VMIC VMIVME-7750 Product Manual

Intel 133mhz front-side bus pentium iii processor - vmebus sbc
Hide thumbs
Table of Contents

Advertisement

Quick Links

VMIVME-7750
Intel 133MHz Front-Side Bus Pentium III Processor -
VMEBus SBC
Product Manual
12090 South Memorial Parkway
Huntsville, Alabama 35803-3308, USA
w
w
(256) 880-0444
(800) 322-3616
Fax: (256) 882-0859
500-007750-000 Rev. D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VMIVME-7750 and is the answer not in the manual?

Questions and answers

Related Manuals for VMIC VMIVME-7750

Summary of Contents for VMIC VMIVME-7750

  • Page 1 VMIVME-7750 Intel 133MHz Front-Side Bus Pentium III Processor - VMEBus SBC Product Manual 12090 South Memorial Parkway Huntsville, Alabama 35803-3308, USA (256) 880-0444 (800) 322-3616 Fax: (256) 882-0859 500-007750-000 Rev. D...
  • Page 3 VMIC reserves the right to make any changes, without notice, to this or any of VMIC’s products to improve reliability, performance, function, or design. VMIC does not assume any liability arising out of the application or use of any product or circuit described herein; nor does VMIC convey any license under its patent rights or the rights of others.

  • Page 5: Table Of Contents

    Table of Contents Overview ..................Intel 815E Chipset .
  • Page 6 Ethernet Controllers ............... . 10BaseT .
  • Page 7 Appendix A - Connector Pinouts ............VMEbus Connector Pinout .
  • Page 8 Main Menu ................. QuickBoot .
  • Page 9 Security ..................Password On Boot .
  • Page 11 VMIVME-7750 PMC and Jumper Locations ........
  • Page 13 VMIVME-7750 I/O Address Map ........

  • Page 15: Overview

    Eurocard form factor that utilizes the advanced technology of Intel’s 815E chipset running at a front-side bus rate of 133 MHz. The VMIVME-7750 is compliant with the VME Specification Rev. C.1 and features a transparent PCI-to-VME bridge, allowing the board to function as a system controller or peripheral CPU in multi-CPU systems.
  • Page 16 Windows NT. The embedded features of the VMIVME-7750 are described in Chapter 3 of this manual. The VMIVME-7750 is suitable for use in a variety of applications, such as: telecommunications, simulation, instrumentation, industrial control, process control and monitoring, factory automation, automated test systems, data acquisition systems and anywhere that the highest performance processing power in a single VME slot is desired.

  • Page 17: Intel 815E Chipset

    Intel 815E Chipset Intel 815E Chipset The VMIVME-7750 incorporates the latest Intel chipset technology, the 815E. This chipset departs from previous generation devices by utilizing a new Advanced Hub Architecture (AHA). The AHA allows for increased system performance by separating many high-bandwidth I/O accesses (like IDE or USB devices) from PCI accesses, relieving bottlenecks on the PCI bus.
  • Page 18 Ethernet MII ICH2 CK-Solano PCI Bus (33MHz, 32-bit) (aka CK-815) ATA-100 IDE (secondary channel) Tundra Universe IIB National LPC SIO #1 Endian Conversion, Compact BYTE SWAP & Flash Tranceivers Rear I/O & VME Bus (P1/P2) Figure 1 VMIVME-7750 Block Diagram...

  • Page 19: Organization Of The Manual

    Chapter 1 - Installation and Setup describes unpacking, inspection, hardware jumper settings, connector definitions, installation, system setup and operation of the VMIVME-7750. Chapter 2 - Standard Features describes the unit design in terms of the standard PC memory and I/O maps, along with the standard interrupt architecture.

  • Page 20: References

    VMIVME-7750 Product Manual References Pentium III Processor for the PGA370 Socket at 500MHz to 1.0 GHz August 2000, Order Number 245264-006 Intel 815 Chipset Family: 82815 Graphics and Memory Controller Hub (GMCH) June 2000, Order Number 290687-001 Intel 82801 BA I/O Controller Hub 2 (ICH2) June 2000, Order Number 290687-001 PCI Local Bus Specification, Rev.
  • Page 21 Scottsdale, AZ 85260 (602) 951-8866 (602) 951-0720 (FAX) www.vita.com The following is useful information related to remote Ethernet booting of the VMIVME-7750: Microsoft Windows NT Server Resource Kit Microsoft Corporation ISBN: 1-57231-344-7 www.microsoft.com The following is useful information related to the operation of the I...

  • Page 22: Safety Summary

    Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture and intended use of this product. VMIC assumes no liability for the customer’s failure to comply with these requirements. Ground the System To minimize shock hazard, the chassis and system cabinet must be connected to an electrical ground.

  • Page 23: Warnings, Cautions And Notes

    Warnings, Cautions and Notes Warnings, Cautions and Notes STOP informs the operator that a practice or procedure should not be performed. Actions could result in injury or death to personnel, or could result in damage to or destruction of part or all of the system. WARNING denotes a hazard.

  • Page 24: Notation And Terminology

    VMIVME-7750 Product Manual Notation and Terminology This product bridges the traditionally divergent worlds of Intel-based PC’s and Motorola-based VMEbus controllers; therefore, some confusion over “conventional” notation and terminology may exist. Every effort has been made to make this manual consistent by adhering to conventions typical for the Motorola/VMEbus world;...

  • Page 25: Chapter 1 - Installation And Setup

    All claims arising from shipping damage should be filed with the carrier and a complete report sent to VMIC Customer Service along with a request for advice concerning the disposition of the damaged item(s).

  • Page 26: Hardware Setup

    VMIVME-7750 Product Manual Hardware Setup The VMIVME-7750 is factory populated with user-specified options as part of the VMIVME-7750 ordering information. The CPU speed, RAM size and flash memory size are not user-upgradable. To change CPU speeds or RAM/Flash size, contact customer service to receive a Return Material Authorization (RMA).

