- Page 1 User Manual SP8SDI SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater All Rights Reserved Version: SP8SDI _2017V1.1...
- Page 2 SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater MAINTENANCE Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this unit. PRODUCT SERVICE 1) Damage requiring service: The unit should be serviced by qualified service personnel if: (a)The DC power supply cord or AC adaptor has been damaged;...
- Page 3 SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater images, data or other recorded content. The items listed are not exclusive, but are for illustration only.) (h)PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY. WARRANTY If your product does not work properly because of a defect in materials or workmanship, our Company (referred to as "the warrantor"...
- Page 4 SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater TABLE OF CONTENTS Specifications Package Contents Panel Descriptions Connecting and Operating Typical Application Product service Warranty...
-
Page 5: Specifications
SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater SPECIFICATIONS Re-clocking Function SDI Standards SD-SDI, HD-SDI,3G-SDI HD/SD-SDI Detection Auto SMPTE 259M Supported Protocols SMPTE 292M SMPTE 424M Data Rates 270Mbps(SD-SDI), 1.485Gbps (HD-SDI), 2.97Gbps (3G-SDI) 480i@60hz, 720p@50/59.94/60hz, 1080i@50/59.94/60hz, Video Support 1080p@23.98/24/25/29.97/30/50/59.94/60hz SDI Signal Type SMPTE-292M, SMPTE-259M, SMPTE-424M Output Impedance 75 ohms... - Page 6 SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater FEATURES 1) 1x8 Splitter & Repeater 2) DC5V 1A Power Supply. 3) Operating Instructions HGCVW T GU Distributes 1 SDI input to 8 SDI outputs simultaneously Single unit can transmit up to 120m/390ft (Belden 1694A) ...
- Page 7 SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater PANEL DESCRIPTIONS Left Side View Right Side View 1) DC 5~12V 2) Green indicator of source status 3) Red indicator of power input 4) SDI outputs 5) SDI input Connecting and Operating 1.
- Page 8 SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater Typical Application Distribute one SDI input to 8 SDI output Connect with HDMI to SDI converter and SDI to HDMI converter...
- Page 9 SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater Repeater connection...
- Page 10 SD/HD/3G-SDI 1 to 8 Distribution Amplifier & Repeater ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
