Sportsman GEN4065 Step-By-Step Manual

Follow This Step-By-Step
Guide To Using Your Generator
1
Remove generator from package
2
Add Oil
3
Add Fuel
4
Start The Generator
Use the generator OUTDOORS in a WELL VENTILATED AREA.
DO NOT CONNECT electrical devices until AFTER the generator
is started.
Turn Engine Switch to ON
Turn FUEL PETCOCK to ON (Figure A)
Adjust the CHOKE to CLOSED/CHOKE position (Figure B)
Start the generator manually with the Recoil (Pull) Start.
Once the engine has started and runs for about a minute, move
the choke lever approximately half way towards the "Open/Run"
position. Wait an additional 30 seconds and then move the choke
lever completely over to the "Open/Run" position.
You can now connect electrical devices.
On
O
Fuel Petcock (Figure A)
Choke (Figure B)
Closed
Open
TOLL-FREE NATIONWIDE HELP LINE! 866-460-9436
Need Help? Do Not Return This Generator To The Store! Call Us First!
Visit our website for Troubleshooting & Frequently Asked Questions
Oil Type: SAE10W-30 Oil (Must add BEFORE first use)
Oil Capacity: 20 fluid oz (0.59 L)
Because this generator includes Low Oil Shut Off, the
generator will not start with low oil)
Unleaded gasoline only octane rating of 87 or higher
Maximum Capacity: 4 Gallon fuel tank
Recoil
4
Start
Engine
Switch
Monday-Friday 8:00-4:30 Central Time
www.sportsmanseriesbrand.com/generators
4
GEN4065
4,000 Surge / 3,250 Running Watts
UNLEADED GASOLINE FUEL
GENERATOR SPECIFICATIONS:
• 120 Volt/ 15A / 60 Hz
• 7.0 HP Engine, 4 Stroke OHV
• Recoil Start
• 4 Gallon Fuel Tank w/Gauge
• Low Oil Shut Off
• UL Listed Electrical Components
• Engine Shut Off Switch
• Circuit Breaker & Power Outlets
• 1-12V DC Outlet
• 2 -120V AC Outlets
• Complies with EPA emissions
• Run time = 9 hours @ 50% load
• Decibel Rating < 68 db
• Warranty: 1 YEAR limited
3
Add Gasoline
2
Add Oil
