CONNECTION DIAGRAM (ROUTER)
C
D
A
B
C
D
E
F
G
A
UNITY CONTROLLER
COMPUTER
110VAC POWER
MACHINE HARNESS
PARALLEL CABLE
USB CABLE
KEYBOARD, MOUSE, MONITOR, JOG PENDANT
