GREAT PLAINS 3S-3000-3210 Operator's Manual

3-section 30-foot folding drill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Table of Contents
Read the operator manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit or
may depict similar models where a topic is identical.
ORIGINAL INSTRUCTIONS
© Copyright 2017
Table of Contents
Index
Operator Manual
3S-3000/F/HD/HDF
3-Section 30-Foot Folding Drill
Manufacturing, Inc.
www.greatplainsmfg.com
Printed 2018-06-18
Index
15485
EN
195-441M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3S-3000-3210 and is the answer not in the manual?

Questions and answers

Related Manuals for GREAT PLAINS 3S-3000-3210

Summary of Contents for GREAT PLAINS 3S-3000-3210

  • Page 1 Table of Contents Index Operator Manual 3S-3000/F/HD/HDF 3-Section 30-Foot Folding Drill Manufacturing, Inc. www.greatplainsmfg.com Read the operator manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! 15485 Illustrations may show optional equipment not supplied with standard unit or may depict similar models where a topic is identical.
  • Page 2 Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you or the dealer have added options not originally ordered with the machine, or removed options that were originally ordered, the weights and measurements are no longer accurate for your machine.

  • Page 3: Table Of Contents

    Great Plains Manufacturing, Inc. provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been taken in the preparation of this manual, Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein.
  • Page 4 3S-3000/F/HD/HDF Cover Index Table of Contents Chain Maintenance............67 Calibration Tray ...............93 Chain Slack ..............67 Digital Scale ..............93 Bleeding Hydraulics............68 Small Seeds Attachment ..........93 Bleeding Opener Lift Hydraulics.......70 Removable Partition ............94 Bleeding Transport Lift Hydraulics ......71 Seed Tube Plug (Small Seeds) ........94 Bleeding Marker Hydraulics ........72 Opener Disk Scraper............94 In-Line Filters..............73...

  • Page 5: Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Important Safety Information Look for Safety Symbol The SAFETY ALERT SYMBOL indicates there is a potential hazard to personal safety involved and extra safety precaution must be taken. When you see this symbol, be alert and carefully read the message that follows it.

  • Page 6: Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Avoid High Pressure Fluids Escaping fluid under pressure can penetrate the skin, causing serious injury.  Avoid hazard relieving pressure before disconnecting hydraulic lines.  Use a piece of paper or cardboard, NOT BODY PARTS, to check for suspected leaks.

  • Page 7: Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Transport Machinery Safely Maximum transport speed for drill is 20 mph (32 kph). Some rough terrains require a slower speed. Sudden braking can cause a towed load to swerve and upset.  Do not exceed 20 mph (32 kph). Never travel at a speed which does not allow adequate control of steering and stopping.

  • Page 8: Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Handle Chemicals Properly Agricultural chemicals can be dangerous. Improper use can seriously injure persons, animals, plants, soil and property.  Do not use liquid treatments with drill.  Read and follow chemical manufacturer’s instructions. ...

  • Page 9: Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Tire Safety Tire changing can be dangerous and should be performed by trained personnel using correct tools and equipment.  When inflating tires, use a clip-on chuck and extension hose long enough for you to stand to one side–not in front of or over tire assembly.

  • Page 10: Safety Decals

     Keep all safety decals clean and legible.  Replace all damaged or missing decals. Order new decals from your Great Plains dealer. Refer to this section for proper decal placement.  When ordering new parts or components, also request corresponding safety decals.

  • Page 11: Table Of Contents Index Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Red Reflectors (S/N S3495-) 26496 838-266C On wing walkboard inside end faces; 2 total Red Reflectors (S/N S3496+) 68447A 838-266C On wing walkboard inside end faces, on brackets at rear of center walkboard on each end; 4 total Amber Reflectors (S/N S3495-) 26496...

  • Page 12: Table Of Contents Index Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Amber Reflectors (S/N S3496+) 68447B 838-265C On bracket at rear of wing walkboard at each end, on outside end face of wing walkboards, on end faces of center walkboard; 8 total Daytime Reflectors (S/N S3495-) 26496 838-267C On outside end faces of center walkboard, inboard of red...

  • Page 13: Table Of Contents Index Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Danger: Read Manual 848-512C WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov On tongue at hitch; 1 total 26496A Danger: Possible Chemical Hazard 838-467C Inside lid of optional Small Seeds box left-hand side, one each box;...

