- Page 1 RS132L24 Rugged Server User Guide The most trusted provider for operational, deployable, and high reliability computing applications. CRYSTAL GROUP INC. ISO 9001:2008 & AS9100C:2009 CERTIFIED QMS ©2015 BY CRYSTAL GROUP INC. ALL RIGHTS RESERVED. DOC-00320 REV E...
-
Page 3: Table Of Contents
RS132L24 Rugged Server CONTENTS After selecting a hyperlink, choose ALT and to jump back to original cursor position. TABLE OF CONTENTS CONTENTS ..........................1 WE THANK YOU ........................3 SAFETY ..........................4 ADVISORIES ............................4 HANDLING PRECAUTIONS .......................5 ELECTROSTATIC DISCHARGE (ESD) ....................5 BATTERY DISPOSAL .........................5... - Page 4 RS132L24 Rugged Server INSTALLING THE PRODUCT IN AN EQUIPMENT RACK ..............11 OPERATING THE PRODUCT ..................15 CONNECTING TO A POWER SOURCE ....................15 POWERING THE SERVER ON ......................15 MAINTAINING THE PRODUCT ..................16 DRIVER UPDATES .......................... 16 CHASSIS ACCESS ........................... 16 CHASSIS VIEWS ..........................
-
Page 5: We Thank You
RS132L24 Rugged Server WE THANK YOU! From all of us at Crystal Group Inc., THANK YOU for your purchase of the RS132L24. Our customers are the lifeline that keeps Crystal going. That is why it is extremely important to us that our customers are 100% satisfied with their product choice. -
Page 6: Safety
A note indicates important information that helps make better use of the equipment. WARNING A warning indicates a potential for property damage, personal injury, or death. CAUTION Caution indicates potential damage to RS132L24 or loss of data if instructions are not followed. RS132L24 User Guide Page... -
Page 7: Handling Precautions
5. Always handle the memory or expansion cards by the edges. 6. Do not touch the input/output connector pins. BATTERY DISPOSAL The following applies to any battery that might be on any board installed in the RS132L24 equipment: Danger of explosion if battery is incorrectly replaced. -
Page 8: Acontact Information
RS132L24 Rugged Server CONTACT INFORMATION support of Our technical personnel are acutely aware that downtime experienced by a customer is a mission critical event. They excel at providing timely and effective responses to any technical issues encountered in the field. Please contact us with any questions or concerns... -
Page 9: Bproduct Information
RS132L24 Rugged Server PRODUCT INFORMATION OVERVIEW The Crystal RS132L24 is a compact one rack unit (R/U) computer in a 1.75 wide by 24 is designed for (see section Installing the Product for more information) or used as a stand-alone unit. The RS132L24 consists of an aluminum chassis/enclosure, a power supply, an active motherboard, processor(s), BD/CD/DVD, memory, and storage). - Page 10 RS132L24 Rugged Server Electromagnetic Interference (EMI) Environmental kits available for shock, vibration, EMI and humidity. Expansion Slots X9DRW-F: Two (2) PCIe 3.0X16 X9SRW-IF: Two (2) PCIe 3.0X16, one (1) PCIeX8 low profile External Bays Option 1 (standard) Option 2 Option 3 (can be combined with HDD option)
- Page 11 RS132L24 Rugged Server Power Supply Options Option 1 (standard) 460W 120/240VAC 50/60Hz w/PFC, 115VAC 400Hz Option 2 425W DC 18-36V System Board Option 1 (Standard) X9DRW-IF, LGA2011 XEON, WIO, 2LAN1000, VGA, 2 PCI-EX16, IPMI, IPKVM, SATA2X8, SATA3X2, SUPERMICRO Option 2...
-
Page 12: Cinstalling The Product
RS132L24 Rugged Server INSTALLING THE PRODUCT GROUNDING AC Version- to ensure a good earth ground, the RS132L24 should be used with a UL listed three-conductor power cord connected to a three-conductor grounded power source. DC Version- input installations- use only approved copper connectors. -
Page 13: Installing The Product In An Equipment Rack
RS132L24 Rugged Server INSTALLING THE PRODUCT IN AN EQUIPMENT RACK Using Fixed Mounting Brackets To install RS132L24 with fixed mounting brackets in an equipment rack, complete the steps and Figure 1 below: 1. Line up eight holes on the sides of the rear mounting brackets with eight holes on the sides... - Page 14 RS132L24 Rugged Server Using Crystal Slides To install RS132L24 with Crystal Slides in an equipment rack, complete the following steps and Figure 2 below: 1. Loosen adjuster screws. 2. Line up the top and bottom holes on the front & rear mounting ears at the desired level of the equipment rack, and attach to the rack using four (two per side) 10-32 x 0.50...
- Page 15 RS132L24 Rugged Server Using Jonathan Rails To install RS132L24 with Jonathan Rails in an equipment rack, complete the following steps below and see Figure 3 on the following page. 1. Attach a bracket (see #6 in Figure 3) to the smooth side of the Jonathan rail that has four or more holes in a row (see #9 in Figure 3).
