C-Nav C-NaviGator III Reference Manual

Control and display unit
Hide thumbs Also See for C-NaviGator III:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
C-NaviGator III
Mounting Reference Guide
Revision 3
Revision Date: March 29, 2018
C-Nav Positioning Solutions
730 E. Kaliste Saloom Road
Lafayette, LA 70508 U.S.A.
www.oceaneering.com/cnav

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-NaviGator III and is the answer not in the manual?

Questions and answers

Related Manuals for C-Nav C-NaviGator III

Summary of Contents for C-Nav C-NaviGator III

  • Page 1 C-NaviGator III Mounting Reference Guide Revision 3 Revision Date: March 29, 2018 C-Nav Positioning Solutions 730 E. Kaliste Saloom Road Lafayette, LA 70508 U.S.A. www.oceaneering.com/cnav...

  • Page 2: C-Navigator Iii

    C-NaviGator III Mounting Reference Guide Release Notice This is the March 29 release of the C-NaviGator III Mounting Reference Guide. Revision History 3/29/2018 Updated to new web domain L.Cortes 7/19/2013 Added additional mounting options J. Hauschildt Added Panel Cut Out Guide & cleaning 3/1/2013 J.
  • Page 3 C-NaviGator III Mounting Reference Guide SAVINGS, OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES, INCLUDING BUT NOT LIMITED TO ANY DAMAGES ASSESSED AGAINST OR PAID BY YOU TO ANY THIRD PARTY, RISING OUT OF THE USE, LIABILITY TO USE, QUALITY OR PERFORMANCE OF SUCH OCEANEERING INTERNATIONAL, INC.

  • Page 4: Table Of Contents

    Figure 3: C-NaviGator III 19” Rack Mounting Plate (P/N CNVJH 13TAP STD-A1) ..........................11 Figure 4: Tilting VESA Wall Mount for C-NaviGator III (P/N PEEST630) .... 12 Figure 5: RAM VESA Plate KIT (P/N CNV-D-246U-IN1KIT1) ......12 Figure 6: RAM 100/75 VESA mount Plate (P/N CNVRAM-D-246U-IN1) ..13...

  • Page 5: Table Of Contents

    C-NaviGator III Mounting Reference Guide Figure 7: RAM 3.68" Diameter Base (P/N CNVRAM-D-202U-IN1) ....13 Figure 8: RAM Double Ball Adapter (P/N CNVRAM-D-230U) ......13 Figure 9: RAM Double Socket Arm, Short (P/N CNVRAM-D-201U-C) ... 13 Figure 10: RAM Double Socket Arm, Regular (P/N RAM-D-201U) ....14 Figure 11: RAM Double Socket Arm, Long (P/N CNVRAM-D-201U-E) ....

  • Page 6: Manual Organization

    C-NaviGator III Mounting Reference Guide Manual Organization This section describes how the manual is laid out. It gives one or two sentence descriptions about each major section. Section 1 – Overview (Page 7) gives a brief overview of the purpose of this document.

  • Page 7: Conventions

    Such note box displays important information which should not be ignored. Section 1 – Overview Introduction This guide is used as a reference for installing and mounting the C-NaviGator III control and display unit. It also shows the mounting options for the C-NaviGator Revision 2...

  • Page 8: Figure 1: C-Navigator Iii Control And Display Unit

    C-NaviGator III Mounting Reference Guide III, as well as their dimensions. For further information, contact C-Nav support (cnavsupport@oceaneering.com). Figure 1: C-NaviGator III Control and Display Unit Revision 2 Page 8 of 20 3/29/2018...

  • Page 9: Section 2 - Installation And Mounting Instructions

    C-NaviGator III Mounting Reference Guide Section 2 – Installation and Mounting Instructions ATTENTION: To prevent damage to chassis corners and / or breaking the front glass, please review the illustrations below before handling the units! Installation and Mounting 1. Most of our products are intended for various methods of installation or mounting (panel mounting, bracket mounting, ceiling/wall, console mounting etc.);...