  • Page 14: Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Warning: Pinch/Crush Hazard 818-045C On tongue near transport hooks; 1 total 26496B Warning: Excessive Speed Hazard 818-337C On tongue near hitch; 1 total 26496A Warning: High Pressure Fluid 818-339C On tongue near hitch; 1 total 26496A 2018-06-18...
  • Page 15 3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Warning: Transport Locks 18-660C WARNING On tongue near transport hooks, on back of wing tool bar (outside when folded); 3 total 26496B Warning: Marker Pinch Crush 818-682C 26497 On front and outside faces of first marker section, two each marker installed;...

  • Page 16: Table Of Contents Index Important Safety Information

    3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Caution: General 818-078C CAUTION On tongue near hitch; 1 total 26496A Caution: Tires Not A Step 818-398C On each axle leg (transport wheels); 2 total 26496 Caution: 60 psi Tire Pressure (Skid Steer Tires) 838-092C On rim of each wheel;...
  • Page 17 3S-3000/F/HD/HDF Table of Contents Index Important Safety Information Caution: 32 psi Tire Pressure (Rib Implement Tires) 818-751C CAUTION To Avoid Injury or Machine Damage from Improper Tire Inflation or Torquing of Wheel Bolts: Maximum inflation pressure of tires is 32 psi. Torque wheel bolts to 90 lb-ft.

  • Page 18: Document Family

    Table of Contents Index Introduction Introduction Great Plains welcomes you to its growing family of new product owners. Your 30-Foot Three-Section Folding Drill has been designed with care and built by skilled workers using quality materials. Proper setup, maintenance, and safe operating practices will help you get years of satisfactory use from the machine.

  • Page 19: Refer To Figure

    Refer to Figure 2 Your machine’s parts were specially designed and should only be replaced with Great Plains parts. Always use the serial and model number when ordering parts from your Great Plains dealer. The serial-number plate is located on the left side of the drill frame below the front of the seed box.

  • Page 20: Owner Assistance

    Plains products. Refer to Figure 3 Your machine’s parts were specially designed and should only be replaced with Great Plains parts. Always use the serial and model number when ordering parts from your Great Plains dealer. The serial-number plate is located on the left side of the drill frame below the front of the seed box.

  • Page 21: Preparation And Setup

    3S-3000/F/HD/HDF Table of Contents Index Preparation and Setup Preparation and Setup This section helps you prepare your tractor and drill for use. Before using the drill in the field, you must hitch the drill to a suitable tractor and also setup the drill. Pre-Setup Checklist ...
  • Page 22 3S-3000/F/HD/HDF Table of Contents Index Preparation and Setup Refer to Figure 4 and Figure 5 1. Adjust the drill hitch to match your tractor-drawbar height. Mount tongue jack on side of tongue. Use jack to raise drill tongue so lowest hitch hole is 18 inches (45.7cm) above ground level with drill lowered to FIELD position.

  • Page 23: Shaft Monitor

    3S-3000/F/HD/HDF Table of Contents Index Preparation and Setup Electrical Connections Refer to Figure 7 Plug drill electrical lead into tractor seven-pin connector. If your tractor is not equipped with a seven-pin connector, contact your dealer for installation. Figure 7 26467 Lighting Connector Refer to Figure 8 If the drill is equipped with the optional shaft monitor,...

  • Page 24: Hydraulic Hose Hookup

    Hoses with a retracted-cylinder symbol feed cylinder rod tractors with fixed-displacement hydraulic pumps, you must ends. install a Great Plains kit, part number 194-143A. If you are 1. Connect opener-lift hoses to circuit designated for not familiar with your tractor hydraulics, consult your tractor hydraulic-motor control.

  • Page 25: Setting The Bypass Valve

    3S-3000/F/HD/HDF Table of Contents Index Preparation and Setup Setting the Bypass Valve Refer to Figure 11 A bypass valve is plumbed into the opener down pressure circuit. Tractors with load-sensing, closed-center hydraulics require this bypass valve to protect the tractor hydraulic system. If you are unsure what type of hydraulic system is on your tractor, contact your tractor manufacturer.
  • Page 26 3S-3000/F/HD/HDF Table of Contents Index Preparation and Setup Refer to Figure 11 on page 21 and Figure 12 at right 4. Release locking discs on down-pressure valves. Adjust knobs on pressure-control valves for opener down pressure so gauges are at: 1800 psi for 3S-3000/F models 2100 psi for 3S-3000HD/HDF models 5.

