Type
5. PHASER ★
(S/R = ON)
Adds modulation to the sound.
* When Send/Return mode is on:
(S/R = OFF)
* When Send/Return mode is off:
6. TREMOLO/PAN
Cyclically varies the volume or
pan.
7. DISTORTION ★
Intensely distorts the sound.
8. OVERDRIVE ★
Mildly distorts the sound.
9. FUZZ ★
Adds overtones to the sound to
distort it intensely.
10. WAH ★
Creates a wah effect.
11. OCTAVE
Adds a lower pitch at octave in-
tervals.
12. COMP ★
(LIMIT = OFF)
Makes the volume more consis-
tent.
* When Effect Limit mode is off:
(LIMIT = ON)
* When Effect Limit mode is on:
13. EQUALIZER ★
Adjusts the volume of each fre-
quency range.
14. LO-Fi ★
Gives the sound a low-fidelity
character.
15. NOISE GEN ★
Creates noise.
16. RADIO TUNING
Simulates the sound heard from
a radio.
17. SLICER ★
Repetitively cuts the sound. A
flanger is also applied.
18. RING MOD ★
Gives a metallic character to the
sound.
19. CHROMATIC PS
This is a two-voice pitch shifter
that changes the pitch in semi-
tone steps.
CTRL 1 (display)
DEPTH/RESONANCE (d-r) ★
Adjusts both DEPTH and RESO-
NANCE simultaneously.
DEPTH/MANUAL (dPt)
Adjusts the depth of modulation.
If the CTRL 2 knob (RATE) is
turned all the way to the left, this
knob adjusts the pitch (MANU-
AL).
DEPTH (dPt)
Adjusts the amount of volume/
pan change.
DRIVE (drV) ★
Adjusts the amount of distortion.
DRIVE (drV) ★
Adjusts the amount of distortion.
DRIVE (drV) ★
Adjusts the amount of distortion.
SENS (SnS)
Adjusts the sensitivity of the wah
effect.
-2OCT LEVEL (oC2)
Adds a pitch two octaves below.
SUSTAIN (SuS)
Adjusts the amount of compres-
sion.
SUSTAIN (SuS)
Adjusts the amount of compres-
sion.
LOW (Lo) ★
Adjusts the volume of the low-
frequency range.
SAMPLE RATE (rAt)
Adjusts the sampling frequency.
COLOR (CoL)
Adjusts the tone of the "shhh"
noise.
TUNING (tun)
Adjusts the tuning drift of a ra-
dio.
TIMING PTN (P01–16)
Specifies the timing at which the
sound is cut. (*2)
FREQUENCY (Frq) ★
Adjusts the pitch of the metallic
sound.
PITCH 1 (-C–CC)
Adjusts Pitch 1 in semitone steps
over a +/-1 octave range.
Chapter 2. Using Effects
CTRL 2 (display)
RATE (rAt)
Adjusts the rate of modulation.
RATE (rAt)
Adjusts the rate of modulation. If
this knob is turned all the way to
the left, the modulation will stop,
and the CTRL 1 knob (DEPTH)
will adjust the pitch (MANUAL).
RATE (rAt)
Adjusts the speed of volume/
pan change.
TONE (ton) ★
Adjusts the tone.
TONE (ton) ★
Adjusts the tone.
TONE (ton) ★
Adjusts the tone.
FREQUENCY (Frq)
Adjusts the pitch of the effect
sound.
-1OCT LEVEL (oC1)
Adds a pitch one octave below.
ATTACK (Att)
Adjusts the sense of attack.
RELEASE (rEL)
Adjusts the sense of release.
MID (Mid) ★
Adjusts the volume of the mid-
frequency range.
BIT (bit) ★
Adjusts the bit depth.
QUALITY (qLt) ★
Adjusts how often scratch noise
(typical of an analog record) will
be heard.
NOISE LEVEL (noS)
Adjusts the volume of the noise.
RATE (t1–t8)
Adjusts the length of TIMING
PTN. (*3)
SENS (SEn) ★
Adjusts the depth of frequency
modulation.
PITCH 2 (-C–CC)
Adjusts Pitch 2 in semitone steps
over a +/-1 octave range.
CTRL 3 (display)
BALANCE (bAL)
Adjusts the volume balance be-
tween the direct sound and effect
sound.
RESONANCE (rES) ★
Gives a distinctive character to
the sound.
WAVEFORM (trM/PAn)
Changes the type of curve by
which the volume or pan will
change cyclically. Turn the knob
toward the left for volume
change, or toward the right for
pan change.
LEVEL (LEV) ★
Adjusts the volume.
LEVEL (LEV) ★
Adjusts the volume.
LEVEL (LEV) ★
Adjusts the volume.
RESONANCE (rES) ★
Adjusts the peak amount of the
wah.
DIRECT LEVEL (dir)
Adjusts the volume of the direct
sound.
LEVEL (LEV) ★
Adjusts the volume.
LEVEL (LEV) ★
Adjusts the volume.
HIGH (Hi) ★
Adjusts the volume of the high-
frequency range.
FILTER (FLt)
Adjusts the filter depth.
LEVEL (LEV) ★
Adjusts the level of the "shhh"
noise.
FREQUENCY RANGE (Frq)
Adjusts the tonal character.
FEEDBACK (Fdb) ★
Adjusts the depth of the flanger.
BALANCE (bAL)
Adjusts the volume balance of
the direct sound and effect
sound.
BALANCE (bAL)
Adjusts the volume balance of
the direct sound and effect
sound.
21
