Bauhn ATVS65-815 Getting Started Manual

65" 4K Ultra High Definition LED LCD Smart TV
Model number: ATVS65-815
GETTING STARTED
1

PARTS LIST

In the box you will find:
1 x 65" (164cm) 4K Ultra High Definition LED LCD Smart TV
1 x Remote Control
2 x AAA Activ Energy Batteries (not pictured)
1 x Mini AV Cable (not pictured)
1 x Mini Y/Pb/Pr Adaptor Cable (not pictured)
2 x Stand Bases (including screws)

WHAT YOU WILL NEED

Screwdriver (for stand installation)
Antenna Cable
Broadband Internet Connection (to access Smart TV
and Catch Up TV features)
2

CONNECTIONS

1 LAN Input
2 USB Input
3 Video Input (Composite)
4 Antenna Input
5 Coaxial S/PDIF Output
6 Optical S/PDIF Output
7 Headphones Output
8 Mini Y/Pb/Pr Input (Component)
9 Mini AV In 2 Input (Composite)
10 HDMI Inputs
3

CONNECT TO POWER

1 Install the stand (see page 5 of the instruction
manual).
2 Connect the antenna cable to the ANT socket of
the TV.
3 Connect a RJ45 LAN cable to the LAN socket
of the TV (for wired Internet connection); or turn
on your Wi-Fi modem/router (for Wi-Fi Internet
connection).
4 Insert batteries into the remote control.
5 Connect the TV power cord into the mains power
socket and turn on the mains power.
6 Press the
on the power to the unit. The standby light will turn
blue and the TV screen will display the initial setup.
4

EASY SETUP SCREEN

The On-Screen Display gives you easy
instructions for setting up the unit. Follow
the OSD instructions to connect the TV
to the Internet and scan TV channels.
Please refer to the instruction manual for
detailed information.
button on the remote control to turn
1 2
3
6 7 8 9
4 5
10