  • Page 27: Operating Instructions

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Operating Instructions This section covers general operating procedures. It assumes that setup items have been completed for both drill and tractor. Experience, machine familiarity and the following information will lead to efficient operation and good working habits.

  • Page 28: Pre-Start Checklist

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Pre-Start Checklist  Lubricate the drill as indicated under Lubrication, “Maintenance and Lubrication” on page 65.  Check the tires for proper inflation according to “Hydraulic Diagrams” on page 99.  Check for worn or damaged parts and repair or replace before going to the field.

  • Page 29: Folding

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Unlock Openers Refer to Figure 14 1. Position opener transport lock handles in FIELD position. 2. Raise openers completely. Figure 14 15548 Opener Unlock Folding Crushing Hazard: Bystanders could be crushed between the folding drill boxes and the drill tongue.

  • Page 30: Transport Hooks

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions 4. Make sure transport lift cylinders and front box lift cylinder are completely retracted (drill is lowered, although openers are raised). 5. Slowly supply oil to rod (retract) end of fold circuit. Completely fold wing frames until both wing gauge wheels contact tongue tube.

  • Page 31: Transport Lift

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Transport Lift 1. Fold the drill (unless this lift is for maintenance or adjustment). See “Folding” on page 25. 2. If the Two Outlet conversion kit is installed, a selector valve near the hitch must be operated to switch between Transport Lift and Opener Lift.

  • Page 32: Drill Weight

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Transport Loss of Control Hazard: Towing the drill at high speeds or with a vehicle that is not heavy enough could lead to loss of vehicle control. Loss of vehicle control could lead to serious road accidents, injury and death.

  • Page 33: Transport Checklist

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Transport Checklist Before transporting the drill, check the following items:  Transport only with a tractor of proper size. See “Specifications and Capacities” on page 96.  Safety Chain in Place (page 17) - Attach safety chain to an anchor on tractor.

  • Page 34: Lowering Drill (Transport Lift)

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Lowering Drill (Transport Lift) Lowering from Transport Lift must be completed prior to unfolding. Transport Lift is on a dedicated hydraulic circuit. The center main frame raises and lowers independently of the opener sub-frames (which are raised and lowered by the Opener Lift circuit).
  • Page 35 3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Unfolding Drill must be lowered from transport lift prior to unfolding. See “Lowering Drill (Transport Lift)” on page 30. 1. Verify that the site has clearance needed to unfold drill. 2. If markers are installed, set Marker/Fold valve at hitch to Fold.

  • Page 36: Opener Operation

    To run drill on tractors with open-center hydraulics or on tractors with fixed-displacement hydraulic pumps, you must install a Great Plains kit, part number 194-143A. Contact your Great Plains...

  • Page 37: Active Hydraulic Systems

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Active Hydraulic Systems 1. Lock hydraulic lever forward during field operation for constant hydraulic flow to openers. Machine Damage Risk: John Deere tractors with Sound-Gard® Body: Tractors with load-sensing hydraulics must use the bypass Use lever lock clip, John Deere part number R52667, valve to operate the drill.

  • Page 38: Priority Flow Hydraulic Systems

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Priority Flow Hydraulic Systems On some tractors with load-sensing hydraulics, the circuit #1 is capable of taking nearly 100 percent of available hydraulic flow. Operating the openers or markers on circuit #1 will starve the other circuit, making one function inoperable.

  • Page 39: Position Seed Cup Doors

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions During operation: • Each time openers are lowered, hold tractor remote hydraulic lever forward for a few seconds to recharge circuit, then return it to its neutral position. The tractor and drill should be on level ground when returning tractor lever to neutral.

  • Page 40: Loading Materials

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Loading Materials Loading Main Seed Box 1. Check that all meter doors are positioned for the The drill must be hitched for seed loading. Seed may be seed size, and not set for clean-out. See “Position loaded in the field or prior to transport.

