T&D RTR-52Pt User Manual

Wireless Thermo Recorder RTR-52Pt Warranty
Customer's name:
Address:
Phone No.:
Dealer's name:
Address:
Phone No.:
Guarantee period 12 months from date of purchase
Date of purchase
Statement of Limited Warranty
1. This product is warranted to be free from defects in materials and workmanship
for a period of one (1) year following the date of purchase. Should the product
fail to operate per specification in normal use during this period T&D will repair
the unit or provide a replacement free of charge. T&D will not accept returns for
any reason other than defects during the warranty period, and will not accept
any product that has been misused, dropped, abused or inappropriately used or
mistreated at any time.
2. This warranty is strictly limited to repair or replacement-in-kind for defective
product. T&D makes no other warranty, either express or implied, and will not ac-
cept liability beyond the remedies stated herein. Specifically, T&D will not accept
liability for direct, indirect, special, consequential or incidental damages arising
from the use of this product.
3. Customers wishing to submit a defective product for repair or replacement during
the warranty period should first contact the dealer from whom it was originally
purchased. After receiving a return authorization the defective product should
then be packaged along with a description of the difficulties being experienced,
proof of purchase and all included accessories and materials, and returned it
to the dealer. In the event of difficulty contacting the original dealer, customers
should contact the nearest authorized T&D sales representative. A list of these
can be found on the company's website, www.tandd.com, or it can be obtained
by contacting TandD US directly.
4. This limited warranty statement gives the customer specific legal rights. The
customer may also have other rights which vary from state to state in the United
States, from province to province in Canada, and from country to country else-
where in the world. To the extent this limited warranty statement is inconsistent
with local law, this statement shall be deemed modified to be consistent with
such local law.
5. For further information relating to product repair or replacement, or for other
service questions after the termination of the warranty period, customers should
contact their local authorized T&D sales representative.
Radio, EMC and Safety Regulations
This device complies with part 15 of the Federal Communi-
cations Commission (FCC) rules and with RSS-210 of the
Industry Canada (IC). Operation is subject to the following
conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received,
including interference that may cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The user is cautioned that changes or modifications not expressly approved by T&D
Corporation, could void the user's authority to operate the equipment.
Inquiries
T&D CORPORATION
Shimadachi 817-1, Matsumoto, Nagano 390-0852 JAPAN
Tel:+81-263-40-0131 Fax:+81-263-40-3152
E-mail: support@tandd.com
Website: http://www.tandd.com/
Wireless Temperature Data Logger
User's Manual
Thank you for purchasing this product.
Carefully read and fully understand
these instructions before using this unit.
© Copyright 2007 T&D Corporation. All rights reserved.
2009.04 16004504080 3rd Edition
Product Specifications
RTR-52Pt
Measurement Channels 1 Temperature Channel
Measurement Range -199.9 to 600 C
Adaptable sensor Pt100 / Pt1000 (with 3 wires)
Measuring current 1mA/Pt100 0.21mA/Pt1000
Measurement Display
0.1 C
Resolution
0.3 C(-199.9 to 80 C)
Measurement Accuracy 0.5 C(80 to 450 C)
(at 0 to 50 C) 1.0 C(450 to 600 C)
Sensor accuracy is not included.
1, 2, 5, 10, 15, 20, 30 seconds /1, 2, 5, 10, 15, 20, 30, 60 minutes,
Recording Interval
Total of 15 choices
Recording Capacity 16,000 Readings x 1 Channel
Endless (Overwrite oldest data when capacity is full)
Recording Mode
One-time (Stop reading when capacity is full)
Current Readings, Recording Settings, Battery Life Warning,
LCD Display Items
Over Measurement Range Warning, Unit
Power Lithium Battery (LS14250(SAFT)) x 1
Approx. 6 months (Battery life depending on measurement environ-
Battery Life
ment, recording interval and battery performance)
Wireless Method FCC Part15 Section249 / IC RSS-210
Transmission Distance Up to 100 meters (May vary with conditions)
Wireless Communication
Interface
Optical Communication
When downloading data (Wireless) Approx. 2,000 readings
Communication Speed per minute [Collection of a full unit of data=Approx. 420 seconds
(optical communication=Approx. 160 seconds)]
Water Resistance IP64 (rated for use in daily life)
*1 *2
H62 x W47 x D19mm
Dimensions
(excluding protrusions / antenna length 20mm)
Weight Approx. 56g. (including 1 lithium battery)
Unit Temp. Resistance -40 C to 80 C
*3
Sensor Adaptor (RTR-05P1) x 1,
Accessories Included: Lithium Battery (LS14250 (SAFT)) x 1, Tube x 1, Strap x 1,
User's Manual (Warranty) x 1
*1 : Not for continued immersion.
*2 : The water resistance rating with the sensor adaptor connected is IP64.
*3 : Radio commnication can not be operated at below -30 C degrees or less.
Notices about this User's Manual
Please read this manual carefully before using the product.
All rights of this User's Manual belong to T&D Corporation. It is prohibited to use,
duplicate and/or arrange a part or whole of this User's Manual without the
permission of T&D Corporation.
Please follow the safety precautions carefully. We cannot guarantee nor are we
responsible for safety if this product is used in any manner other than was
intended.