  • Page 27: Figure 1-1 Vmivme-7750 Pmc And Jumper Locations

    Hardware Setup PMC 1 Figure 1-1 VMIVME-7750 PMC and Jumper Locations...

  • Page 28: Table 1-1 Cpu Board Connectors

    VMIVME-7750 Product Manual Table 1-1 CPU Board Connectors Connector Function Mouse/Keyboard J4, J5 Ethernet 1 & 2 IDE (PRI), Floppy Dual USB Video E2, E4, E5, Factory Reserved E6, E9, E10, Do Not Use C Header J1, J2, J3 PMC Slot 1...

  • Page 29: Power Requirements

    Table 1-7 VME Jumper (User Configurable) - Jumper (E13) Select Jumper Position Enable VME SYSRESET Driver Enable SYSRESET Receiver Power Requirements The VMIVME-7750 requires +5V, +12V and -12V from the VME backplane. Below are the voltage and current requirements. Supply Current (Typical) Current (Maximum) 5.8A...

  • Page 30: Installation

    VMIVME-7750 Product Manual Installation The VMIVME-7750 conforms to the VMEbus physical specification for a single slot 6U dual Eurocard (dual height). It can be plugged directly into any standard chassis accepting this type of board. CAUTION: Do not install or remove the board while power is applied.

  • Page 31: Bios Setup

    Configuration’. The CMOS configuration controls many details concerning the behavior of the hardware from the moment power is applied. The VMIVME-7750 is shipped from the factory with hard drive type configuration set to AUTO in the CMOS. Details of the VMIVME-7750 BIOS setup program are included in Appendix C.

  • Page 32: Figure 1-2 Installing A Pmc Card On The Vmivme-7750

    VMIVME-7750 Product Manual Third Party PMC Expansion Board Standoff Figure 1-2 Installing a PMC Card on the VMIVME-7750...

  • Page 33: Front/Rear Panel Connectors

    The VMIVME-7750 provides front-panel access to the PMC expansion site, the VGA connector, both 10/100 Ethernet connectors, the manual reset switch, COM 1 and 2, dual USB and the status LEDs. A drawing of the VMIVME-7750 front-panel is shown in Figure 1-3. The front-panel connectors and indicators are labeled as follows: •...

  • Page 34: Led Definition

    VMIVME-7750 Product Manual LED Definition Reset Switch Reset - Allows the system to be reset from the front panel. LAN Active LED R Reset - Lights during reset condition, (Red LED). 10BaseT/100BaseTx LED P Power - Indicates when power is applied to the LAN Active board, (Green LED).

  • Page 35: Table 1-8 Status Indications

    Front/Rear Panel Connectors In addition, the front-panel LEDs are used to indicate various modes of operational status that can occur with the VMIVME-7750. The table below is a summary of these indications. Table 1-8 Status Indications State Indication Board is in Reset “LAN 10BaseT/100BaseT”...
  • Page 36 VMIVME-7750 Product Manual...

  • Page 37: Chapter 2 - Standard Features

    Universal Serial Bus..........52 Introduction The VMIVME-7750 is an Intel Pentium III processor-based single board computer compatible with modern industry standard desktop systems. The VMIVME-7750 therefore retains industry standard memory and I/O maps along with a standard interrupt architecture.

  • Page 38: Cpu Socket

    Windows NT 4.0 service pack level 3. It is recommended that an emergency repair disk be kept up-to-date and easily accessible. The VMIVME-7750 includes 32 Kbyte of non-volatile SRAM which can be accessed by the CPU at any time, and is used to store system data that must not be lost during power-off conditions.

  • Page 39: Memory And Port Maps

    The memory map for the Tundra Universe II-based interface VMIVME-7750 is shown in Table 2-1. All systems share this same memory map, although a VMIVME-7750 with less than the full 256 Mbyte of SDRAM does not fill the entire space reserved for On-Board Extended Memory.

  • Page 40: I/O Port Map

    VMIVME-7750 Product Manual I/O Port Map Like a desktop system, the VMIVME-7750 includes special input/output instructions that access I/O peripherals residing in I/O addressing space (separate and distinct from memory addressing space). Locations in I/O address space are referred to as ports.
  • Page 41 $500 - CFF 2048 Reserved * While these I/O ports are reserved for the listed functions, they are not implemented on the VMIVME-7750. They are listed here to make the user aware of the standard PC usage of these ports.

  • Page 42: Interrupts

    The interrupt number in HEX and decimal are also defined for real and protected mode in Table 2-4 on page 43. The interrupt hardware implementation on the VMIVME-7750 is standard for computers built around the PC architecture, which evolved from the IBM PC/XT. In the IBM PC/XT computers, only eight interrupt request lines exist, numbered from IRQ0 to IRQ7 at the PIC.

  • Page 43: Table 2-4 Pc Interrupt Vector Table

    Interrupts Table 2-3 PC Hardware Interrupt Line Assignments (Continued) AT FUNCTION COMMENTS Mouse Math Coprocessor AT Hard Drive Flash Drive Table 2-4 PC Interrupt Vector Table INTERRUPT NO. REAL MODE PROTECTED MODE LINE Divide Error Same as Real Mode Debug Single Step Same as Real Mode Memory Parity Error, Same as Real Mode...
  • Page 44 VMIVME-7750 Product Manual Table 2-4 PC Interrupt Vector Table (Continued) INTERRUPT NO. REAL MODE PROTECTED MODE LINE BIOS Comm I/O Same as Real Mode BIOS Cassette Tape I/O Same as Real Mode BIOS Keyboard I/O Same as Real Mode BIOS Printer I/O...

