Package Contents
• HD Wire-Free Add-On Security Camera
• Camera Antenna*
• Rechargeable Power Pack*
• Power Pack Adapter*
• Mounting Kit*
• Quick Start Guide
* Per camera in multi-camera packs.
Installation Tips
The wire-free cameras use a Passive InfraRed (PIR)
sensor to ensure video is only recorded when motion
is detected. Follow the tips below for more accurate
motion detection and to optimize battery life:
• See images to the right
for ideal setup. It is
recommended to place
your camera at least 6ft
(2m) above the ground and
angle it slightly downward
toward the monitoring area,
excluding any busy areas
(e.g., sidewalks or roadways).
• Ensure the camera image
is free of obstructions (i.e.,
tree branches).
• Position the camera no more
than 20ft (6m) away from
the area you wish to monitor.
• For best performance,
position the camera so that objects of interest will move
from side-to-side across the camera image, rather than
moving towards or away from the camera.
• Install the camera within range of the wireless receiver
(noted in the camera's specifications).
• This camera is weather resistant for outdoor use (IP65
rated). Installation in a sheltered location is recommended.
• Battery life will vary based on temperature, settings and
number of events.
Safety Precautions
• Read this guide carefully and keep it for future reference.
• Follow all instructions for safe use of the product and handle with
care.
• Use the camera within given temperature, humidity and voltage
levels noted in the camera's specifications.
• Do not disassemble the camera.
• Do not point the camera directly towards the sun or a source of
intense light.
• Use only the supplied regulated power supply provided with the
product. Use of a non-regulated, non-conforming power supply
can damage the product and void the warranty.
• Periodic cleaning may be required. Use a damp cloth only. Do not
use any harsh, chemical-based cleaners.
Resources
Need Help?
Visit us online for up-to-date software
and complete instruction manuals
1
Visit lorextechnology.com
Search for the model number
2
of your product
Click on your product in the
3
search results
4
Click on the Downloads tab
Dimensions
3.8" /
7.2" /
96mm
182mm
Disclaimers
• For a full list of compatible recorders, visit
lorextechnology.com/compatibility
• Not intended for submersion in water. Installation in a sheltered
location recommended.
Copyright © 2017 Lorex Corporation
As our products are subject to continuous improvement, Lorex reserves
the right to modify product design, specifications and prices, without
notice and without incurring any obligation. E&OE. All rights reserved.
LWB3801AC1_LWB3901AC1_QSG_EN_R1
HD Wire-Free Add-On Security Camera
Quick Start Guide
English Version 1.0
6.1" /
154mm
LWB3801AC1 / LWB3901AC1
www.lorextechnology.com
