SpaNet SV2 Quick Reference Manual page 2

CHANGING LIGHT MODES
When light is first turned on the keypad
will display the light mode menu
showing current light mode in use.
Press or button to step
through choice of light modes:
WHTE White Light
UCLR User Colour
FADE Fade Effect
STEP Step Effect
Press button to confirm light
mode selection.
Dependant on light mode selected the
keypad will then display one of three
light mode option screens.
CL:xx User Colour Number
L.SPD Light Transition Speed
L.BRT Light Brightness
Press or button to adjust
each setting.
Press button to save each setting
and move to the next setting.
Note: All light settings are saved for
future ON / OFF use.
FULL KEYLOCK
Press and hold this button combination
until LOCK appears on the display:
+ +
up down pump a
Repeat button combination to unlock.
Note: Once locked if any button is
pressed the key stroke will be ignored
and the display will show LOCK.
PARTIAL KEYLOCK
Press and hold this button combination
until LOCK appears on the display:
+ +
up down pump b
Repeat button combination to unlock.
Note: Once locked only pumps, blower, light
and sanitise buttons can be used. Access
to all other buttons is disabled.
SETUP MENU
The setup menu allows customisation
of the adjustable controller settings.
Menu access and item adjustments are
carried out as follows:
Press and hold and buttons
together until [MODE] is displayed.
Press or to navigate through
setup menu items.
Press to enter item adjustment.
Press or to adjust setting.
Press to confirm setting and exit.
All setup menu items follow the same
adjustment procedure. Menu items that
can be adjusted are as follows:
[MODE] OPERATING MODES
Operating modes effect heating and
filtration behaviour. The choices are:
NORM Normal heating & filtration
ECON Heating only during filtration
AWAY Heating disabled. Filtration
reduced to 1hr p/day.
WEEK Mon-Thu
(works like AWAY mode)
Fri-Sun (works like NORM mode)
[FILT] DAILY FILTRATION TIME
Adjust the hours of filtration per day.
Filtration limits differ for type of pump:
Circ Pump 1-24 hrs
(2A or less)
Jet Pump 1-8 hrs
(2spd or 1spd)
[F.CYC] FILTRATION CYCLES
This setting defines how often filtration
cycles occur. Filtration can be set to run
every 1/2/3/4/6/8/12 or 24 hrs
[SNZE] SLEEP TIMERS
Used to disable automatic heating and
filtration during certain times of day or
night. Upon entering SNZE menu there
are four choices:
1.SNZ Sleep Timer #1
2.SNZ Sleep Timer #2
R.SET Reset timers to default
EXIT Exit sleep timer menu
Only one sleep timer needs to be set
however two timers are provided to
facilitate different sleep settings on
different days. Each sleep timer setting
consists of a week day setting, start
time and stop time (refer below).
x.DAY Day(s) of operation
x.BGN Sleep timer begin time
x.END Sleep timer end time
Use the Up, Down & OK buttons to
adjust and confirm each setting.
[P.SAV] POWER SAVE (off peak)
Reduce operating costs by limiting
filtration and heating to occur during
cheaper off peak power periods. There
are three P.SAV modes:
OFF P.SAV disabled
LOW Off-peak filtration only
HIGH Off-peak filtration & heating
Once P.SAV mode is selected the begin
and end times of the PEAK power tariffs
must be set so the control knows NOT
to operate during those peak hours.
BGN Peak power begin time
END Peak power end time
[W.CLN] AUTOMATIC SANITISE
Adjust the start time of the 10 minute
automatic daily sanitise cycle. Setting
can be adjusted from 0:00 to 23:59.
[D.DIS] DEFAULT DISPLAY MODE
Used to adjust the default display mode
shown on the keypad. Setting choices:
W.TMP Water Temperature
S.TMP Set Temperature
TIME Clock
[T.OUT] LOAD TIME OUTS
All accessory loads (pumps & blowers)
automatically turn off after a time out
period has elapsed. Adjust the time out
period from 10-60 minutes.
[H.PMP] HEAT PUMP MODE
Defines heat pump operating mode:
AUTO Heat & Cool
HEAT Heat Only
COOL Cool Only
OFF Heat Pump Disabled
[H.ELE] ELEMENT BOOST
Enables/disables SV electric element to
boost heat pump heating if the water
o
temperature is 2 C or more below set
temperature point OR the heat pump
has been operating for more than 1hr.
OFF Element disabled
(heat pump only)
ON SV element + heat pump
