INSTALLATION INSTRUCTIONS
FOR COMPLETE SLOAN HAND
DRYER SPOUT
Unless otherwise noted, Sloan Valve Company warrants this product, manufactured and sold for commercial or industrial uses, to be free from defects
in material and workmanship for a period of three (3) years (one (1) year for special finishes, SF faucets, PWT electronics and 30 days for PWT software)
from date of first purchase. During this period, Sloan Valve Company will, at its option, repair, replace, or refund the purchase price of any product
which fails to conform with this warranty under normal use and service. This shall be the sole and exclusive remedy under this warranty. Products must
be returned to Sloan Valve Company, at customer's cost. No claims will be allowed for labor, transportation or other costs. This warranty extends only
to persons or organizations who purchase Sloan Valve Company's products directly from Sloan Valve Company for purpose of resale. This warranty
does not cover the life of the batteries.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT IS SLOAN VALVE
COMPANY RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY MEASURE WHATSOEVER.
IMPORTANT
Read this entire installation manual to ensure proper
installation. When finished with the installation, file this
manual with the owner or maintenance department.
Compliance and conformity to local codes and ordinances is
the responsibility of the installers.
Separate parts from packaging and make sure all parts are
accounted for before discarding any packaging material.
If any parts are missing, do not begin installation until you
obtain the missing parts.
TOOLS REQUIRED FOR INSTALLATION
• Slotted screwdriver
PRIOR TO INSTALLATION
Prior to installing the Hand Dryer spout install the items listed below.
IMPORTANT:
• INSTALL ALL ELECTRICAL WIRING IN ACCORDANCE
WITH NATIONAL/LOCAL CODES AND REGULATIONS.
• INSTALL ALL PLUMBING IN ACCORDANCE WITH
APPLICABLE CODES AND REGULATIONS.
• A 24 VAC STEP-DOWN TRANSFORMER MUST BE USED.
• USE APPROPRIATE PRECAUTIONS WHILE CONNECTING
THE POWER SOURCE.
EHD-511 SPOUT
LIMITED WARRANTY
Turn OFF electrical power to the electrical outlets, then
unplug all electrical units prior to installation. Electrical
power MUST remain off until installation is complete.
Wear all proper safety equipment prior to installation.
• Wire stripper/crimping tool
THIS PRODUCT CONTAINS MECHANICAL AND/OR
ELECTRICAL COMPONENTS THAT ARE SUBJECT TO NORMAL
WEAR. THESE COMPONENTS SHOULD BE CHECKED ON A
REGULAR BASIS AND REPLACED AS NEEDED TO MAINTAIN
If you have questions about how to install your hand dryer, consult
!!! IMPORTANT !!!
THE VALVES PERFORMANCE.
your local Sloan Representative
or call Sloan Technical Support at:
1-888-SLOAN-14 (1-888-756-2614)
Code No. 0816673
Rev. 2 (07/15)