  • Page 41: Spill Flap

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Loading Fertilizer Compartment Load fertilizer after transport if possible. Some spillage can occur through meters during transport, even with the drive system disengaged. Possible Agricultural Chemicals Hazards: Take necessary materials safety precautions when loading dusty seed, treated seed or fertilizer.

  • Page 42: Fertilizer Box Operation

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Fertilizer Box Operation The 3S-3000/F and HDF models are equipped with a 100% Fert. Seed Fert. Seed fertilizer compartment capable of planting seed only, or seeding and applying fertilizer in the same field pass. Use only dry, granular fertilizer in the fertilizer box.

  • Page 43: Using Fertilizer Compartment

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Using Fertilizer Compartment Refer to “Loading Materials” on page 36 and see “Loading Fertilizer Compartment” on page 37. Seeding with Both Compartments 1. Clean out boxes. See “Main Seed Box Clean-Out” on page 66 and “Fertilizer Box Clean-Out” on page 66.

  • Page 44: Initial Seeding Depth

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Initial Seeding Depth Refer to Figure 36 1. Set opener seeding depth by adjusting press-wheel height . To adjust, first raise openers slightly, then lift and slide T-handles on top of openers Adjust all press wheels to the same height.

  • Page 45: Marker Operation

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Marker Operation Optional markers are equipped with a double-selector valve, on the tongue near the hitch, to combine the box-fold circuit with the marker circuit. On a 2-outlet tractor, there is a second selector valve, for the lift circuits, mounted above the marker/fold selector.

  • Page 46: Lift Selector Valve Operation

    Tractors with only two remote circuits need an optional selector valve, which shares a single tractor circuit between transport lift and opener lift. Two Outlet Tractor Hydraulic Kit Great Plains Part number 194-122A. This combines the transport lift hydraulic circuit and opener lift hydraulic circuit.

  • Page 47: Shaft Monitor Operation

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Shaft Monitor Operation The optional shaft monitor generates an alarm if any one or more of the three main seed box meter shafts on the drill stop turning for more than 20 seconds. Refer to Figure 41 To operate shaft monitor, turn system on by activating on-off switch...

  • Page 48: Wing Stand

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Parking Following these steps when parking the drill for periods of less than 36 hours. For longer periods, see “Storage” on page 45. Parking with Drill Unfolded Crushing Hazard: This drill has a negative tongue weight 1.

  • Page 49: Storage

    3S-3000/F/HD/HDF Table of Contents Index Operating Instructions Storage Store the drill where children do not play. If possible, store it inside for longer life. 1. Perform the drill Parking checklist. 2. If storing with openers lowered, disconnect seed hoses at openers to prevent deformation. 3.

  • Page 50: Small Seeds Rate

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Adjustments To get full performance from your drill, you need an Main Box Seed rate is controlled by adjustments for: understanding of all component operations, and many • Drive Type sprocket (one sprocket each gauge provide adjustments for optimal field results.

  • Page 51: Setting Material Rates

    All chart rates, for all boxes, normally located in the manual pak enclosure at the rear are approximate. Great Plains strongly recommends of the left wing. calibration of each box to the material to be applied.

  • Page 52: Frame Level

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Frame Level Refer to Figure 44 The 00 and 00HD Series openers are designed to produce optimal results when the opener frames are level with the ground. Operating with drill frame level is also recommended, and this is set by hitch height (page 18).

  • Page 53: Weight Bars

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Frame Weight The standard drill includes 1697 pounds (770kg) of weight bars inside the main tool bar. This, plus the extra weight of 00HD row units, permits adjustment of the full range row unit down forces. If markers are installed, additional force is available.

  • Page 54: Variable Displacement

    To run the drill on tractors with open-center hydraulics 2200 psi or on tractors with fixed displacement hydraulic pumps you must install a Great Plains kit, part number 2300 psi 194-143A. Contact your Great Plains dealer for ordering information. See “Non-Active Hydraulic System”...

  • Page 55: Setting Hydraulic Down-Pressure

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Setting Hydraulic Down-Pressure 1. Lower openers to the ground. Lock hydraulic lever forward for constant hydraulic flow. You must lock hydraulic lever forward. See “Opener Operation” on page 32. Refer to Figure 48 2. Release lock disk Turn...

