Summary of Contents for Bauhn ATV40FHDS-0720
- Page 1 ” MODEL: ATV40FHDS-0720 User Manual...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents TV Guide Welcome On-Screen Set Up Recording Contents Networking Recording Live TV Unpack and Prepare TV Setting Menus Scheduled Recording What's in the box Channel Playback Picture Important Tips Pause Live TV (Time-shift) Sound Attaching the stand USB Mode Network Wall-mounting the TV Set up... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the box Before installing your new TV, check you have everything needed. In the box you will find: A. 40" Full HD Smart TV B. Remote Control C. AAA Activ Energy Batteries D. TV Stands E. -
Page 5: Important Tips
Important Tips • Place the TV on a level surface. • Place the TV away from any source that may generate heat or vibrations. • Make sure there is enough space around vents for airflow. • The remote control works up to 6 metres away from the TV. •... -
Page 6: Attaching The Stand
Attaching the stand • Unplug the TV from the power outlet before installing or removing the stand. • Only touch the frame, not the screen. • It is highly recommended to use safety straps for securing the TV. Unless you are wall-mounting the TV, you will need to attach its stand/legs. -
Page 7: Wall-Mounting The Tv
Wall-mounting the TV • Unplug the TV from the power outlet before wall-mounting. • Contact a professional for assistance with wall-mounting the TV. Required 200mm • VESA Mounting Bracket • 4 x M6*10mm screws (or longer as required) The TV comes with holes on the back panel for use with wall-mounting brackets (bracket not included). -
Page 8: Connect To Power
Connect to power Don't forget to plug in the TV to the power outlet. Leave the power switched off until installation is finished. Make sure the TV is switched off at the power outlet Image is an example only. Plug on your TV may vary. until you have finished connecting your cables. -
Page 9: Controls And Connections
Controls and Connections Get to know your TV On/Standby light and Remote sensor Buttons on the TV • When the TV is on standby, press this button to turn the TV on. • When the TV is on, press once to access the on-screen control menu. -
Page 10: Ports On The Tv
Ports on the TV 10 | CONTROLS AND CONNECTIONS... - Page 11 Connect to your broadband modem using a network cable (not included) for the best streaming experience. However, the TV also has built-in Wi-Fi. Connect to your amplifier or soundbar using an AUX cable (not AUDIO OUT included). Turn down the TV volume to 0 and use your external device to control the volume.
-
Page 12: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure the batteries are correctly aligned and properly pushed into AAA size place. batteries included Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 13: Using The Remote Control
Using the Remote Control To use the remote, point it towards the remote sensor at the front of the TV. The remote will not operate if its path is blocked. The remote has a range of up to about 6 metres from Remote Hints and Tips the TV at an angle of up to 30 degrees to either side of the sensor, as illustrated below. -
Page 14: Buttons & Functions
Buttons & Functions (POWER): Switch the TV to On or Standby NUMBER BUTTONS : Directly enter channels or input password INFO : Display program information (MUTE): Mute or restore sound RED/GREEN/ INFO LIST YELLOW/BLUE: Functions are according to LIST : Display the DTV channel list the on-screen display : Return to the previous screen or (MENU) : Press once to enter the quick... - Page 15 GUIDE P.MODE S.MODE SOURCE P.MODE : Change the picture to one of S.MODE : Change the sound to one the preset settings of the preset settings : Turn the volume up or down : Go to the next or previous channel (SOURCE) : Access the input sources : Switch between TV and Teletext...
-
Page 16: On-Screen Set Up
On-Screen Set Up Image is an example only. Plug may vary. Make sure equipment is properly connected (as shown on pages 10-11) before connecting the TV to power. Make sure the TV is plugged in at the power socket and switched (POWER) button on. -
Page 17: Networking
Networking If the TV isn't connecting to the internet check the troubleshooting section for more info! You can set up your TV so that it can access the Internet through your home network using a wired or wireless connection. Connecting to a Wireless Network Advanced settings: If you wish to add a hidden Wi-Fi network, go to (MENU) button on the remote to select... - Page 18 Connecting to a Wired Network • Connect an ethernet cable to the LAN port on the back of the TV. (MENU) button on your remote to select • Press the Network. • Change the Connection Type setting to 'Wired'. The TV will automatically pick up the network setting from the modem and connect to the network.
-
Page 19: Tv Setting Menus
TV Setting Menus Menu Navigation Buttons Press the (MENU) button twice to display the TV main menu settings. See the guide below for all the Once you have programmed any settings, the TV will retain them in other buttons you'll need to use to adjust and change its memory until you change them, your settings. - Page 20 Support • Advanced Settings: • HbbTV • Colour Temperature, SDR To • Country • Software Update (USB) HDR, HDR, Noise Reduction, • HDMI CEC • Internet Update Check MPEG NR, Dynamic Contrast, Film Mode, PC Mode, Overscan, • PVR File System •...
