC CHARGING STAND
Quick charge voltage: 750mA
Maintenance charge voltage: 100mA
Charging temperature range: +10°C ...+40°C
Quick charging time: 2h 45min
Maximum charging time: 4h (in fault situation for security reasons)
Conditions for ending charging: -dV, Tmax ≤45°C, tout ≤4h
Feed voltage for charging stand: 12VDC ... max. 30VDC
Weight of charging stand: ca. 170g
BATTERY DISPOSAL
A used battery is classified as hazardous waste! Please make sure that the battery is properly
disposed of in accordance with instructions from the authorities. Do not dispose of the battery
by burning it.
WARRANTY CONDITIONS
Warranty period for the lamp and the battery is one year. The warranty period begins when
the lamp is purchased. The warranty covers manufacturing and raw material defects in line
with general warranty conditions. Under the warranty period, the lamp may be serviced by
an authorized MICA service agent only. If you need the lamp to be serviced under the warranty,
please contact the retailer from whom you purchased your MICA lamp.
OTHER MICA LAMPS
For more information, please contact Mica Elektro Oy directly or visit our web site at
www.mica.fi
© Mica Elektro Oy LTD. 5-2005. We reserve the right to revise any information in this user
manual without a preliminary notice.
01877_2
(Table A1)
User manual for MICA ML-600/601/602 lamps
TO USER
Manufactured in Finland, MICA ML is a small yet effective rechargeable product family for
demanding professional use. The frames are splash and shock proof. The lamps' bright light
pattern is achieved by using a high halogen and an aluminum reflector. At best, the lamps'
operating time is three hours with a 4W bulb and a fully loaded NiMH battery.
Please read this manual carefully in order to secure your lamp a long service life.
Mica Elektro Oy LTD. POB 42, FIN-00381, Helsinki FINLAND
tel: +358-9-5617 666 fax: +358-9-5617 6688
email: info@mica.fi internet: www.mica.fi
Prior to use, remember
to attach the battery wire
to the printed circuit
board!
The battery must always
be charged full prior to
using the lamp.
