- Page 1 ® PeakTech 5110/5115 Digital-Thermometer Bedienungsanleitung / Operation Manual 5110 1-Kanal/CH 5115 2-Kanal/CH...
-
Page 2: Safety Precautions
1. Safety Precautions This product complies with the requirements of the following European Community Directives: 2004/108/EC (Electro- magnetic Compatibility) amended 2004/22/EC (CE- Marking). Pollution degree 2. To ensure safe operation of the equipment and eliminate the danger of serious injury due to short-circuits (arcing), the following safety precautions must be observed. - Page 3 Do not operate the equipment near strong magnetic fields (motors, transformers etc.). Keep hot soldering irons or guns away from the equipment. To avoid electrical shock, do not use this instrument when voltages at the measurement surface exceed 24V AC or To avoid damage or burns, do not make temperature measurement in microwaves ovens.
- Page 4 Measuring instruments don’t belong to children hands. 2. Introduction These instruments are portable 3 ½ digit, compact-sized digital thermometer designed to use external K-type thermocouple as temperature sensor. Temperature indication follows Reference Temperature/ Voltage tables (N.I.S.T. Monograph 175 Revised to ITS-90) for K-type thermocouples. -17-...
-
Page 5: Specifications
-50° C..1300° C; -58° F..2000° F (P 5115) Resolution 0,1° C / 1° C; 0.1° F / 1° F; 1 K (P 5110) 0,1° C / 1° C; 0.1° F / 1° F (P 5115) Temperature 0.1 times the applicable accuracy specifi- Coefficient cation per °... - Page 6 Reading rate 2.5 times per second Input Connector Accepts standard miniature thermocouple connectors (flat blades spaced 7,9 mm, center to center). Operating Tem- 0 ... +50° C (32° F ... 122° F) < 80 % perature Storage Tem- -20° C ... +60° C (-4° F ... 140° F) < 70 % perature Probe Type-K-thermocouple...
- Page 7 Accessories Holster, Battery, Type-K thermocouple (P 5115 2 St.) 3.1. Technische Daten ® PeakTech 5110: Range Accuracy -50° C ... 0° C ± 2° C 0° C ... 1000° C ± 0,5% rdg. + 1° C 1000° C ... 1300° C ±...
-
Page 8: Operating Instructions
To select the alternate display resolution, press the corresponding “0.1° /1° ” key (P 5115) / (P 5110: 0,1° or 1° key). 4.3. MAX Mode Pressing the Max key to enter the MAX mode. The thermo- meter then records and updates the maximum absolute value and the MAX annunciator appears on the display. - Page 9 Pressing the Backlight key to turn on the LCD-backlighting Function. Pressing the Backlight key again to turn off the LCD- backlighting function 4.6. Tc (Temperature Compensator) (only P 5110) Checking Mode. Pressing and hold the "Tc" key to enter the temperature compensator-checking mode.
- Page 10 4.7. Preparation 1. Ensure battery is in place, if LCD-display shows the battery symbol, the battery should be replaced. 2. Make sure all function keys are set properly. (HOLD) switch is on an "OFF" position, make sure no "DATA- HOLD" displayed on LCD. 3.
- Page 11 4.9. Adjustment for T1-T2 measurement (only P 5115) The choice of the input connectors with the correspond indicated buttons T1, T2 or T1-T2 at the unit. To measure the differential temperature connect the thermocouples to the inputs and press “T1-T2”. The indicated temperature value is the difference between T1 and T2.
- Page 12 4.10. Battery Replacement Power is supplied by a 9 V “transistor” battery (NEDA 1604, IEC 6F22). The battery sign appears on the LCD when replacement is needed. To replace the battery, remove the screw from the back of the meter and lift off the battery cover. Remove the battery from its contacts.
