- Page 1 User Manual SCA121DTN Scaler Switcher with Digital Amplifier-TN (12 Inputs) All Rights Reserved Version: SCA121DTN _2016V1.1...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
-
Page 3: Safety Precautions
Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com... -
Page 4: Table Of Contents
4.4.1. Installation/uninstallation of RS232 Control Software ......12 4.4.2. Basic Settings ..................12 4.4.3. RS232 Commands ................13 4.4.4. Control Modes ..................16 4.4.5. Control SCA121DTN via TCP/IP communication software ....18 4.4.6. TCP/IP Configuration ................19 5. Specification ......................20 5.1. Specifications of SCA121DTN ................ 20 5.2. - Page 5 Scaler Switcher with Digital Amplifier-TN (12 inputs) 6. Panel Drawing ......................24 7. Troubleshooting & Maintenance ................25 8. After-sales Service ....................27 Altimium www.altimium.com...
-
Page 6: Introduction
1. Introduction 1.1. Introduction to SCA121DTN SCA121DTN is a full HD scaler switcher with 12 video, 6 audio & 2 MIC inputs. It scales & switches any video signal HDMI, VGA, YPbPr, C-Video & S-video to HDBaseT, HDMI & VGA simultaneously, and any audio to 2x20W amplifier. It’s controllable via the button, IR, RS232 &... - Page 7 Scaler Switcher with Digital Amplifier-TN (12 inputs) 1 x User Manual Notes： Please confirm if the product and the accessories are all included, if not, please contact with the dealers. Altimium www.altimium.com...
-
Page 8: Panel Description
① Two RCA connectors for stereo audio output; One VGA output; One HDMI output with audio embedded; One HDBT port for HDMI extending (works with HDMI twisted pair Receiver), support PoC. ② Four VGA connectors for VGA inputs. Altimium www.altimium.com... - Page 9 ⑨ Connector for POWER. ⑩ Two MIC connectors: MIC with pre-amplification, LINE for audio direct input. ⑪ Grounding protection. Note: Pictures shown in this manual are for reference only, different model and specifications are subject to real product. Altimium www.altimium.com...
-
Page 10: System Connection
Step2. Connect the corresponding audio source to the corresponding AUDIO INPUT port of SCA121DTN with audio cable separately. C-VIDEO1 shares the same audio input port with S-VIDEO3; Pr-Pb-Y shares the same audio input port with C-VIDEO4, you can select either side as audio input port. -
Page 11: Poc Solution
PoC share the same power supply and eliminates the need for extra power supply at the remote nodes. Connect SCA121DTN with HDMI twisted pair Receiver with PoC via a CAT5e/6 cable, then plug the power cable of the switcher to an AC100V~240V power supply, HDMI... -
Page 12: Applications
Scaler Switcher with Digital Amplifier-TN (12 inputs) 3.5. Applications SCA121DTN has a good application in various occasions, such as computer realm, monitoring, big screen displaying, meeting room, education and bank & securities institution etc. 3.6. Collocation Products SCA121DTN usually works with other devices to deliver multiple video& audio sources. - Page 13 ID looping function. 99pcs Programmable Control Panel can be looped and controlled together, by ID identifying. Programmed by USB or RS232, working with PC software (PS-WP). Crystal and backlit buttons with easy user-friendly customizable changeable labels. The backlit brightness is controllable. Altimium www.altimium.com...
-
Page 14: Operations
XGA: 1024x768 MIC volume control WXGA: 1280x800 area, can work when not in MENU mode. HD: 1360x768 4.2. OSD Operations SCA121DTN provides a nice OSD operation menu, with various functions and languages. The operation introduction is showed as follows. Altimium www.altimium.com... -
Page 15: Picture Setting
The Second icon from left of the OSD menu is to set the audio/sound parameter. It includes the sound effect preset, bass, treble, balance, scene mode, surround and smart volume setting. Some parameters are available depending on different inputs. Please check the picture below: Altimium www.altimium.com... -
Page 16: System Setting
VGA setting: Adjust the H/V signal of VGA input, includes auto adjustment. Output adjustment: Adjust H/V size and H/V position of the output. This function is available only with HDMI and VGA inputs. 4.3. Firmware Update SCA121DTN supports firmware field-updating by USB flash disk. The operation procedures are: Altimium... -
Page 17: Rs232 Control
SCA121DTN from remote. Control local device from remote: Connect the RS232 ports of SCA121DTN and HDMI twisted pair Receiver with PoC, and connect a control device (e.g. a PC) to HDMI twisted pair Receiver with PoC, then it’s able to send corresponding commands to control SCA121DTN from remote. -
Page 18: Rs232 Commands
Command Sending Area. 4.4.3. RS232 Commands Communication protocol: RS232 Controlling Protocol Command Type: ASCII Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none Command Function Description Feedback Example 0600% MUTE Line LINE Mute On Altimium www.altimium.com... - Page 19 Bright.) Sound Mode: XX (XX 0615% SM Mode can be user, standard, news, or movie.) 0616% MENU of OSD MENU 0617% Command to reset to factory defaults Factory reset 0618% Change the resolution to 1360X768 HD Resolution: HD Altimium www.altimium.com...
