TR-51S/52S
User's Manual
Thank you for purchasing this product.
Carefully read and fully understand these
instructions before using this unit.
Shimadachi 817-1, Matsumoto, Nagano 390-0852 Japan
Tel:+81-263-40-0131 Fax:+81-263-40-3152
Homepage:http://www.tandd.com/ E-mail:support@tandd.com
© Copyright 2007 T&D Corporation. All rights reserved. 2009. 06 16004514110 (3rd Edition)
This is printed using recycled paper.
Product Specifications
TR-51S TR-52S
Measurement Item Temperature Temperature
Measurement Channels 1 Ch（Internal Sensor Type） 1 Ch（External Sensor type）
Measurement Range ― 40 to 80℃ ― 60 to 155℃
Typ. ± 0.3℃ : ― 20 to 80℃
Typ. ± 0.5℃ : ― 40 to ― 20℃
Measurement Accuracy Typ. ± 0.5℃ 80 to 110℃
Typ. ± 1.0℃ : ― 60 to ― 40℃
110 to 155℃
Measurement Display Resolution 0.1℃
Recording Capacity 16000 data
Recording Start Method Immediate / Programmed
Recording Mode Endless / One-time
Select from 1,2,5,10,15,20 and 30 seconds or
Recording Interval
from1,2,5,10,15,20,30 and 60 minutes
Temperature measured, recording conditions, battery life warning,
LCD Display Items memory FULL, sensor unconnected, over measurement range,
temperature unit (° F / ° C) and Upper / Lower limit over
Power（*1 ） Lithium battery LS14250 x 1 (Lithium battery CR2 also Okay)
Battery Life（*2） Maximum 4 years
Waterproof Capacity IP67（Immersion proof） IP64（Splash resistant）
External Dimensions H62mm x W47mm x D19mm (Excluding protrusions)
Weight Approx. 54g including battery Approx. 55g including battery
Standard Sensor Built - in TR-5106: Teflon resin sensor
Unit Temp. Resistance ― 40 to 80℃
Accessories Included Lithium Battery LS14250 x 1, Tube x 1, Strap x 1, User's Manual (Warranty) x 1
(*1 ) The lithium battery (LS14250) is not sold in stores. It can be purchased through our
distributors as (Optional Battery Set TR-10P2) Normal lithium batteries sold in stores (CR2)
can be used, but the operating range is reduced to ― 20℃ to 60℃ . If you will be using the
logger in an environment where temperatures may be lower than ― 20℃ or higher than 60℃ ,
we strongly suggest purchasing and using the "Optional Battery Set TR-10P2".
(*2) Battery life depends upon the measuring environment, recording interval, and quality of the
battery being used.
Specifications for TR-5106
（Temperature Sensors for TR-52S）
Sensor Heat-Durability ― 70 to 180℃
Dimensions Diameter: 2mm / Cable length: 0.6m
Thermal Time Constant in the air : Approx 15 sec. / in agitated water : Approx 2 sec.
Shielding Teflon resin （FEP）
Waterproof Capacity Only the sensor tip is waterproof, the rest is immersion proof (IPX7)
Notices about this User's Manual
- All rights of this User's Manual belong to T&D Corporation. It is prohibited to use, duplicate and/or arrange a part or whole of this User's Manual without the permission of T&D
Corporation.
- Please follow the safety precautions carefully. We cannot guarantee nor are we responsible for safety if this product is used in any manner other than was intended.
- T&D Corporation accepts no responsibility for any malfunction of and/or trouble with this product or with your computer that is caused by the improper handling of this product and will
deem such trouble or malfunction as falling outside the conditions for free repair of the attached warranty.
- T&D Corporation accepts no responsibility for any result or effects from using this User's Manual.
- Figures and illustrations in this manual may be slightly simplified and may differ from the actual product.
- We sincerely hope that the contents of this manual are true and complete. If you find any information to have been omitted, or if the information within is confusing or mistaken please
contact your retailer or T&D Corporation.
- The warranty that is included in this User's Manual cannot be reissued, so please keep it in a safe place.