  • Page 45: Pci Interrupts

    For a single function device, only INTA# may be used while the other three interrupt lines have no meaning. Figure 2-1 on page 47 depicts the VMIVME-7750 interrupt logic pertaining to VME operations and the PMC site.

  • Page 46: Pci Device Interrupt Map

    VMIVME-7750 Product Manual The slave PIC accepts the VME interrupts through lines that are defined by the BIOS. The BIOS defines which interrupt line to utilize depending on which system requires the use of the line. PCI Device Interrupt Map The PCI bus-based external devices include the PMC sites, Ethernet controller and the PCI-to-VME bridge.

  • Page 47: Figure 2-1 Connections For The Pc Interrupt Logic Controller

    Interrupts INTR 8259 MASTER- PORTS $020-$021 Unused Floppy Keybd Interrupt Com 2 Com 1 Unused Timer 8-15 Control IRQ0 IRQ1 IRQ2 IRQ3 IRQ4 IRQ5 IRQ6 IRQ7 8259 SLAVE- PORTS $0A0-$0A1 Real-Tm Mouse Math Flash IRQ2 Hard Drv Drive Clock Coproc IRQ8 IRQ9 IRQ11...

  • Page 48: Table 2-6 Nmi Register Bit Descriptions

    VMIVME-7750 Product Manual The PCI-to-VME Bridge has the capability of generating a Non-Maskable Interrupt (NMI) via the PCI SERR# line. Table 2-6 describes the register bits that are used by the NMI. The SERR interrupt is routed through logic back to the NMI input line on the CPU.

  • Page 49: Integrated Peripherals

    VME backplane to a VMIACC-0562 transition utility board which terminates into a standard 40-pin header. This channel can support two drives, a master and slave. The IDE interface on the VMIVME-7750 supports ATA-33, ATA-66 and ATA-100 drives and automatically determines the proper operating mode based on the type of drive used.

  • Page 50: Ethernet Controllers

    10BaseT has a maximum length of 100 meters. 100BaseTx The VMIVME-7750 also supports the 100BaseTx Ethernet. A network based on a 100BaseTx standard uses unshielded twisted-pair cables and a RJ-45 connector. The 100BaseTx has a maximum length of 100 meters.

  • Page 51: Video Graphics Adapter

    Video Graphics Adapter Video Graphics Adapter The SVGA port on the VMIVME-7750 is controlled by the Intel Graphic and Memory Controller Hub (GMCH) chip with 4 Mbyte video DRAM. The GMCH is hardware and BIOS compatible with the industry EGA and SVGA standards supporting both VESA high-resolution and extended video modes.

  • Page 52: Universal Serial Bus

    VMIVME-7750 Product Manual Universal Serial Bus The VMIVME-7750 provides a dual Universal Serial Bus (USB) connection on the front panel. The on-board USB controllers completely support the standard USB interface. The USB Host Controller moves data between system memory and the USB by processing and scheduling data structures.

  • Page 53: Chapter 3 - Embedded Pc/Rtos Features

    VME applications. These features make the unit ideal for embedded applications, particularly where standard hard drives and floppy disk drives cannot be used. The VMIVME-7750 also supports C by integrating specialized circuitry for these functions.

  • Page 54: Vmebus Bridge

    The VMIVME-7750 supports High Throughput DMA transfers of bytes, words and longwords in both Master and Slave configurations. If Endian conversion is not needed, VMIC offers a special “Bypass” mode that can be used to further enhance throughput (not available for byte transfers).

  • Page 55: I2C Support

    I2C_SCL The VMIVME-7750 provides termination on the I C signals. The controller can issue interrupts to the VMIVME-7750 when handshaking on the C-bus. When the I C-bus controller drives the interrupt active, software must service and then clear the interrupt. Software can determine the cause of the interrupt by reading the bit of the status register.

  • Page 56: Embedded Pci Functions

    The “Device ID” field indicates that the device is for VME products (00) and indicates the supported embedded feature set. The “Vender ID” and “Subsystem Vendor ID” fields indicate VMIC’s PICMG assigned Vender ID (114A). The “Subsystem ID” field indicates the model number of the product (7750).

  • Page 57: Timers

    Timers Timers General The VMIVME-7750 provides four user-programmable timers (two 16-bit and two 32-bit) which are completely dedicated to user applications and are not required for any standard system function. Each timer is clocked by independent generators with selectable rates of 2MHz, 1MHz, 500kHz and 250kHz. Each timer may be independently enabled and each is capable of generating a system interrupt on timeout.

  • Page 58: Timer Control Status Register 2 (Tcsr2)

    VMIVME-7750 Product Manual Each timer has an independently selectable clock source which is selected by the bit pattern in the “Timer x Clock Select” field as follows: Clock Rate 2MHz 1MHz 500kHz 250kHz Each timer can be independently enabled by writing a “1” to the appropriate “Timer x Enable”...

  • Page 59: Timer 1 & 2 Load Count Register (Tmrlcr12)

    Timers result, it is not possible to capture the values of all four timers at a given instance in time. However, by setting this bit to “1”, all four timer outputs will be latched only on reads to the Timer 1 & 2 Current Count Register (TMRCCR12). Therefore, to capture the current count of all four timers at the same time, perform a read to the TMRCCR12 first (with a 32-bit read), followed by a read to TMRCCR3 and TMRCCR4.

  • Page 60: Timer 4 Load Count Register (Tmrlcr4)

    VMIVME-7750 Product Manual Timer 4 Load Count Register (TMRLCR4) Timer 4 is 32-bits wide and obtains its load count from the Timer 4 Load Count Register (TMRLCR4), located at offset 0x18 from the address in BAR2. The mapping of bits in this register are as follows:...