  • Page 10: General Mounting Instructions

    The cooling must not be impaired by partial covering of the unit or by installation of the unit in a confined cabinet. 3. In the area of the wheel house, the distance of the C-NaviGator III from the magnetic standard compass or the magnetic steering compass must not be less than the permitted magnetic protection distance.
  • Page 11 C-NaviGator III Mounting Reference Guide NaviGator III is at least 80cm (31.5”) from a standard compass; at least 45cm (18”) from a steering compass. 4. When selecting the site of a display unit, the maximum cable lengths have to be considered.

  • Page 12: Section 3- Mounting Options

    Flat Screen Table Stand (P/N CNVCHIFSB018BLK) (See Fig. 2) Figure 2: Flat Screen Table Stand for C-NaviGator III/ CHIFSB0108BLK OPTION #2 C-NaviGator III 19” Rack Mounting Plate (P/N CNVJH 13TAP STD-A1) (See Fig. Figure 3: C-NaviGator III 19” Rack Mounting Plate P/N CNVJH 13TAP STD-A1...

  • Page 13: Option #3

    Figure 4: Tilting VESA Wall Mount for C-NaviGator III (P/N PEEST630) OPTION #4 RAM VESA Ball Mounts- allows the C-NaviGator III to be mounted to the ceiling, wall or desktop with fully adjustable positioning. Here are the following RAM VESA Ball Mount parts and accessories (Figures 5 through 13): ...

  • Page 14: Figure 6: Ram 100/75 Vesa Mount Plate (P/N Cnvram-D-246U-In1)

    C-NaviGator III Mounting Reference Guide  RAM VESA mount Plate (P/N CNVRAM-D-246U-IN1) (See Fig. 6) Figure 6: RAM 100/75 VESA mount Plate (P/N CNVRAM-D-246U-IN1)  RAM 3.68" Diameter Base (P/N CNVRAM-D-202U-IN1) (See Fig. 7) Figure 7: RAM 3.68" Diameter Base (P/N CNVRAM-D-202U-IN1) ...

  • Page 15: Figure 10: Ram Double Socket Arm, Regular (P/N Ram-D-201U)

    C-NaviGator III Mounting Reference Guide Figure 10: RAM Double Socket Arm, Regular (P/N RAM-D-201U)  RAM Double Socket Arm, Long (P/N CNVRAM-D-201U-E) (See Fig. 11) Figure 11: RAM Double Socket Arm, Long (P/N CNVRAM-D-201U-E)  RAM 11" x 3" Additional Heavy Duty Base (P/N CNVRAM-D-111B-IN1U) (See Fig.

  • Page 16: Section 4- Cleaning Instructions

    The user can select Clean Screen in General Settings. By choosing this option (See Fig.13), the display will ignore input from the touch screen for 10 seconds. The user can wipe the screen using a dry soft fabric cloth. As a promotion, C-Nav provides a soft fabric cloth with every C-NaviGator III.
  • Page 17 C-NaviGator III Mounting Reference Guide 2) Fold a cloth into a small pad, dampen the cloth with alcohol, and wipe the glass from one edge to the other in one direction with one continuous motion. 3) The soft cloth & alcohol wipe is recommended to clean fingerprints and oils off the glass.

  • Page 18: Section 5- Physical Dimensions

    C-NaviGator III Mounting Reference Guide Section 5- Physical Dimensions  355.00 (W) x 248.50 (H) x 58.00 (D) mm  13.98” (W) x 9.78” (H) x 2.28” (D)  4 x M4 VESA mounting 75x75mm, Max 8mm deep  Built-in Console mounting 4 x M5x15mm screws ...

  • Page 19: Section 6- Panel Cut-Out Guide

    C-NaviGator III Mounting Reference Guide Section 6- Panel Cut-Out Guide A link to the drawing below can be found HERE. A full sized cut out template for the C-NaviGator III can be found HERE (Requires print out on a sheet of ANSI size B (11”...

  • Page 20: Section 7 - Mechanical Drawings

    C-NaviGator III Mounting Reference Guide Section 7 - Mechanical Drawings Revision 2 Page 20 of 20 3/29/2018...