- This manual has been written using ℃ as the standard unit of temperature.
Safety Precautions and Instructions
*Please carefully observe the following safety measures when using our product.
To prevent any loss or damage to our customers, other people and / or property, and to ensure the proper use of our products we ask that before using our product you carefully read,
understand and follow the safety rules and precautions for our products as outlined below.
Do not take apart, repair or modify the main unit.
It may cause fire, electrocution or damage. Ask the shop where you purchased the products or T&D
Corporation to carry out any repairs.
If any smoke or strange smells are emitted from the unit, immediately cease using it.
Continued use may cause fire, electrocution or damage.
Do not use any batteries other than those that are recommended.
It may cause fire or damage.
We are not responsible for any malfunction or trouble caused by the use of our
product or by any problem caused by the malfunction of our unit. Please be fully
aware of this before using our product.
This product has been designed for private or industrial use only. It is not for use in
situations where strict safety precautions are necessary such as in connection with
medical equipment whether directly or indirectly.
Do not drop or expose the unit to strong impact.
Do not put your fingers or foreign matter into the sensor connection.
Do not put your fingers or foreign matter into the communication port.
The units can be operated with "T&D Recorder for Windows (TR-5, 7xU)" version
1.50E or later.
The latest version of "T&D Recorder for Windows (TR-5, 7xU)" can be downloaded free of charge
from our Web Site.
Battery life depends on the measurement environment, communication frequency,
recording interval and battery quality.
The TR-52S only becomes water resistant (IP64 splash resistant) if the temperature
sensor has been connected.
Without the sensor connected, the connector part of neither the main unit nor the temperature sensor
is water resistant; make sure not to get wet.

Part Names

TR-51S TR-52S
Internal Sensor Type External Sensor Type
IP67 (Immersion proof) IP64 (Splash resistant)
LCD Display LCD Display
Warning LED (red)
Optical Communication
Port
Sensor Jack
*TR-52S is not water resistant unless the sensor has been connected.
DANGER
If water or a foreign object enters the case, immediately cease using it.
Store all batteries, sensors and Thermo Recorder units out of the reach of children.
It is dangerous to swallow batteries.
Please be careful when using in overly hot or cold environments; touching the units
may cause burns or frostbite.
CAUTION
Pay attention as water leakage or foreign objects entering into the unit case is
possible in the following cases.
- The case was closed with dust, hair, etc., on the rubber packing or in the groove for the packing.
- The rubber packing becomes damaged.
(In this case, please purchase the optional maintenance set.)
- The unit suffered from significant temperature change while wet.
Especially in the case that the temperature changes from high to low.
Do not use or store the unit in places such as listed below:
It may cause electrocution, fire or damage to the unit or to your computer.
- Areas exposed to direct sunlight
- Areas exposed in water or high-pressure water flow.
- Areas exposed to organic solvents and corrosive gas.
- Areas exposed to strong magnetic fields
- Areas exposed to static electricity.
- Areas exposed to fire or overheating.
- Areas exposed to excessive dust or smoke.
When using the included Sensor TR-5106, please take note of the following:
・ Do no bend the sensor (tip section) or expose it to a strong impact. This may cause
trouble or break the wire.
・ The sensor and the cable are shielded by Teflon®. If the shield has a defect or tear, the
waterproof capacity is lost as the shield is very thin. Inspect it before operation.
・ Insert the sensor tip to at least 5cm or more to obtain on accurate temperature
measurement.
・ Only use the sensor within the sensor heat-durability range.
Contact with oil may cause cracks to appear in the casing of the unit.
If the unit is being used in an environment where there is a possibility of
oil spraying or splashing, T&D strongly advises that the unit be placed in a
Polyethylene bag before using.
TR-5106
Temperature Sensor (for TR-52S)
① Thermistor ② Teflon Resin (FEP)-Shielded
Connecting the Sensor
Connect the sensor adapter to the sensor jack on the logger.
Make sure that the plug is completely inserted; until you hear a
"click" sound.
About Optional Sensors
Please see our Web Site for
details about optional sensors
available for the TR-52S.