  • Page 61: Timer 4 Current Count Register (Tmrccr4)

    Timers When this field is read, the current count value is latched and returned. There are two modes that determine how the count is latched depending on the setting of the “Read Latch Select” bit in the WDT Control Status Register (CSR2). See the CSR2 register description for more information on these two modes.

  • Page 62: Timer 4 Irq Clear (T4Ic)

    VMIVME-7750 Product Manual Timer 4 IRQ Clear (T4IC) The Timer 4 IRQ Clear (T4IC) register is used to clear an interrupt caused by Timer 4. Writing to this register, located at offset 0x3C from the address in BAR2, causes the interrupt from Timer 4 to be cleared.

  • Page 63: Watchdog Timer

    Watchdog Timer Watchdog Timer General The VMIVME-7750 provides a programmable Watchdog Timer (WDT) which can be used to reset the system if software integrity fails. WDT Control Status Register (WCSR) The WDT is controlled and monitored by the WDT Control Status Register (WCSR) which is located at offset 0x08 from the address in BAR2.

  • Page 64: Wdt Keepalive Register (Wkpa)

    VMIVME-7750 Product Manual The “WDT Enable” bit is used to enable the Watchdog Timer function. This bit must be set to “1” in order for the Watchdog Timer to function. Note that since all registers default to zero after reset, the Watchdog Timer is always disabled after a reset. The Watchdog Timer must be re-enabled by the application software after reset in order for the Watchdog Timer to continue to operate.

  • Page 65: Nvsram

    PCI bus. The contents of this memory is retained when the power to the board is removed. VME Control The following table shows the register definitions for the VMIVME-7750 (offset from BAR0). Table 3-3 Register Definitions Offset From BAR0 Register Name...
  • Page 66 VMIVME-7750 Product Manual Table 3-3 Register Definitions Offset From BAR0 (Continued) Register Name Offset Unused Not Used BPENA Endian conversion bypass bit 1=Bypass 0=Not bypassed ECENA Endian conversion bit 1= Enabled 0=Disabled Unused 31:12 Not Used VBAR 0x04 VME_ADDR Latched VME Address...

  • Page 67: Flash Disk

    Flash Disk. Configuration The Flash Disk resides on the VMIVME-7750 as the secondary IDE bus master device (the secondary IDE bus slave device is not assignable). The default setting in the Phoenix BIOS ‘STANDARD CMOS SETUP’ screen is the ‘AUTO’ setting. In the Phoenix BIOS ‘PERIPHERAL SETUP’...

  • Page 68: Functionality

    Following the creation of the partitioning scheme, the partitions can be formatted to contain the desired file system. As discussed earlier, a typical system consists of the VMIVME-7750 with its resident Flash Disk configured as the Secondary IDE device, a hard drive attached to the Primary IDE interface, and a floppy drive attached to the floppy interface.
  • Page 69 Flash Disk 3. Set Flash Disk Master to “AUTO”. 4. Set boot device to floppy. 5. Boot DOS from the floppy, and verify that the System Configuration Screen shows only the Flash Disk. 6. Run FDISK. 7. Delete all current partitions (any data currently stored in the partitions will be lost).

  • Page 70: Remote Ethernet Booting

    VMIVME-7750 Product Manual Remote Ethernet Booting The VMIVME-7750 is capable of booting from a server using either LAN1 or LAN2 over a network utilizing Lanworks BootWare BIOS. The BootWare BIOS gives you the ability to remotely boot the VMIVME-7750 using a variety of network protocols. The Ethernet must be connected through either LAN front panel (RJ-45) connector to boot remotely.

  • Page 71: Chapter 4 - Maintenance

    8. Quality of cables and I/O connections If products must be returned, contact VMIC for a Return Material Authorization (RMA) Number. This RMA Number must be obtained prior to any return. VMIC Customer Service is available at: 1-800-240-7782.
  • Page 72 VMIVME-7750 Product Manual...

  • Page 73: Appendix A - Connector Pinouts

    PMC Connector Pinout ..........81 Introduction The VMIVME-7750 VMEbus SBC has several connectors for its I/O ports. Wherever possible, the VMIVME-7750 uses connectors and pinouts typical for any desktop PC.

  • Page 74: Vmebus Connector Pinout

    Figure A-1 shows the location of the VMEbus P1 and P2 connectors and their orientation on the VMIVME-7750. Table A-1 shows the pin assignments for the VMEbus connectors. Note that only Row B of connector P2 is used; all other pins on P2 are reserved and should not be connected.
  • Page 75 VMEbus Connector Pinout Table A-1 VMEbus Connector Pinout (bottom board) (Continued) PIN # P1 ROW A P1 ROW B P1 ROW C P2 ROW Z P2 ROW A P2 ROW B P2 ROW C P2 ROW D SIGNAL SIGNAL SIGNAL SIGNAL SIGNAL SIGNAL...

  • Page 76: Serial Connector Pinout

    VMIVME-7750 Product Manual Serial Connector Pinout Each standard RS-232 serial port connector is a Microminiature D9 male as shown in Figure A-2. Adapters to connect standard D9 serial peripherals to the board are available. Please refer to the product specification sheet for ordering information.

  • Page 77: Usb Connector

    USB Connector USB Connector The dual USB port uses an industry standard dual 4 position shielded connector. Figure A-3 shows the pinout of the dual USB connector. USB1 & 2 CONNECTOR SIGNAL FUNCTION USBV USB Power USB- USB Data - USB+ USB Data + USBG...

  • Page 78: Ethernet Connector Pinout (J4 And J5)

    VMIVME-7750 Product Manual Ethernet Connector Pinout (J4 and J5) The pinout diagram for the Ethernet 10BaseT and 100BaseTx connector is shown in Figure A-4. ETHERNET CONNECTOR (10BaseT, 100BaseTx) Signal Name Transmit Data Transmit Data Receive Data TX_CT_OUT Transmit Center Tap Out...

