Quick Start Guide For Telit SL869-3DR EVK
USB CABLE
EVALUATION KIT
EVK Kit Contents
ANTENNA
USB DRIVE
Set-Up
1.
Plug the USB drive into your working PC and install
TelitView. The USB drivers should load automatically.
2.
Using the USB cable, connect the PC to the EVK Unit by
inserting the mini-USB connector into the USB-1
connector located at the rear of the EVK.
3.
Connect the antenna into the RF connector
4.
Activate the TelitView application and click "Setup".
5.
Select SL869-3DR and click "OK".
Advertisement
Table of Contents
Related Manuals for Telit Wireless Solutions SL869-3DR
Summary of Contents for Telit Wireless Solutions SL869-3DR
- Page 1 Quick Start Guide For Telit SL869-3DR EVK Set-Up ANTENNA USB CABLE Plug the USB drive into your working PC and install TelitView. The USB drivers should load automatically. Using the USB cable, connect the PC to the EVK Unit by inserting the mini-USB connector into the USB-1 connector located at the rear of the EVK.
- Page 2 To log data, click on the Record data icon in the main tool bar. Assign a file name and location, click “save” and “start to log”. For more information, refer to the SL869-3DR EVK User Guide. For technical support please contact: TS-EMEA@telit.com TS-AMERICAS@telit.com...
