Contents Of The Kit - Kronos InTouch 9100 Standard Installation Manual

Chapter 1 Before You Install the InTouch

Contents of the kit

The contents of your kit may vary depending on the model and the options
ordered for your site. For example, the Standard model transformer and Slim
Profile wall transformer are separately orderable items.
The bag of hardware is the same for the two models except where noted:
Part
Maintenance badge
10 x1 1/4 self-tapping screw
Plastic wall anchors
Ethernet strain relief clip
M3 x 10 screw
Strain relief clip
Security wrench (torx)
M4 x10 torx screw
SEMS M3 x 6 screw
10
Quantity
1
3
3
1
2
Standard: 2
Slim Profile: 1
1
1
3
Where Needed
Supplied for magnetic stripe, HID
proximity, bar code, and smart card
readers.
• Standard model: "Step 3: Mount the
base" on page 31
• Slim Profile model:
base" on page 68
• Standard model: "Connect Ethernet
cable" on page 48
• Slim Profile model:
power and cables to the main board"
page 77
• Standard model: "Secure the cables
with the strain relief clip"
• Slim Profile model:
cables with the strain relief clip"
page 73
• Standard model: "Close the cover and
secure the screws"
• Slim Profile model:
and secure the screws"
• Standard model: "Install the transition
board option kit" on page 40 and
6: Attach the plastic transformer plate"
on page 43
• Slim Profile model: N/A
"Step 3: Mount the
"Step 7: Connect
on
on page 51
"Step 6: Secure the
on
on page 57
"Close the cover
on page 81
"Step
