DAHUA DH-PFA5300R - Connection Box for Panoramic Camera
1. INTRODUCTION
Thank you for choosing DAHUA DH-PFA5300R junction box! This junction box is
designed specifically for DAHUA panoramic cameras, providing a safe and tidy
solution for cable and connection management. It is ideal for the IPC-PFW5849-
A180-E2-ASTE panoramic camera, offering additional protection against adverse
environmental conditions.
2. PRODUCT SPECIFICATIONS
•
Model: DAHUA DH-PFA5300R
•
Material: Aluminum
•
White color
•
Weight: 0.39kg
•
Maximum load: 3 kg
•
Protection: IP66, IK10
•
Compatibility: DAHUA IPC-PFW5849-A180-E2-ASTE panoramic camera
3. PACKAGE CONTENTS
•
1 x Waterproof Junction Box
•
4 x M4x10 Screws
•
3 x ST4X25 Screws
•
3 x Plastic expansion bolt
•
1 x S3.0 Key
•
1 x Water Board
•
1 x Mounting Adhesive
•
1 x User Manual
User manual
IPC-PFW5849-A180-E2-ASTE
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dahua DH-PFA5300R
Summary of Contents for Dahua DH-PFA5300R
- Page 1 DAHUA DH-PFA5300R - Connection Box for Panoramic Camera IPC-PFW5849-A180-E2-ASTE 1. INTRODUCTION Thank you for choosing DAHUA DH-PFA5300R junction box! This junction box is designed specifically for DAHUA panoramic cameras, providing a safe and tidy solution for cable and connection management. It is ideal for the IPC-PFW5849- A180-E2-ASTE panoramic camera, offering additional protection against adverse environmental conditions.
- Page 2 4. INSTALLATION 4.1 Prerequisites • DAHUA IPC-PFW5849-A180-E2-ASTE panoramic camera. • Tools: Drill, screwdriver, level. • Suitable mounting surface: solid and stable wall or ceiling. 4.2 Installation Steps 1. Selection of Assembly Location: Choose a suitable location on the wall or ceiling that is solid and stable, •...
- Page 3 • Pass the cables through the rubber gasket to protect them and prevent dust and water from entering. 8. Cable Connection: Connect the power and data cables according to the camera • specifications. Make sure all connections are secure and protected. •...