  • Page 56: Opener-Subframe Adjustment

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Opener-Subframe Adjustment Refer to Figure 49 Each drill section has an opener frame which pivots about the centerline of the drill gauge wheels. These floating opener frames have the ability to rock the openers 15 degrees up and 15 degrees down as a group.

  • Page 57: 8. Small Seeds Delivery Tube: Optional

    3S-3000/F/HD/HDF Table of Contents Index Adjustments 00 Row Unit Adjustments Refer to Figure 51 (which depicts a row unit fully populated with all optional accessories [except ® scraper and Keeton ] supported for use with the Model 3S-3000/F Three Section 3000 Folding Drills) From front to back, a 00 Series row unit can include the following capabilities (some optional): 1.

  • Page 58: Hd Row Unit Adjustments

    (which depicts a row unit fully populated with all optional accessories supported for use with the 3S-3000HD drill) From front to back, a Great Plains 00HD Series row unit can include the following capabilities (some optional): 1. Opener height adjustment: standard If a few rows need to run deeper, such as in tire tracks, the arm’s pivot point may be lowered.

  • Page 59: Opener Height

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Opener Height The depth to which the opener disk blades penetrate the soil is controlled in front by the tool bar and pivot (opener height), and in the back by the press wheel height. If the actual ground level is lower for some rows, such as those in tire tracks, you can lower that row unit by lowering the pivot point.

  • Page 60: Disk Blade Adjustments

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Disk Blade Adjustments Opener disc angle and stagger is not adjustable, but disc-to-disc spacing is, and may need attention as discs experience normal wear. Spacers will need to be reset when blades are replaced. Refer to Figure 56 The ideal spacing causes the blades to be in contact for about one inch.

  • Page 61: Seed Firmer Adjustments

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Seed Firmer Adjustments 00HD Series row units include a seed flap, and accept one of two optional seed firmers. The seed flap requires no adjustment, but may need to be replaced if worn, and may need to be shortened if an optional seed firmer is added after initial delivery.

  • Page 62: Opener Depth (Press Wheel Height)

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Opener Depth (Press Wheel Height) Refer to Figure 61 Set opener seeding depth by adjusting press-wheel height To adjust, first raise openers slightly, then lift and slide T handles on top of openers Adjust all press wheels to the same height.

  • Page 63: Marker Adjustments

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Marker Adjustments Pinch, Crush and Sharp Object Hazards: You may be injured if hit by a folding or unfolding marker. Markers may fall quickly and unexpectedly if the hydraulics fail. Never allow anyone near the drill when folding or unfolding the markers.

  • Page 64: Marker Chain Adjustment

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Marker Chain Adjustment There are two basic adjustments needed on the marker chain, especially in new installation. These adjustments are interrelated and should be done in the following order: Refer to Figure 63 Marker Lifting Slack 1.

  • Page 65: Marker Disk Adjustment

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Marker Disk Adjustment Sharp Object Hazard: Marker disks may be sharp. Use caution when making adjustments in this area. Mark Width Refer to Figure 64 is the direction of travel. To change angle of cut, and the width of the mark, loosen ...

  • Page 66: Marker Speed

    3S-3000/F/HD/HDF Table of Contents Index Adjustments Marker Speed The procedure for adjusting marker speed is different for single marker with needle valve and dual markers with sequence valve. Single Marker/Needle Valve Speed Refer to Figure 66 A needle valve controls the folding speed. The needle valve is near the rod end of the marker cylinder.

  • Page 67: Troubleshooting

    3S-3000/F/HD/HDF Table of Contents Index Troubleshooting Troubleshooting Problem Solution Check for plugging in feed cup. Uneven seed spacing or uneven stand Check to see if seed tubes are plugged. Reduce ground speed. Check opener disks to see they turn freely. Use faster drive type speed and close feed cup flutes to a more narrow position.
  • Page 68 The blade may be reversed to pull dirt in or throw dirt out depending on soil conditions. If a smooth blade does not provide an adequate mark an optional notched (no-till) blade assembly is available through your Great Plains dealer. Under some conditions, the more aggressive notched blade will leave a more visible mark.