- Page 20 Volume Bar: Display Digital Sound Ouput: 0652% Check Digital audio output status Enable 0655% Freeze output image Freeze: Enable 0656% Cancel the freezing of output image Freeze: Disable 0698% Firmware update 0701% Switching to HDMI1 input Source: HDMI 1 Altimium www.altimium.com...
-
Page 21: Control Modes
4001. IP & Gateway can be changed as you need, Serial Port cannot be changed. Controlled by PC without network accessing Connect a computer to the HDBaseT port of SCA121DTN, and set its IP address and gateway to the same IP section as the default IP of SCA121DTN (192.168.0.178). - Page 22 SCA121DTN can be connected with a router to make up a LAN with the PC(s), this make it able to be controlled in a LAN. Make sure SCA121DTN’s IP section is the same with the router. Please connect like the following figure for LAN control.
-
Page 23: Control Sca121Dtn Via Tcp/Ip Communication Software
Scaler Switcher with Digital Amplifier-TN (12 inputs) Step4. Set the PC’s IP address and gateway to the original one. Step5. Connect SCA121DTN and PC(s) to the router. PCs in the same LAN are able to control SCA121DTN asynchronously. The HDBT port of SCA121DTN is used for TCP/IP control. And all the control commands are the same as the RS232 command list. -
Page 24: Tcp/Ip Configuration
Enter correct username and password to log in the WebServer: Username: admin; Password: admin Here is the main configuration interface of the WebServer: Users can configure the IP port, including the IP reset, Serial reset and password reset, update firmware of the IP module on the WebServer. Altimium www.altimium.com... -
Page 25: Specification
Scaler Switcher with Digital Amplifier-TN (12 inputs) 5. Specification 5.1. Specifications of SCA121DTN Video Input Video Output 4 HDMI 4 VGA 1 HDMI Input 1 YPbPr Output 1 VGA 2 C-Video 1 HDBT 1 S-Video HDMI female connector VGA(15 pin HD),... -
Page 26: Specifications Of Video/Audio Input/Output
Changeable aspect ratio. (Full-screen, wide screen, 4:3) Color RGB adjustable 5.2.2. YPbPr input Input Display Parameter Resolution Frame Frame Frame frequency frequency frequency 720×480 I 15.75 720×480 P 31.5 720×576 I 15.625 720×576 P 31.25 1280×720P 16:9 1280×720P 37.50 16:9 Altimium www.altimium.com... -
Page 27: Vga Input
640×480@75Hz 1280×1024@75Hz 800×600@56Hz 1360×768@60Hz 800×600@60 Hz 1920×540@60Hz 800×600@72 Hz 1920×1080I@60Hz 800×600@75Hz 1920×1080P@60Hz 1024×768@60 Hz Digital embedded audio decoding. Changeable aspect ratio (Full-screen, wide screen, 4:3, auto-adjust). Support HDCP1.3, compatible with DVI signal. 5.3. Audio input/output Altimium www.altimium.com... - Page 28 2 pairs of L/R analog audio input, 4 VGA audio and 2 MIC audio inputs 2x10W@8Ω amplifier output. L/R stereo audio output and HDMI embedded audio. Volume/Bass/Treble adjustable Audio status presets, changeable scene mode (Wall-mounted, Desk) Altimium www.altimium.com...
-
Page 29: Panel Drawing
Scaler Switcher with Digital Amplifier-TN (12 inputs) 6. Panel Drawing 483 mm 437 mm OUTPUTS VGA INPUTS VIDEO INPUTS VIDEO INPUTS RS232 TCP/IP C-VIDEO Ω 2x10Watt@8 AUDIO LINE HDBT/PoC HDMI HDMI INPUTS VGA AUDIO Altimium www.altimium.com... -
Page 30: Troubleshooting & Maintenance
(e.g. a are correct. PC) through RS232 port The device is broken Send it to authorized dealer for repairing. Static becomes stronger bad grounding Check the grounding and when connecting the video make sure it is connected connectors well. Altimium www.altimium.com... - Page 31 Scaler Switcher with Digital Amplifier-TN (12 inputs) If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. Altimium www.altimium.com...
-
Page 32: After-Sales Service
Scaler Switcher with Digital Amplifier-TN (12 inputs) 8. After-sales Service If there appear some problems when running SCA121DTN, please check and deal with the problems referring to this user manual. 1) Product Limited Warranty: We warrants that our products will be free from defects in materials and workmanship for three years, which starts from the first day you buy this product (The purchase invoice shall prevail). - Page 36 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