  • Page 79: Video Connector Pinout

    Video Connector Pinout Video Connector Pinout The video port uses a standard high-density DB15 SVGA connector. Figure A-5 illustrates the pinout. VIDEO CONNECTOR DIRECTION FUNCTION Green Blue Reserved Ground Ground Ground Ground Ground Reserved DDC Data Horizontal Sync Vertical Sync DDC Clock Shield Chassis Ground...

  • Page 80: Keyboard And Mouse Connectors And Pinout (J7)

    Ground +5 V Mouse Clock Keyboard Clock Shield Chassis Ground *An adapter cable is included with the VMIVME-7750 to separate the keyboard and mouse connector. Figure A-6 Keyboard/Mouse Connector and Pinout Table A-2 Keyboard/Mouse Y Splitter Cable Keyboard Mouse Function...

  • Page 81: Pmc Connector Pinout

    PMC Connector Pinout PMC Connector Pinout PMC #1 (J1) Connector and Pinout Table A-3 PMC #1 (J1) Connector Pinout PMC Connector (J1) PMC Connector (J1) Left Side Right Side Left Side Right Side Name Name Name Name +12 V +5 V TRDY +3.3 V +5 V...

  • Page 82: Pmc #1 (J2) Connector And Pinout

    VMIVME-7750 Product Manual PMC #1 (J2) Connector and Pinout The PCI Mezzanine Card (PMC) carries the same signals as the PCI standard; however, the PMC standard uses a completely different form factor. Tables A-4 through A-3 are the pinouts for the PMC connectors (J1 and J2).

  • Page 83: Pmc #1 (J3) Connector And Pinout

    PMC Connector Pinout PMC #1 (J3) Connector and Pinout Table A-5 PMC #1 (J3) Connector Pinout PMC Connector (J3) PMC Connector (J3) Left Side Right Side Left Side Right Side Connected Connected Connected Connected Name Name Name Name CONN[1] P2 pin D1 CONN[2] P2 pin Z1 CONN[33]...
  • Page 84 VMIVME-7750 Product Manual...

  • Page 85: Appendix B - System Driver Software

    LAN operation is provided by an Intel GD82559ER Fast Ethernet adapter chip (LAN1) and the embedded Intel 815E chipset (LAN2). The two LAN adapters can be configured to allow the VMIVME-7750 to access two separate, physical networks. Each LAN adapter is capable of running 10BaseT and 100BaseTx.

  • Page 86: Using Usb Keyboard/Mouse With Microsoft Windows Operating Systems

    VMIVME-7750 Product Manual Using USB Keyboard/Mouse with Microsoft Windows Operating Systems This section applies if either a USB keyboard or USB mouse is connected. It does not apply if a PS/2 keyboard and mouse are used. Windows 98SE/Windows 2000 The use of a USB keyboard/mouse with an operating system that supports USB devices requires changing the default BIOS settings before and after the installation of Windows 98SE/2000.

  • Page 87: Bios Setup

    BIOS Setup BIOS Setup To enable/disable Legacy USB Support and/or assign a interrupt to the USB controllers, perform the appropriate actions as outlined below: 1. Immediately after the CPU has been powered on or reset, press to enter the ‘PhoenixBIOS Setup Utility’. 2.

  • Page 88: Microsoft Windows 98Se Software Driver Installation

    VMIVME-7750 Product Manual Microsoft Windows 98SE Software Driver Installation 1. Prior to installing Windows 98SE, ensure the BIOS is set to assign an interrupt to the USB controller. Also ensure ‘Installed O/S’ is set to ‘Win98/Win2000’. See “BIOS Setup” on page 87 for guidelines on changing BIOS settings.

  • Page 89: Video Driver Installation

    Microsoft Windows 98SE Software Driver Installation 2. Click ’Start’, ‘Run’, ‘Browse’. In the ‘Look in’ pull-down selection menu, select the ‘Windows Drivers’ CD-ROM. Double-click on the ‘Win98’ folder. Double-click on the ‘UltraATA’ folder. Double-click on ’UltraATA’. Click ‘OK’. 3. At the ‘Intel Ultra ATA Storage Driver 6.1 Setup’ window, click ‘Next’. Click ‘Yes’ to agree to the license agreement.

  • Page 90: Ethernet Adapter Drivers Installation

    VMIVME-7750 Product Manual Ethernet Adapter Drivers Installation 1. Insert the Windows 98SE installation CD-ROM. Insert the ‘LAN1: Intel(R) GD82259ER Fast Ethernet Adapter’ floppy disk. 2. Right-click on ‘My Computer’ and select ‘Properties’. Click on the ‘Device Manager’ tab. 3. Select the first ‘PCI Ethernet Controller’ (found under ‘Other devices’) and click ‘Properties’.

  • Page 91: Microsoft Windows Ntw 4.0 Software Driver Installation

    Microsoft Windows NTW 4.0 Software Driver Installation Microsoft Windows NTW 4.0 Software Driver Installation 1. Follow the normal Windows NTW 4.0 installation until the Windows NT Workstation Setup window that states ‘Windows NT needs to know how this computer should participate on a network.’ 2.

  • Page 92: Ethernet Adapter Drivers Installation

    VMIVME-7750 Product Manual 2. If not already present, insert the ‘Windows Drivers’ CD-ROM. Click ‘Start’, ‘Run’, ‘Browse’. In the ‘Look in’ pull-down selection menu, select the ‘Win_drivers’ CD-ROM. Double-click on the ‘WinNT’ folder. Double-click on the ‘Lan1’ folder. Double-click on ‘Makedisk’. Click ‘OK’.
  • Page 93 Microsoft Windows NTW 4.0 Software Driver Installation driver disks as required by Windows NT Networking installation. Provide data relative to the network configurations. 15. At ‘Network Settings Change’ window, remove the floppy disk and CD-ROM and click ‘Yes’ to restart the computer. 16.

