More information, guides and updates can be found from Internet
Package includes:
- RRAP –router
- Installation guide
Connectors / Ports:
1.
WAN port: Connect your xDSL or cable modem to this port by
Ethernet cable.
LAN 1 – 4 ports: Connect your PC to these ports by Ethernet cable
2.
3.
WPS button: Press 5 seconds to start WPS function
4.
Reset button: Press 7 seconds for reset to factory defaults
5.
Power button: Turn power OFF and ON
6.
Power connector: Insert provided power adapter to this connector
7.
USB port: Use this port to connect USB modem or USB memory
Installation requirements:
-
Place the product to horizontal and flat base
-
Keep the product away from heating devices
-
Do not keep product in dusty or wet place
RRAP GIGABIT WLAN ROUTER
Quick Installation Guide
- Power adapter
- Network cable
https://www.alinetrade.com
Front panel led's/functions:
1.
Power LED:
ON = Power is ON
OFF = Power is OFF
2.
WAN LED:
ON = WAN port connected
Flashing = data traffic on network (WAN)
OFF = WAN port is not connected
LAN 1 – 4 LED:
3.
ON = LAN port connected
Flashing = data traffic on network (LAN)
OFF = LAN port is not connected
4.
2.4GHz WLAN LED:
OFF = 2.4GHz Wireless network not activated
Flashing = 2.4GHz Wireless network is activated and ready
5.
5GHz WLAN LED:
OFF = 5GHz Wireless network not activated
Flashing = 5GHz Wireless network is activated and ready
6.
WPS LED:
Fast flashing = WPS function enabled for 2 minutes
OFF = WPS function disabled
Advertisement
Related Manuals for A-Link RRAP
Summary of Contents for A-Link RRAP
-
Page 1: Quick Installation Guide
RRAP GIGABIT WLAN ROUTER Quick Installation Guide https://www.alinetrade.com More information, guides and updates can be found from Internet Package includes: - RRAP –router - Power adapter - Installation guide - Network cable Front panel led’s/functions: Power LED: ON = Power is ON... -
Page 2: Getting Started
WLAN password = Check the ”WLAN key” from product sticker Management User name = admin ; Password = admin RRAP is in ”Gateway” mode as factory defaults. WAN port will get the IP address from operator and all LAN ports as well as WLAN are behind in NAT firewall at own local network. - Page 3 RRAP GIGABIT WLAN REITITIN Pika-asennusohje https://www.alinetrade.com Lisätietoa, ohjeita ja päivityksiä löydät Internetistä osoitteesta Pakkaus sisältää: - RRAP – reititin - Virtalähde - Asennusohje - Verkkokaapeli Etupaneelin valot/toiminnot: Power LED: ON = Virrat on päällä OFF = Virrat on pois päältä...
- Page 4 WLAN password = Katso”WLAN key” laitteen tarrasta Hallintasivujen Username = admin ; Password = admin RRAP on oletuksena ”Gateway” tilassa, jolloin WAN – portille tulee IP – osoite operaattorilta ja kaikki LAN – portit sekä WLAN ovat NAT -palomuurin takana omassa lähiverkossa. IP – osoite tietokoneille haetaan automaattisesti reitittimeltä.