  • Page 69: Maintenance And Lubrication

    5. Inspect hydraulic hoses for cuts, cracks and aging. Check fittings for evidence of leaks. 6. Keep disk scrapers properly adjusted. 7. Replace any worn, damaged or illegible safety decals. Order new decals from your Great Plains dealer. See “Safety Decals” on page 6. 2018-06-18 Table of Contents...

  • Page 70: Materials Clean-Out

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Materials Clean-Out Main Seed Box Clean-Out Refer to Figure 68, which depicts the seed cup door handle in a normal operating position. 1. Set the Seed Rate Handle to zero (0) for the section of the drill to be cleaned out.

  • Page 71: Small Seeds Box Clean-Out

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Small Seeds Box Clean-Out 1. Open lid of each box and scoop out as much seed as possible. 2. To recover remaining seed, place a collection tarp under the small seeds tubes at the openers. 3.

  • Page 72: Bleeding Hydraulics

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Bleeding Hydraulics To function properly, the hydraulics must be free of air. If hydraulics have not been bled, they will operate with jerky, uneven motions and could cause wings to drop rapidly during folding or unfolding. If hydraulics were not bled during initial implement setup or if you replace a part in hydraulic system during the life of the drill, complete the following procedures.
  • Page 73 3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Bleeding Fold Hydraulics Refer to Figure 73 1. Review warnings, bleeding notes and system 6. Slowly supply oil to base end of fold cylinders (line information on page 68. ) until oil appears at loosened hose fitting. Tighten base end hose fitting and cycle fold cylinders in and 2.

  • Page 74: Bleeding Opener Lift Hydraulics

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Bleeding Opener Lift Hydraulics Refer to Figure 74 1. Review warnings, bleeding notes and system 6. Slowly supply oil to top side of pressure-control information on page 68. valves until oil begins to appear at a loosened hose fitting.

  • Page 75: Bleeding Transport Lift Hydraulics

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Bleeding Transport Lift Hydraulics Refer to Figure 75 1. Start with the transport axle in the lowered (field) position, and the box lift cylinder (at the middle of the tongue) completely retracted. Loosen the base end NEVER CRAWL UNDER THE DRILL IN THE RAISED hose fitting at the elbow on the left transport lift POSITON WITHOUT THE CYLINDER LOCK CHANNELS...

  • Page 76: Bleeding Marker Hydraulics

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Bleeding Marker Hydraulics Crushing and Sharp Object Hazard: You may be injured if hit by a folding or unfolding marker. Markers may fall quickly and unexpectedly if the hydraulics fail. Never allow anyone near the drill when folding or unfolding markers.

  • Page 77: In-Line Filters

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication In-Line Filters If the raising or lowering times of the openers slow noticeably, check the in-line filters and clean if needed. Refer to Figure 77 Two filters are located on one each of the down-pressure adjustment valves.

  • Page 78: Leveling The Drill

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Leveling the drill To perform leveling, the drill must be hitched to a tractor, with at least the hydraulics connected. Negative Tongue Weight: Raising openers on unfolded, unhitched drill will cause drill tongue to rise suddenly, which could cause serious injury or death.

  • Page 79: Wing Box Alignment

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Wing Box Alignment 1. Place a block ahead of the wing gauge wheels. Refer to Figure 81 2. Pull forward against blocks to rock wing frames back. Pull forward until stop bolts are firmly against toolbars.

  • Page 80: Transfer Drive Shaft

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Align Transfer Drive Shaft Refer to Figure 83 and Figure 84 After wing boxes are properly aligned, the transfer drive shaft must be aligned so the pair of break-away jaws  are fully engaged and are concentric. The in hex drive shafts holding the clutch jaws should not contact each other...
  • Page 81 3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Refer to Figure 85 and Figure 86 3. To align the clutch jaws vertically, loosen the two  inch bolts at the bottom of the breakaway clutch bracket , and adjust the bracket as needed. 4.

  • Page 82: Spacer Washer

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Toolbar Height Refer to Figure 87 and Figure 88 Toolbar height above ground level is factory set and normally does not require adjustment. If you tear down the drill for repair, or if the tool bar is visibly not level, spacer washers on vertical pivot pins allow for a small amount of tool bar-height adjustment.