  • Page 94: Microsoft Windows 2000 Software Driver Installation

    VMIVME-7750 Product Manual Microsoft Windows 2000 Software Driver Installation 1. Prior to installing Windows 2000, ensure the BIOS is set to assign an interrupt to the USB controller. Also ensure ‘Installed O/S’ is set to ‘Win98/Win2000’. See “BIOS Setup” on page 87 for guidelines on changing BIOS settings.

  • Page 95: Ethernet Adapter Drivers Installation

    Microsoft Windows 2000 Software Driver Installation 2. Click ‘Start’, ‘Run’, ‘Browse’. In the ‘Look in’ pull-down selection menu, select the Windows Drivers CD-ROM. Double-click on the ‘Win2000’ folder. Double-click on the ‘Video’ folder. Double-click on ‘Setup’. Click ‘OK’. 3. At the ‘Intel(R) 810/810E/815/815E/815EM Chipset Graphics Drivers’ window, click ‘Next’.

  • Page 96: Status Of Pci Devices Listed In Windows Device Manager

    Manager will still indicate that several PCI devices do not have drivers loaded. In the sample screen shot shown in Figure B-1, the two devices listed under “Other devices” are the Tundra Universe IIB PCI-to-VMEbus bridge and the VMIC proprietary FPGA. The second USB controller is present but not utilized. Although these devices are listed as non-functioning by Windows, the hardware is functioning as designed.

  • Page 97: Appendix C - Phoenix Bios

    Exit Menu ............111 Introduction The VMIVME-7750 utilizes the BIOS (Basic Input/Output System) in the same manner as other PC/AT compatible computers. This appendix describes the menus and options associated with the VMIVME-7750 BIOS.

  • Page 98: First Boot

    VMIVME-7750 Product Manual First Boot The VMIVME-7750 has a First Boot menu enabling the user to, on a one time basis, select a drive device to boot from. This feature is useful when installing from a bootable disk. For example, when installing Windows NT from a CD, enter the First Boot menu and use the arrows keys to highlight ATAPI CD-ROM Drive.

  • Page 99: Main Menu

    Main Menu Main Menu The Main menu allows the user to select QuickBoot, set the system clock and calendar, record disk drive parameters, and set selected functions for the keyboard. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ H6DI 6q‰hprq Trpˆ…v‡’ Q‚r… 7‚‚‡ @‘v‡ D‡r€ÃTƒrpvsvpÃCryƒ Rˆvpx7‚‚‡ÃH‚qr) b@hiyrqd T’†‡r€ÃUv€r) )&)#%d 6yy‚†Ã‡urÆ’†‡r€Ã‡‚...

  • Page 100: Legacy Diskette

    The VMIVME-7750 does not support a second floppy drive. The default is Disabled. Primary Master/Slave The VMIVME-7750 is capable of utilizing two IDE devices on the Primary Master bus. The default setting is Auto. The Primary Slave is assigned to the CD-ROM (if installed).

  • Page 101: Secondary Master

    Main Menu Secondary Master The Secondary Master is the resident Compact Flash Disk (if installed). The default setting is Auto. Keyboard Features The Keyboard Features allows the user to set several keyboard functions. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ H6DI D‡r€ÃTƒrpvsvpÃCryƒ Fr’i‚h…qÃArh‡ˆ…r† Tryrp‡†ÃQ‚r…‚Ã†‡h‡r Iˆ€G‚px) b6ˆ‡‚d s‚…ÃIˆ€G‚px Fr’Ã8yvpx) b9v†hiyrqd...

  • Page 102: Keyboard Auto-Repeat Delay (Sec)

    VMIVME-7750 Product Manual Keyboard Auto-Repeat Delay (sec) If the Key Click is enabled, this determines the delay before a character starts repeating when a key is held down. The options are: 1/4, 1/2, 3/4 or 1 second. The default is 1/2.

  • Page 103: Com Port Address

    Main Menu Com Port Address If enabled, it will allow remote access through the serial port. The options are: Disabled, Motherboard Com A and Motherboard Com B. The default is Disabled. Baud Rate Selects a baud rate for the serial port. The options are: 600, 1200, 2400, 4800, 9600, 19.2, 38.4 and 115.2.

  • Page 104: Advanced Menu

    VMIVME-7750 Product Manual Advanced Menu Selecting Advanced from the Main menu will display the screen shown below. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ 69W6I8@9 Hhv Trpˆ…v‡’ Q‚r… 7‚‚‡ @‘v‡ D‡r€ÃTƒrpvsvpÃCryƒ D†‡hyyrqÃPT) bP‡ur…d Sr†r‡Ã8‚svtˆ…h‡v‚Ã9h‡h bI‚d Tryrp‡Ã‡urƒr…h‡vt # 8hpurÃHr€‚…’ †’†‡r€Ãv†‡hyyrq # DPÃ9r‰vprÃ8‚svtˆ…h‡v‚ ‚Ã’‚ˆ…Æ’†‡r€Ãuvpu Gh…trÃ9v†xÃ6ppr††ÃH‚qr) b9PTd ’‚ˆÃvyyȆrÀ‚†‡ G76Ã6††v†‡rqÃU…h†yh‡v‚...