T&D Corporation accepts no responsibility for any malfunction of and/or trouble
with this product or with your computer that is caused by the improper handling of
this product and will deem such trouble or malfunction as falling outside the
conditions for free repair of the attached warranty.
T&D Corporation accepts no responsibility for any result or effects from using this
User's Manual.
Safety Precautions and Instructions
To prevent any loss or damage to our customers, other people and/or property, and to ensure the proper use of our products we ask that before using
our product you carefully read, understand and follow the safety rules and precautions for our products as outlined below.
Explanation of Warning Symbols
These entries are actions that absolutely under no
DANGER
circumstance should be taken. The taking of such an action
may cause serious personal physical damage or death.
These entries are actions that if taken may lead to physical
CAUTION
injury or damage to persons or things.
Do not take apart, repair or modify the main unit.
It may cause fire, electrocution or damage. Ask the shop where you
purchased the products or T&D Corporation to carry out any repairs.
If any smoke or strange smells are emitted from the unit, immediately
cease using it.
Continued use may cause fire, electrocution or damage.
Do not use any battery other than those that are recommended. It
may cause fire or damage.
We are not responsible for any malfunction or trouble caused by the
use of our product or by any problem caused by the malfunction of
our unit. Please be fully aware of this before using our product.
This product has been designed for private or industrial use only.
It is not for use in situations where strict safety precautions are
necessary such as in connection with medical equipment whether
directly or indirectly.
Do not drop or expose the unit to strong impact.
The case material of this unit is susceptible to certain organic
solvents and oils, such as vegetable oil. Prolonged exposure to
these substances can cause cracking of the case and will void the
manufacturer's warranty.
When using this unit in environments where such oils are present,
please insure that it is protected from contact through use of a
polyethylene bag or other means.
Do not put your fingers or foreign matter into the sensor connection.
Battery terminals may provide insufficient contact due to age or
vibration. Please be careful not to lose data due to insufficient
contact.
Battery life depends on the measurement environment,
communication frequency, recording interval and battery quality.
Remove battery from any unit that is not to be used for a long period
of time.
Battery left in a unit not being used for a long time may leak and
cause a malfunction.
Avoid using the lithium batteries, LS 14250 for long periods at
temperatures over 60 .
The battery life may be significantly decreased.
Figures and illustrations in this manual may be slightly simplified and may differ
from the actual product.
On screen messages, figures or illustrations in this manual may vary slightly or be
simplified from the actual messages and product.
We sincerely hope that the contents of this manual are true and complete. If you
find any information to have been omitted, or if the information within is confusing
or mistaken please, contact your retailer or T&D Corporation.
Microsoft ® , Windows ® and WindowsNT ® are registered trademarks of Microsoft
Corporation USA and are binding in the USA and all other countries. Company
names and product names are trademarks or registered trademarks of each
company.
The Warranty that comes with this Manual can not under any cicumstance be
reissued, so please keep it in a safe place. The Manual itself can be downloaded
from our Website: http://www.tandd.com
*Please carefully observe the following safety measures when using our
product.
Explanation of Picture Symbols
This symbol denotes an important warning or caution. Inside or near the
symbol will appear another symbol giving details.
(EX: stands for ELECTROCUTION)
This symbol denotes a forbidden action. Inside or near the symbol will
appear another symbol giving details.
(EX: stands for DO NOT TAKE APART)
This symbol denotes an action that you must take. Inside or near the
symbol will appear another symbol giving details.
(EX: stands for TAKE PLUG OUT OF SOCKET)
DANGER
If water or a foreign object enters the case, immediately cease using
it.
Store all battery, sensors and Thermo Recorder units out of the reach
of children. It is dangerous to swallow battery.
Please be careful when using in overly hot or cold environments,
touching the units may cause burns or frostbite.
The RTR-52Pt is a devices to measure temperature. Do not use this
unit for any purpose other than temperature measurement.
CAUTION
Please use the latest version of our software which can be
downloaded free of charge from our Website.
Pay attention to water leakage or foreign objects entering into the
unit case as in the following cases.
The case was closed with dust, hair, etc., on the rubber packing or in the
groove for the packing.
The rubber packing was damaged. (In this case, please purchase the
optional maintenance set.)
The unit suffered from significant temperature change while wet.
especially if the temperature change was from high to low.
Do not use or store the unit in places such as listed below:
It may cause electrocution, fire or damage to the unit or to your
computer.
Areas exposed to direct sunlight
Areas exposed to water or high-pressure water flow.
Areas exposed to organic solvents, corrosive gas and oils.
Areas exposed to strong magnetic fields
Areas exposed to static electricity.
Areas exposed to fire or overheating.
Areas exposed to excessive dust or smoke.
When using Sensor Adaptor RTR-05P1, please take note of the follow-
ing:
This sensor adaptor is not waterproof. Only use in an environment
where there is no condensation or possibility of wetness.
When connecting the sensor, please follow the connection diagram on
the terminal block. Please make sure to securely tighten the screws to
the terminal block so as there is no chance of becoming unfastened.
Cracks may develop in the unit casing if it comes into contact with
hazardous substances such as oil products.
When using the unit in such an environment, protect the unit by plac-
ing it inside a polyethylene bag.