  • Page 83: Opener-Frame Clearance

    If the shear bolt breaks, replace it with an equivalent  -16x2in Grade 2 bolt (Great Plains part 802-266C). If that size is not available in your local market, temporarily Figure 90 15632 substitute an M10x1.5 Class 5.8 metric bolt and nut.

  • Page 84: Marker Disk

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Marker Disk Refer to Figure 92 If grease-seal cap for marker-disk-hub bearings is damaged or missing, disassemble and clean hub. Repack with grease and install a new seal or grease cap. Figure 92 18795 Marker Bearing and Cap 2018-06-18...

  • Page 85: Seed Flap Replacement

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Seed Flap Replacement Refer to Figure 93 To replace an 816-302C seed flap use a needle nose pliers or similar tool to grasp “T” top of flap. Pull upward to pull flap up out of metal bracket Push new seed flap down through metal bracket until flap snaps into place with “T”...

  • Page 86: Lubrication

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Lubrication Intervals (operating hours) Multi-purpose Multi-purpose Multi-purpose Inspection at which service oil lubricant spray lubricant grease lubricant is required 34208 Opener Frame Pivots 2 grease fittings on center section, 1 grease fitting each wing section; 4 total Type of Lubrication: Grease Quantity: Until grease emerges at pivot ends.
  • Page 87 3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Telescoping Drive Shaft 2 grease fittings Type of Lubrication: Grease Quantity: Until grease emerges. 18875 Drive Shaft Clutches 2 grease fittings each of 3 clutches; 6 total Type of Lubrication: Grease Quantity: Until grease emerges Also smear grease on clutch engagement.
  • Page 88 3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Fertilizer Shaft Bearings 1 grease fitting each bearing, 2 per shaft; 6 total Type of Lubrication: Grease Quantity: Until resistance is felt 16381 Small Seeds Shaft Bearings 1 grease fitting each bearing, 2 per shaft; 6 total Type of Lubrication: Grease Quantity: Until grease emerges 18082...
  • Page 89 3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Transport Lift Pivots 2 grease fittings inside pivot Type of Lubrication: Grease Quantity: Until grease emerges at pivot ends 15543 Transport Axle 2 grease fittings Type of Lubrication: Grease Quantity: Until grease emerges 15541 Mainframe Pivots 2 grease fittings each pivot;...
  • Page 90 3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Gauge Wheel Chain As Required 1 chain per gauge wheel; 2 total Type of Lubrication: Chain Lube Quantity: Coat thoroughly  Slack: in (13mm) in top span 18865 Clutch to Seed Jackshaft Chain As Required 1 chain per section;...
  • Page 91 3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Clutch Shaft to Fertilizer Range Chain As Required 1 chain per section; 3 total Type of Lubrication: Chain Lube Quantity: Coat thoroughly  Slack: in (7mm) in top span 16379 Fertilizer Range to Jackshaft Chain As Required 1 chain per section;...

  • Page 92: Small Seeds

    3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Small Seeds Drive Chains As Required 2 chains per section; 6 total Type of Lubrication: Chain Lube Quantity: Coat thoroughly Slack:  in (13mm) in top span of long chain  in (7mm) in longest span of final drive chain 17180 Transport Wheel Bearings 2-3 Years...
  • Page 93 3S-3000/F/HD/HDF Table of Contents Index Maintenance and Lubrication Marker Disk Bearings 2-3 Years 2 races each marker; 2 or 4 total Type of Lubrication: Grease Quantity: Repack 15481 2018-06-18 Table of Contents Index 195-441M...

  • Page 94: Options

    3S-3000/F/HD/HDF Table of Contents Index Options Options Hitches One hitch is selected upon initial order of a drill, and includes the spring wire loop, safety chain, and all fasteners. Additional hitches may be ordered for conversion in the field, and include extra hitch mounting bolts, lock washers and nuts.

  • Page 95: Point Row Clutch

    3S-3000/F/HD/HDF Table of Contents Index Options Point Row Clutch On the standard drill, all sections raise and lower simultaneously. Shutting off seed flow on one or two sections requires stopping and making setup changes. The Point Row Clutch option provides cab control of opener lift on a section-by-section basis.

