SERVICE MANUAL

X1161/X1261/X1161A/X1161N/X110/H5360
Date
Revise Version
2009.05.22
2009.06.25
2009.08.06
2009.09.16
Copyright September, 2009
SI :
V1.0
Initial Issue
V2.0
Modify Chapter 5
1. Add X1161's extended models: X1161A, X1161N,X110
V3.0
2. Update Engineering Spec. of Chapter 1
3. Modify Chapter 4
1. Add X1261's extended models: H5360
V4.0
2. Update Engineering Spec. of Chapter 1
3. Modify Chapter 4
All Rights Reserved
TSE:
Description
P/N: 36.8CP01G001
Check:
Approved:
