By fitting optional equipment this product can operate automatically under normal running
conditions. The optional controls fit within the casing of the unit and are supplied with easy to fit
instructions.
Wall Mounted Controller WMCEC
This enables the end user to control the fan speed from a wall mounted control.
Plinth to suit Caspian Universal CCLP
Where the product is installed floor level, the plinth will raise the unit 150mm above the
floor. (Available in black & white)
Air inlet filters for all models.
For accessories or spares please contact either your supplier or Smith's Environmental
Products Ltd.
Technical designation 60, 90, 120, 150, 180 LST
Products with this symbol (crossed out wheelie bin) cannot be disposed as household waste.
Old electrical and electronic equipment must be recycled at a facility capable of handling these
products and their waste by-products. If you are purchasing replacement equipment your
retailer may offer a 'take back' scheme, or will be able to give details of the nearest approved
authorised treatment facility. Proper recycling and waste disposal will help conserve resources
whilst preventing detrimental effects on our health and the environment.
WEEE Registered Code : WEE/ED0093VW
Smith's Environmental Products Ltd
Blackall Industrial Estate, South Woodham Ferrers, Chelmsford, Essex, CM3 5UW
Tel: 01245 324900 Fax: 01245 324422
Sales: sales@SmithsEP.co.uk General Information E-mail: info@SmithsEP.co.uk Web: www.SmithsEP.co.uk
For Ireland (Republic & Northern), contact MT Agencies on 00 353 1 864 3363
In light of our policy of continuous development Smith's Environmental Products Ltd reserve the right to alter
specifications without prior notice.
Iss: 5
Accessories
8
60, 90, 120, 150 & 180
Series Fan Convectors
User Information.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision
A means for disconnection from the supply mains having a contact
separation in all poles that provides full disconnection under overvoltage
category III conditions must be incorporated in the fixed wiring in
accordance with the wiring rules.
OCT 17
Ensure that the fan convector is switched-off before opening the cover.
LST Caspian
Suitable for Low Level Installation Only
Installation & User Guide
