Resource Data Management PR0624 User Manual page 3

4 Port USB Hub User Guide
USB Cable
A USB cable comes supplied with the Hub and the cable is 40cm in length. The USB
cable has an A type USB connection at one end, which connects to the host device
and a B type USB connection which connects to the USB 4 port "USB Device" port.
Specification
Power requirements
Supply Voltage Range:
Supply Frequency:
Typical supply current:
RDM advise the use of a suitable external over-current protection device.
General
Operating temperature range: +5
Operating Humidity:
Storage temperature range:
Environmental:
Weight:
Safety:
EMC:
Ventilation:
Enclosure Size:
Mounting Dimensions
Disclaimer
The specifications of the product detailed in this document may change without notice. RDM Ltd shall not be liable for errors or omissions, for
incidental or consequential damages, directly or indirectly, in connection with the furnishing, performance or misuse of this product or document.
Warning
Ensure that all power is
switched off before
installing or maintaining
this product
24 Vac (+/- 10%) OR 24 Vdc (+/- 10%)
50 - 60 Hz (+/- 10%) OR DC
<1 Amp
0 0
C to +50 C
80% maximum
0 0
-20 C to +65 C
Indoor use at altitudes up to 2000m, Pollution Degree 1,
Installation Category II.
Voltage fluctuations not to exceed ±10% of nominal voltage
120 Grams
EN61010
EN 55022/A1 : 2007
EN 55024/A2 : 2003
There is no requirement for forced cooling ventilation
97mm (L) x 73mm (W) x 30mm (H)
48mm
USB Port 4
USB Port 3
USB Port 2
USB Port 1
48mm
USB Device
Mounting Holes
106mm
Revision 1.1 Page 3 of 3