  • Page 96: Shaft Monitor

    3S-3000/F/HD/HDF Table of Contents Index Options Shaft Monitor This kit provides a cab alarm in the event that a main box seed meter shaft stops turning (which might result from excess down-pressure lifting a gauge wheel, low tire pressure/flat tire, chain break or clutch malfunction). Order one kit per drill.

  • Page 97: Small Seeds Attachment

    3S-3000/F/HD/HDF Table of Contents Index Options Calibration Tray This tray is used to calibrate seed for the main seed box to accurately achieve your target population. Only one tray per drill is needed. Description Part Number Plastic Calibration Tray 837-013C Cal Tray End Mount 194-707D Calibration Tray Spring Clip...

  • Page 98: Removable Partition

    3S-3000/F/HD/HDF Table of Contents Index Options Removable Partition This partition reduces side-to-side seed flow in the small seeds box. This can prevent seed pile-up when drilling across slopes and in other situations where the seed is particularly fluid. Order one per partition. Description Part Number RMVBL SMALL SEED BOX PARTITION...

  • Page 99: 00Hd Series

    3S-3000/F/HD/HDF Table of Contents Index Options Seed Firmers The standard 3S-3000/F/HD/HDF drill includes seed flaps. A choice of firmers is an option in the product bundles, or may be field-installed as kits. Only one type of seed firmer may be installed at the same time. Order one firmer kit per opener.

  • Page 100: Transport

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Appendix A - Reference Information Specifications and Capacities 3S-3000-6006 3S-3000-4875 3S-3000-3610 3S-3000HD-6006 3S-3000HD-4875 3S-3000HD-3610 Row Count Row Spacing 6 in (15.2 cm) 7.5 in (19.1 cm) 10 in (25.4 cm) Main Seed Box Capacity 92.7 bushels (3267 liters) Tractor Requirements...

  • Page 101: Drill Dimensions

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Drill Dimensions 15646 2018-06-18 Table of Contents Index 195-441M...

  • Page 102: Torque Values Chart

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Torque Values Chart Bolt Head Identification Bolt Head Identification Bolt Bolt 10.9 Size Size Grade 2 Grade 5 Grade 8 Class 5.8 Class 8.8 Class 10.9 ft-lb ft-lb ft-lb ft-lb ft-lb in-tpi ft-lb...

  • Page 103: Transport Lift

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Hydraulic Diagrams Transport Fold 15602 Transport Lift 15602 2018-06-18 Table of Contents Index 195-441M...

  • Page 104: Dual Markers

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Dual Markers 15605 Single Marker 15605 2018-06-18 Table of Contents Index 195-441M...

  • Page 105: Two Outlet Conversion

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Two Outlet Conversion 15605 2018-06-18 Table of Contents Index 195-441M...

  • Page 106: Opener Lift: Standard Closed-Center

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Opener Lift: Standard Closed-Center 22979 2018-06-18 Table of Contents Index 195-441M...

  • Page 107: Opener Lift: Optional Open-Center

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Opener Lift: Optional Open-Center 22980 2018-06-18 Table of Contents Index 195-441M...

  • Page 108: Point-Row

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Point-Row 22969 2018-06-18 Table of Contents Index 195-441M...

  • Page 109: Gauge Wheel Drive Chain

    3S-3000/F/HD/HDF Table of Contents Index Appendix A - Reference Information Gauge Wheel Drive Chain 15606 2018-06-18 Table of Contents Index 195-441M...

  • Page 110: Appendix B - Initial Setup

    3S-3000/F/HD/HDF Table of Contents Index Appendix B - Initial Setup Appendix B - Initial Setup Scraper Installation Optional disk scrapers are not factory installed. To install them in the field: 1. Remove one or both disk blades to gain safe access to the mount.

  • Page 111: Marker Setup

    3S-3000/F/HD/HDF Table of Contents Index Appendix B - Initial Setup Marker Setup Refer to Figure 96 Markers are field-installed, but usually do not have their extension length precisely set. The drill must be leveled per “Center Box Frame Leveling” on page 74, and marker(s) must be in correct working order per “Marker Maintenance”...
  • Page 112 This Warranty is limited to the replacement of any defective part by Great Plains and the installation by the dealer of any such replacement part. Great Plains reserves the right to inspect any equipment or part which are claimed to have been defective in material or workmanship.

  • Page 113: Caution