-
Page 21: Channel
Channel Option Description Automatically tunes all available free-to-air TV channels. Adjust settings (default Auto Tuning settings are set for Australia), select 'Search' and press OK. DTV Manual Manually select the broadcast channel frequency and tune digital TV channels. Tuning ATV Manual Manually select and tune analog TV channels. - Page 22 Channel Edit Use the buttons to highlight a channel. Option Description YELLOW to select the channel then Move the channel location on the list. Press Move buttons to select a position and press OK to confirm it. use the Skip BLUE to skip the highlighted channel.
-
Page 23: Picture
Picture Picture Mode : Super bright and clear picture settings for ultra bright viewing environments such as store-fronts. : Brighter and clearer picture settings for bright viewing environments. Standard : Settings are optimised for viewing movies. Movie : Picture setting for general viewing environments and is energy efficient. Home : Adjust settings to best suit your viewing environment and content. User User Mode settings Option... - Page 24 Aspect Ratio Option Description This item is used to adjust the picture size. Sizes may differ between Noise input sources. Reduces screen noise/static. Reduction PTP (Pixel to Pixel): Displays the picture in the same resolution as received by the TV. Reduces MPEG (video) noise to improve MPEG NR picture quality.
-
Page 25: Sound
Sound Option Description Sound Mode Movie Music News Game Sports Standard User Below options are available when sound is set to User. Option Description Equalization Adjust selected frequencies. Surround Adjust surround sound effect from your TV speakers. Dialogue Improves the clarity of voice. Enhancer AVC (Auto Adjust the increase or decrease of audio when you change channels, video... - Page 26 Balance Adjust the audio output between the left and right speakers. S/PDIF Mode Set the digital sound output setting. Audio Description (AD) provides an additional audio track for visually AD Switch challenged persons (DTV only, subject to program). AD Volume Adjusts the volume for the Audio Description (AD) when it's switched on.
-
Page 27: Network
Network You can set up your TV so that it can access the Internet through your home network using a wired or wireless connection. Make sure you have a network cable connected to the TV Wired Network Settings Option Description Connection Switch between Wired and Wireless connections. - Page 28 Wireless Network Settings Option Description Connection Switch between Wired and Wireless connections. Type Wireless Select a wireless network to connect to. Networks Enter the password of the selected wireless network. Press the OK Password button to make the on-screen keyboard appear. Visible Tick this box to see the password in plain text.
-
Page 29: System
System Option Description Language Select your preferred On Screen Display language. Subtitle Turn subtitles On or Off (available for digital channels, depending on the program). Turn On or Off. Subtitles for hearing impaired people (available for digital channels, depending on the Subtitle Hearing Impaired program). - Page 30 HDMI CEC Setup This feature allows for your TV and your connected HDMI device to be controlled by one remote control. It also means you can turn them both on or off simultaneously. (SOURCE) button on the unit or remote control to select the HDMI input source. Press the Option Description...
-
Page 31: Pvr File System
PVR File System To make changes to PVR (Personal Video Recording), ensure your USB drive is inserted into the TV. Check the troubleshooting section if you're having problems setting up your USB device. Option Description Select Disk Select a disk used for PVR. Format Start Format the connected USB disk. -
Page 32: Lock
Lock 0000 Factory Password: Enter the factory password '0000' using the number buttons 4711 Master Password: on the remote and select 'OK' on-screen. If you changed your password but forgot it, you can still use the master password. Option Description Lock System Turn system lock on/off. -
Page 33: Timer
Timer Option Description On: Automatically syncs the TV clock according to the DTV broadcasting time. Auto Sync Off: Manually adjust the TV clock. Time Zone Adjust your timezone. Clock Displays the DTV signal time or set the time manually. Sleep Timer Select the desired Auto Sleep (Standby) duration. -
Page 34: Support
Support Option Description Software Update (USB) Update the software using the USB memory device. Internet Update Check Update the software using the internet. NetReady Version Display current software version information. Installation Guide Access the first time installation setup guide. View End-User License Read and accept/decline the EULA. -
Page 35: Quick Menu
Quick Menu The Quick Menu gives you access to selected menu settings without the hassles of navigating through the full menu. Press on your remote once to access this. (MENU) Option Description Select the picture best suited to the content you are viewing. Picture Mode Standard Movie Home... - Page 36 Sports Mode Optimise picture and sound to give the most immersive experience possible. Options: On / Off. Select your preferred audio language (available for digital channels if multiple audio languages are Audio Languages broadcasted). Audio Only Turns off the TV screen and listen only to the audio. Press the OK button to get the picture on screen again. More Access the full menu settings.
