User's Manual
Installation
HQ Series
HQ-112.43 / HQ-112.64 / HQ-112.95
HQ-218 / HQ-212.64 / HQ-212.95
Antes de utilizar el equipo, lea la sección
"Precauciones de seguridad" de este manual.
Conserve este manual para futuras consultas.
Before operating the device, please read the
"Safety precautions" section of this manual.
Retain this manual for future reference.
Advertisement
Table of Contents
Related Manuals for DAS HQ-112.43
Summary of Contents for DAS HQ-112.43
- Page 1 User's Manual Installation HQ Series HQ-112.43 / HQ-112.64 / HQ-112.95 HQ-218 / HQ-212.64 / HQ-212.95 Antes de utilizar el equipo, lea la sección “Precauciones de seguridad” de este manual. Conserve este manual para futuras consultas. Before operating the device, please read the “Safety precautions”...
-
Page 2: Table Of Contents
CONFIGURATIONS 9 - 11 4x HQ-112.xx (horizontal array) 4x HQ-112.95 + 2x HQ-218 (horizontal array) 6x HQ-112.43 + 2x HQ-218 (vertical array) 16x HQ-212.XX + 1x DX-100I 16x HQ-212.XX bi-amp + 1x DX-100I + 1x DX-80 SPECIFICATIONS 13 - 14... -
Page 3: Safety Precautions
HQ series Precauciones de Seguridad Safety Precautions Cajas acústicas pasivas / Passive loudspeaker enclosures Conserve y lea todas estas instrucciones. Keep these instructions. Siga todas las advertencias. Heed all warnings. Follow all instructions. El signo de exclamación dentro de un triángulo indica la The exclamation point inside an equilateral triangle indicates the existencia de componentes internos cuyo reemplazo puede existence of internal components whose substitution may affect... -
Page 4: Warranty
GARANTÍA Todos nuestros productos están garantizados por un periodo de 24 meses desde la fecha de compra. Las garantías sólo serán válidas si son por un defecto de fabricación y en ningún caso por un uso incorrecto del producto. reparaciones garantía pueden realizadas,... -
Page 5: Declaration Of Conformity
DECLARACIÓN DE CONFORMIDAD DECLARATION OF CONFORMITY DAS Audio Group, S.L. C/ Islas Baleares, 24 - 46988 - Pol. Fuente del Jarro - Valencia. España (Spain). Declara que la serie HQ: Declares that HQ series: Cumple con los objetivos esenciales de las Directivas: Abide by essential objectives relating Directives: De Baja Tensión / Low Voltage... -
Page 6: Introduction
INTRODUCTION The DAS HQ series is designed for medium to large scale installations such arenas, stadiums, auditoriums and theaters. The HQ models offer tightly controlled coverage patterns and high output capabilities being usable individually, or in multiple unit arrays. The models are offered in FX paint finish. This finish is adequate for applications where cabinets are covered or protected, and where cabinets are unprotected and directly exposed to the environment. - Page 7 HQ-112.95 -Two-way system with 2 selectable operating modes: passive system or Bi-amplified system. -12” bass loudspeaker, 12HQ, 3" VCD. -Compression driver with titanium diaphragm, M-78N, 3" VCD. -Rotatable 90º x 50º horn design -Trapezoid geometry enclosure -Finish: FX covered and direct exposure -20 built-in rigging points.
- Page 8 - Selectable passive/biamplified operating modes - Tight 60º x 40º coverage angles - Rotatable horns - Stainless steel rigging kit The DAS HQ-212.64 is designed for medium to large scale installations such as arenas, auditoriums, stadiums and theaters. The HQ models offer tightly controlled...
