7
If you are not using an Ethernet connection, a list of available
wireless networks will appear. Highlight the network and
click or press Select. If the network you are connecting to is
secure, you will be prompted to enter the password.
8
Once you connect, the Home page will display a green check
mark. Your device is now connected to the Internet.
You may now connect other wireless devices to your DIR-508L and
share the Internet connection. You can also share files by connecting a
USB thumb drive to the router.
Troubleshooting
How do I connect my wireless devices to the DIR-508L router?
1. Open your wireless network utility that displays available wireless
networks.
2. Select the Wi-Fi Network name (DIR508L by default) and connect.
You can also connect using WPS:
1. Press the WPS button on the DIR-508L for one second.
2. Within one minute press the WPS button on your wireless device.
3. Allow up to two minutes to connect.
Note: Some devices may require you to log in to a utility to start
the WPS process. Refer to the user manual of the device you want
to connect to the router if you do not know how to start the WPS
process.
How do I change the wireless settings on the DIR-508L router?
1. Open a web browser (e.g., Internet Explorer, Chrome, Firefox, or
Safari) and go to http://dlinkrouter.local. (or 192.168.0.1).
2. At the login screen, click or press the Log in button (no password
by default).
3. Click or press DIR-508L or click or press Settings > Wi-Fi Settings.
4. Enter a new wireless name and password. Click or press
Advanced Settings for more options.
5. Click or press Save.
Note: if you have changed the Wi-Fi Network name, the device you
are currently using to connect to the DIR-508L will drop. You will need
to open your wireless utility and connect to the DIR-508L using the
new network name.
What if I forgot my router password?
1. If you forgot your router password or want to reset
the DIR-508L back to the default settings, press
and hold the reset button using a paper clip and
release after five seconds.
Warning: This process will erase all your settings.
Documentation available at http://www.dlink.com/DIR-508L.
Technical Support
Having trouble installing your new product? D-Link's website contains
the latest user documentation and software updates for D-Link products.
United States
Canada
Phone: (877) 453-5465
Internet:
http://support.dlink.ca
Internet:
http://support.dlink.com
Copyright ©2013 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and the
D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the United
States and other countries. iPhone, iPad, and iPod touch are registered trademarks of Apple Inc.
Android is a trademark of Google, Inc. Other trademarks are the property of their respective
owners. Maximum wireless signal rate derived from IEEE Standard 802.11n and 802.11g
specifications. Actual data throughput will vary. Network conditions and environmental
factors, including volume of network traffic, building materials and construction, and network
overhead, lower actual data throughput rate. Environmental factors will adversely affect
wireless signal range. Product specifications, size and shape are subject to change without
notice, and actual product appearance may differ from that depicted on the packaging. Visit
www.dlink.com for more details.
GPL Code Statement
This D-Link product includes software code developed by third parties,
including software code subject to the GNU General Public License ("GPL") or
GNU Lesser General Public License ("LGPL"). As applicable, the terms of the GPL
and LGPL, and information on obtaining access to the GPL code and LGPL code
used in this product, are available to you at:
http://tsd.dlink.com.tw/GPL.asp
The GPL code and LGPL code used in this product is distributed WITHOUT ANY
WARRANTY and is subject to the copyrights of one or more authors. For details,
see the GPL code and the LGPL code for this product and the terms of the GPL
and LGPL.
Written Offer for GPL and LGPL Source Code
Where such specific license terms entitle you to the source code of such
software, D-Link will provide upon written request via email and/or traditional
paper mail the applicable GPL and LGPLsource code files via CD-ROM for a
nominal cost to cover shipping and media charges as allowed under the GPL
and LGPL.
Please direct all inquiries to:
Email:
GPLCODE@dlink.com
Snail Mail:
Attn: GPLSOURCE REQUEST
D-Link Systems, Inc.
17595 Mt. Herrmann Street, Fountain Valley, CA 92708
GNU GENERAL PUBLIC LICENSE
Version 3, 29 June 2007
Copyright (C) 2007 Free Software Foundation, Inc. <http://fsf.org/>
View the full GPL Code Statement at http://www.gnu.org/licenses/gpl.html
Version 1.0 | July 25, 2013 11500Y20NX00301A1