-
Page 37: Smart Tv
Smart TV Smart TV Applications • Netflix • Yahoo! Weather Before you start using apps, your TV must be connected to the internet. • YouTube • NetRange Smart TV apps • Amazon Prime Video • Toon Goggles The speed of your internet connection determines the quality of your audio/video experience when you •... -
Page 38: Screencast
Screencast App Portal The Screencast feature enables you to mirror the display NetRange Smart TV apps gives you access to number from a compatible Android device like a smartphone of other content and service providers. or tablet on the TV screen by connecting your mobile Some apps may require a paid subscription. -
Page 39: Web Browser
Web Browser Refresh Address bar Add to Bookmark Go Forward Home Using the web browser, you can surf the Internet on the TV similar to how Go Back Settings you would do on a PC. NOTE: Use a wired or wireless keyboard and mouse (not provided) for an easier web browsing experience. -
Page 40: Tv Guide
TV Guide (Free to air TV) TV Guide Functions To access the TV Guide, press the Function Remote Button GUIDE button on the remote. Select a channel, time or program To activate the TV Channels use the GUIDE buttons to select a channel in the left column, then press OK to Display programs by time or channel GREEN... -
Page 41: Recording
Recording Important Tips: • Back-up your personal data before plugging in your USB to the TV. We do not assume liability for any loss of data due to misuse or malfunction. • You cannot change channels while in recording mode. •... -
Page 42: Recording Live Tv
Before you can record with this TV Recording, scheduled recording and pause (including time-shift recording), you must live TV functions only work in DTV mode insert your USB storage device into the (free-to-air). USB port. Recording Live TV Start Recording / REC Press once - start recording. -
Page 43: Pause Live Tv (Time-Shift)
Pause Live TV (Time-shift) Recording, scheduled recording and pause live TV functions only work in DTV mode Temporarily pause the live TV signal, then resume (free-to-air). playback at your convenience. Before you can record with this TV (including time-shift recording), you must insert your USB storage device into the USB port. -
Page 44: Usb Mode
USB Mode You can only play Photos in the Photo category, Music in the Music category and so on. Make sure you select the correct category for the file you wish to play. Set up Function Remote Button Insert your USB into a USB port on the TV. Choose a Source or File (SOURCE) button to select 'Media' mode. - Page 45 Playback Functions Playback of different media types have different controls. Photo Music Function Remote Button Function Remote Button Navigate to a folder or file Navigate to a folder or file Play your track Display your photo Rewind or fast forward the current Hide or display the on-screen toolbar track...
- Page 46 Video Function Remote Button Navigate to a folder or file Play your video Only supported file types will be displayed. See the Pause your video specifications table for supported file types. Resume playback Stop playback Rewind or fast forward the current track Restart or skip the current track Change advanced settings...
-
Page 47: Troubleshooting
Troubleshooting If you have problems with your TV, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 886 649. Problem Solution Make sure that the batteries are installed with their poles (+/–) in the correct direction. Remove any obstacles between the remote control and remote control sensor on the TV. - Page 48 Problem Solution Ensure that connection to the device is correct and that all cables are fully inserted. There is no picture/ Remove and reconnect all cables connected to the TV and the external devices. Try new cables if possible. sound or distorted picture/sound from Restart the connected devices by unplugging each device's power cord and then plugging it in again.
- Page 49 Problem Solution If you are using Wi-Fi, make sure the Wi-Fi password is entered correctly. Turn off the access point. Wait for 2 minutes and then turn them back on. Ensure that there are no obstacles between the TV and the access point. (The Wi-Fi strength can be decreased by appliances, cordless phones, stone walls/fireplaces, etc.) Reduce interference by not using or turning off other wireless devices.
-
Page 50: Specifications
Specifications With stand: 904.3 x Active screen size 39.5” (100.3cm) (diagonal) 180.1 x 561.5 mm Dimensions (W x D x H) Resolution Without stand: 904.3 x 1920 x 1080 80.3 x 514.5 mm Refresh rate 60Hz 5.7 kg HDMI version 1.4a Weight Gross... -
Page 51: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can National Television and Computer Recycling be a suffocation hazard for babies and young children, please ensure all packaging materials are out of Scheme reach and are safely disposed of. -
Page 52: Warranty Information
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 53: Repair And Refurbished
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 54 Notes...
- Page 55 Notes...
- Page 56 Online support Visit www.bauhn.com.au for software updates to keep your TV up-to-date, as well as the latest User Manual for information on the updated features. Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