- Page 16 RS132L24 Rugged Server The images on the following page may not depict the product received. Table 4 Not all chassis support Jonathan Rails Jonathan Rails Parts List ITEM DESCRIPTION SCREW, PHIL FHD 100D 8- KEPS NUT, 8-32 X 0.344 HEAD STL...
-
Page 17: Doperating The Product
RS132L24 Rugged Server OPERATING THE PRODUCT If the RS132L24 is part of a rack configuration, refer to the more information on connecting to a power source. CONNECTING TO A POWER SOURCE Please see Section C- Installing the Product on page 10 for more information. -
Page 18: Emaintaining The Product
CHASSIS ACCESS Removing the Cover 1. Make sure the RS132L24 is powered off and the unit is disconnected from the power source. 2. Remove the screws connecting the top cover to the chassis using a Phillips screw driver. 3. Lift the cover to expose the interior of the chassis. -
Page 19: Chassis Views
RS132L24 Rugged Server CHASSIS VIEWS: Drive Bay 1 Drive Bay 0 Power Drive Bay 2 Power Switch Drive Bay 3 Figure 4. Front View RS132L24 GROUND STUD EXPANSION WITH POWER SLOT WINGNUT INPUT I/O PORT Figure 5. Rear View RS132L24 The images above may not depict the product received. -
Page 20: Input/Output (I/O) Ports
RS132L24 Rugged Server INPUT/OUTPUT (I/O) PORTS: X9DRW-iF Figure 6. I/O Ports Table 5 NUMBER FUNCTION COM Port 1 (Turquoise) USB 2.0 PORT 0 USB 2.0 PORT 1 IPMI LAN USB 2.0 PORT 2 USB 2.0 PORT 3 LAN 1 LAN 2... -
Page 21: Input/Output (I/O) Ports Continued
RS132L24 Rugged Server INPUT/OUTPUT (I/O) PORTS CONTINUED: X9SRW-F Figure 7. I/O Ports Table 6 NUMBER FUNCTION COM 1 USB 2.0 PORT 1 USB 2.0 PORT 0 IPMI LAN USB 2.0 PORT 2 USB 2.0 PORT 3 LAN 1 LAN 2... -
Page 22: Input/Output (I/O) Motherboard Guides
RS132L24 Rugged Server INPUT/OUTPUT (I/O) Motherboard guides: For detailed information about the X9 motherboard option included in the product, please review the motherboard guide at the following link: X9DRW-iF.Motherboard Guide See chapter 2 - Connectors and I/O Ports. X9SRW-F Motherboard Guide See chapter 2 - Connectors and I/O Ports. -
Page 23: Expansion/Riser Card Removal And Replacement
Removing and Replacing the Plug-in Expansion/Riser Card Disconnect power source to prevent injury. Installing a plug-in expansion/riser card requires opening the RS132L24 cover, removing the card cage, inserting the card into the motherboard, replacing the card cage, and disconnecting and reconnecting the appropriate connectors. - Page 24 RS132L24 Rugged Server 8. Attach appropriate connectors. 9. Replace chassis cover. Figure 8. Expansion/Riser Card Installation The image above may not depict the product received. RS132L24 User Guide Page of 29...
-
Page 25: Hard Drive Removal And Replacement
RS132L24 Rugged Server HARD DRIVE REMOVAL AND REPLACEMENT Removing and Replacing the Carrier/Hard Drive Assembly The procedure below may be different depending on the explicit drive contained in the product. Steps: 1. Power the system down (unless a drive controller supporting hot-swap has been... -
Page 26: Memory Removal And Replacement
RS132L24 Rugged Server MEMORY REMOVAL AND REPLACEMENT Removing and Replacing the Memory Contact Crystal Technical Support before performing a memory upgrade. Use only Crystal- approved memory for upgrades. Do not force the DIMM. Forcing the DIMM may result in equipment damage. Check the alignment and keying before installing. - Page 27 RS132L24 Rugged Server DIMM KEY RELEASE LEVER Figure 10. Installing DIMM RS132L24 User Guide Page of 29...
-
Page 28: Ftroubleshooting
RS132L24 Rugged Server TROUBLESHOOTING CONTACT TECHNICAL SUPPORT If any problems arise when using the product, please contact Technical Support at one of the options listed on page 6. Before calling, please have the following information available to help expedite assistance: 1. -
Page 29: Available Warranty
RS132L24 Rugged Server AVAILABLE WARRANTY CRYSTAL GROUP LIMITED WARRANTY Seller warrants to the Buyer that the products manufactured by it will be free from defects in material and warranty shall be the repair or replacement of any part or parts which prove to be defective under normal use and service within five (5) years from the date of delivery to the Buyer. -
Page 30: Legal Information
RS132L24 Rugged Server LEGAL INFORMATION THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS USER GUIDE ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS USER GUIDE ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS. -
Page 31: Disclaimers
RS132L24 Rugged Server The information contained in this document is provided for reference only. Crystal Group Inc. does not assume any liability arising out of the application or use of the information or products described herein. This user guide may contain or reference information and products protected by copyrights or patents and it does not convey any license under the patent rights of Crystal Group Inc., nor...