  • Page 105: I/O Device Configuration

    Advanced Menu Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ 69W6I8@9 D‡r€ÃTƒrpvsvpÃCryƒ 8hpurÃHr€‚…’ Tr‡†Ã‡urƇh‡rÂsÇur Hr€‚…’Ã8hpur b@hiyrqd €r€‚…’Ãphpur 8hpurÃT’†‡r€Ã7DPTÃh…rh) bX…v‡rÃQ…‚‡rp‡d 8hpurÃWvqr‚Ã7DPTÃh…rh) bX…v‡rÃQ…‚‡rp‡d 8hpurÃ7h†rÃ$ !x) bX…v‡rÃ7hpxd 8hpurÃ7h†rÃ$ !x%#x) bX…v‡rÃ7hpxd 8hpurÃ@‘‡rqrqÃHr€‚…’Ã6…rh) bX…v‡rÃ7hpxd 8hpurÃ66AAA) b9v†hiyrqd 8hpurÃ77AAA) b9v†hiyrqd 8hpurÃ8'87AA) bX…v‡rÃUu…‚ˆtud 8hpurÃ888AAA) bX…v‡rÃUu…‚ˆtud 8hpurÃ99"AA) bX…v‡rÃUu…‚ˆtud 8hpurÃ9#9&AA) bX…v‡rÃUu…‚ˆtud 8hpurÃ9'97AA) bX…v‡rÃUu…‚ˆtud 8hpurÃ989AAA bX…v‡rÃUu…‚ˆtud A Cryƒ Tryrp‡ÃD‡r€8uhtrÃWhyˆr†A(Tr‡ˆƒÃ9rshˆy‡†...

  • Page 106: Large Disk Access Mode

    VMIVME-7750 Product Manual Large Disk Access Mode The options for the Large Disk Access Mode are UNIX Novell Netware or Other. If you are installing new software and the drive fails, change this selection and try again. Different operating systems require different representations of drive geometries.

  • Page 107: Default Primary Video Adapter

    Default Primary Video Adapter Select ‘PCI’ to have a PCI video card, if installed, used for the boot display device. Do not select ‘AGP’ as the VMIVME-7750 does not support AGP. Graphics Aperture Select the size of the graphics aperture for the AGP video device. The options are: 4MB, 8MB, 16MB, 32MB, 64MB, 128MB or 256MB.

  • Page 108: Security

    VMIVME-7750 Product Manual Security Utilize this screen to set a user password. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ Trpˆ…v‡’ D‡r€ÃTƒrpvsvpÃCryƒ Trpˆ…v‡’ Tˆƒr…‰v†‚…ÃQh††‚…q ÃÃÃTr‡ÃV†r…ÃQh††‚…q bÃ@‡r…Ãd p‚‡…‚y†Ã6ppr††Ã‡‚Çur ÃTr‡ÃTˆƒr…‰v†‚…ÃQh††‚…q b@‡r…d †r‡ˆƒÃˆ‡vyv‡’ !ÃQh††‚…qÃi‚‚‡) b9v†hiyrqd "ÃAv‘rqÃqv†xÃi‚‚‡Ã†rp‡‚… bI‚…€hyd #Ã9v†xr‡‡rÃhppr††)ÃÃà bV†r…d $ÃWv…ˆ†ÃpurpxÃ…r€vqr…) b9v†hiyrqd %ÃT’†‡r€ÃihpxˆƒÃ…r€vqr…) b9v†hiyrqd A Cryƒ Tryrp‡ÃD‡r€8uhtrÃWhyˆr†A(Tr‡ˆƒÃ9rshˆy‡† ↑ ↓ @T8@‘v‡ Tryrp‡ÃHrˆ@‡r…Tryrp‡Ã#ÃTˆiHrˆA Th‰rÃhqÃ@‘v‡...

  • Page 109: Power

    Power Power This screen, selected from the Main screen, allows the user to configure power saving options on the VMIVME-7750. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ QPX@S Hhv 6q‰hprq Trpˆ…v‡’ 7‚‚‡ @‘v‡ D‡r€ÃTƒrpvsvpÃCryƒ 8QVÃUu…‚‡‡yvtÃ9‚ÃUu…r†u‚yq b9v†hiyrqd 8QVÃUu…‚‡‡yvtÃihpxÃu’†‡r…r†v† b 8d Hh‘v€ˆ€ÃQ‚r…Æh‰vt† Uu…‚‡‡yvtÃÈ b$Èd p‚†r…‰r†Ã‡urÃt…rh‡r†‡ h€‚ˆ‡Ã‚sÆ’†‡r€Ãƒ‚r… Q‚r…ÃTh‰vt†) b9v†hiyrqd Hh‘v€ˆ€ÃQr…s‚…€hpr...

  • Page 110: Boot Menu

    VMIVME-7750 Product Manual Boot Menu The Boot priority is determined by the stack order, with the top having the highest priority and the bottom the least. The order can be modified by highlighting a device and, using the <+> or <-> keys, moving it to the desired order in the stack. A device can be boot disabled by highlighting the particular device and pressing <Shift 1>.

  • Page 111: Exit Menu

    Exit Menu Exit Menu The Exit menu allows the user to exit the BIOS program, while either saving or discarding any changes. This menu also allows the user to restore the BIOS defaults if desired. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ @‘v‡ Hhv 6q‰hprq Q‚r… 7‚‚‡...
  • Page 112 VMIVME-7750 Product Manual...

  • Page 113: Appendix D - Lanworks Bios

    BIOS Features Setup ..........116 Introduction The VMIVME-7750 includes a LANWorks option which allows the VMIVME-7750 to be booted from a network. This appendix describes the procedures to enable this...