-
Page 9: Configurations
CONFIGURATIONS Next, you will see three examples. You will find more configurations on our website. 4x HQ-112.xx (horizontal array) LINK LINK HQ-112.XX HQ-112.XX HQ-112.XX HQ-112.XX 4x HQ-112.95 + 2x HQ-218 (horizontal array) LINK LINK HQ-112.95 HQ-218 HQ-112.95 HQ-112.95 HQ-218 HQ-112.95 DSP-2060A D100 PRC (Power Reduction Control) for D-100:... -
Page 10: Hq-112.43 + 2X Hq-218 (Vertical Array)
CONFIGURATIONS (cont’d) 6x HQ-112.43 + 2x HQ-218 (vertical array) HQ-218 HQ-218 HQ-112.43 HQ-112.43 DSP-2060A D100 HQ-112.43 HQ-112.43 PRC (Power Reduction Control) for D-100: PRC = 0 dB for HQ-218 PRC = -4 dB for HQ-112.xx HQ-112.43 HQ-112.43 Nota: Para acoplamiento acústico óptimo el usuario debe girar los difusores de MF y HF como se explica en las figuras abajo. -
Page 11: Hq-212.Xx + 1X Dx-100I
CONFIGURATIONS (cont’d) 16x HQ-212.XX + 1x DX-100I DX SERIES DSP PROTECTION PROCESSING POWER AMPLIFIER BRIDGE 1+2 BRIDGE 3+4 BACK MENU NEXT STBY MUTE ADJUST CLIP G.R. REMOTE AUX 1-4 DIGITAL IN IN A-D NETWORK AUDIO QUIT ENTER BANK DX SERIES DSP EDIT PROCESSING POWER AMPLIFIER 16x HQ-212.XX bi-amp + 1x DX-100I + 1x DX-80... -
Page 13: Line Drawings
LINE DRAWINGS ALL DIMENSIONS IN MILLIMETERS Manual del Usuario / HQ series / User’s Manual... -
Page 14: Line Drawings
LINE DRAWINGS ALL DIMENSIONS IN MILLIMETERS Manual del Usuario / HQ series / User’s Manual... -
Page 15: Installation
INSTALLATION Connectors The DAS HQ series is designed to facilitate the connection for installations, so it has been provided with two types of connectors: the NL4 type, standard for professional audio equipment (except HQ-212.xx), and screw terminals, easier to use in most types of installations. These terminals are connected in parallel, so that we can carry the amplified audio signal up to a device and we can forward it to the next box, very easily. - Page 16 Example: HQ-212.95 90º HORIZONTAL DISASSEMBLE TURN 90º 90º HORIZONTAL ASSEMBLE After turn: 90º VERTICAL 90º VERTICAL Manual del Usuario / HQ series / User’s Manual...
- Page 17 Coverages The DAS HQ series is designed with trapezoid enclosures to very easily achieve the desired coverages in fixed installations. Here are some basic examples. Vertical Array 70º coverage VISTA LATERAL SIDE VIEW Vertical Array 110º coverage VISTA LATERAL SIDE VIEW...
- Page 18 Horizontal Array 150º coverage VISTA SUPERIOR TOP VIEW Horizontal Array 60º coverage VISTA SUPERIOR TOP VIEW Horizontal Array 100º coverage VISTA SUPERIOR TOP VIEW Manual del Usuario / HQ series / User’s Manual...
-
Page 19: Horizontal Array
Array 360º coverage The DAS HQ series, as seen in these examples, allows more combinations to achieve the desired coverage in each installation. We have collected only the most indicative examples, given the infinite possibilities. On our website, you can find the "gll" files for Ease Focus software, with which you can simulate the acoustic performance of a given configuration of devices. - Page 20 Example: HQ-212.XX HQ-212.64 35º HQ-212.64 40º HQ-212.95 Manual del Usuario / HQ series / User’s Manual...
-
Page 21: Accessories
Do not fly enclosures from unsafe structures. Consult a certified professional if needed. All flying accessories that are not supplied by DAS Audio are the user's responsibility. Use at your own risk. ANL-2... - Page 22 To hang the units, the Allen-head screws must be removed and replaced by M10 eyebolts on one side of the enclosure. Each rigging point has a 200 kg (440 lb) working load limit. Then choose the slings or chains of required load resistance and length, bearing in mind that the length difference between the front and back slings or chains will determine the vertical orientation.
- Page 23 Horizontal array: 2x HQ-112.xx + 1x HQ-218 Vertical array: 3x HQ-112.xx Vertical array: 3x HQ-112.xx + 1x HQ-218 Manual del Usuario / HQ series / User’s Manual...
- Page 24 Vertical array: 2x HQ-212.64 + 1x HQ-212.95 Manual del Usuario / HQ series / User’s Manual...
-
Page 25: Annex: Table For Cable Selection
ANNEX : Table for cable selection This table shows the power loss in % and dB, for different cable lengths and sections shown. It is recommended that the losses do not exceed 30% in any case (around 3dB). Although it is recommended minimizing losses, the maximum acceptable losses are usually around 15% (approximately 1.4dB). - Page 26 46988 Fuente del Jarro Miami, FL. 33166 - U.S.A. Tower #34-36 Santa Efigênia, São Paulo Valencia, SPAIN TOLL FREE: 1 888 DAS 4 USA Singapore 039190 Brasil. CEP: 01208-000 Tel. +34 96 134 0860 Tel. +65 6549 7760 Tel. +551133330764...