  • Page 114: Boot Menus

    First Boot menu. Selecting “Managed PC Boot Agent (MBA)” to boot from the LAN in this screen applies to the current boot only, at the next reboot the VMIVME-7750 will revert back to the setting in the Boot menu.
  • Page 115 Boot Menus Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ 7‚‚‡ H6DI 6q‰hprq Trpˆ…v‡’ Q‚r… @‘v‡ D‡r€ÃTƒrpvsvpÃCryƒ H76ÃVI9DÃ7ˆ†ÃTy‚‡Ã%ÃG6Ià ÃSr€‚‰hiyrÃ9r‰vpr†) Fr’†Ãˆ†rqÇ‚ÉvrÃ‚… ÃCh…qÃ9…v‰r p‚svtˆ…rÃqr‰vpr†) ÃÃ6U6QDÃ89SPHÃ9…v‰r 1@‡r…3Ãr‘ƒhq†Ã‚… ÃSr€‚‰hiyrÃ9r‰vpr†) p‚yyhƒ†r†Ãqr‰vpr†Ãv‡u H76ÃVI9DÃ7ˆ†ÃTy‚‡Ã'ÃG6IÃ! hÃÂ…Ã 18‡…yÃÃ@‡r…3Ãr‘ƒhq† 1Tuvs‡Ãà 3Ãrhiyr†Ã‚… qv†hiyr†ÃhÃqr‰vpr 13ÃhqÃ13À‚‰r†Ã‡urà qr‰vprȃÂ…Ãq‚ 13Àh’À‚‰rÃ…r€‚‰hiyr qr‰vprÃir‡rrÃCh…qà 9v†xÂ…ÃSr€‚‰hiyrÃ9v†x 1q3Ã…r€‚‰rÃhÃqr‰vpr ‡uh‡Ãv†Ã‚‡Ãv†‡hyyrq A Cryƒ Tryrp‡ÃD‡r€8uhtrÃWhyˆr†A(Tr‡ˆƒÃ9rshˆy‡† ↑ ↓ @T8@‘v‡ Tryrp‡ÃHrˆ@‡r…Tryrp‡Ã#ÃTˆiHrˆA Th‰rÃhqÃ@‘v‡ ←...

  • Page 116: Bios Features Setup

    VMIVME-7750 Product Manual BIOS Features Setup After the Managed PC Boot Agent has been enabled, there are several boot options available to the user. These options are RPL (default), TCP/IP, Netware and PXE. The screens below show the defaults for each boot method.

  • Page 117: Netware

    BIOS Features Setup Netware HhhtrqÃQ8Ã7‚‚‡Ã6tr‡ÃH76É"!Ã7DPTÃD‡rt…h‡rq pÃ8‚ƒ’…vtu‡Ã (('ÃG6IX‚…x†ÃUrpu‚y‚tvr†Ã8‚Ãhƈi†vqvh…’ÂsÃ"8‚€Ã8‚…ƒ‚…h‡v‚ 6yyÃ…vtu‡†Ã…r†r…‰rq 8‚svtˆ…h‡v‚ 7‚‚‡ÃHr‡u‚q) Ir‡h…r Q…‚‡‚p‚y '!! 8‚svtÃHr††htr) @hiyrq Hr††htrÃUv€r‚ˆ‡) %ÃTrp‚q† 7‚‚‡Ãshvyˆ…rÃQ…‚€ƒ‡) Xhv‡Ãs‚…Ãxr’ 7‚‚‡ÃAhvyˆ…r) Ir‘‡Ã77TÃqr‰vpr V†rÃpˆ…†‚…Ãxr’†Ã‡‚Ãrqv‡)ÃVƒ9‚ÃpuhtrÃsvryqÃGrs‡Svtu‡ÃpuhtrÉhyˆr @T8ǂĈv‡ÃA(Ã…r†‡‚…rÃ…r‰v‚ˆ†Ã†r‡‡vt†ÃA Ç‚Æh‰r HhhtrqÃQ8Ã7‚‚‡Ã6tr‡ÃH76É"!Ã7DPTÃD‡rt…h‡rq pÃ8‚ƒ’…vtu‡Ã (('ÃG6IX‚…x†ÃUrpu‚y‚tvr†Ã8‚Ãhƈi†vqvh…’ÂsÃ"8‚€Ã8‚…ƒ‚…h‡v‚ 6yyÃ…vtu‡†Ã…r†r…‰rq 8‚svtˆ…h‡v‚ 7‚‚‡ÃHr‡u‚q) V†rÃpˆ…†‚…Ãxr’†Ã‡‚Ãrqv‡)ÃVƒ9‚ÃpuhtrÃsvryqÃGrs‡Svtu‡ÃpuhtrÉhyˆr @T8ǂĈv‡ÃA(Ã…r†‡‚…rÃ…r‰v‚ˆ†Ã†r‡‡vt†ÃA Ç‚Æh‰r...
  • Page 118 VMIVME-7750 Product Manual...

  • Page 119: Appendix E - Sample C Software

    This directory contains code used to setup the Universe IIB chip with one PCI-to-VME window and enable Universe IIB registers to be accessed from the VMEbus to allow mailbox access. Directory \fpga This directory contains code used to test the functions of the VMIC-designed FPGA such as timers, SRAM controller and Watchdog Timer.

  • Page 120: Directory \I2C

    This directory contains memory and PCI access routines used by many of the sample code applications. Directory \vlm This directory contains code that demonstrates how to read the voltages from the analog inputs of the super I/O component on the VMIVME-7750.
  • Page 121 Index Numerics Intel 82559 Ethernet Controller Intel programmers 50, 78 100BaseTx interrupt line assignment 50, 78 10BaseT jumper locations 31, 46 BIOS BIOS setup screens LPT1 Parallel I/O LPT2 Parallel I/O CMOS configuration connectors CPU board diagram Customer Service master interrupt controller memory address map Motorola programmers DMA controller...
  • Page 122 VMIVME-7750 Product Manual 39, 43 real mode real-time clock Return Material Authorization (RMA) number Serial I/O (COM1,2,3 & 4) serial port connector, D9 or RJ45 SERR interrupt SIZE SVGA connector System BIOS Setup Utility unpacking procedures USB port connector vector interrupt table...

Table of Contents
