Cochlear Mini 2 Quick Manual page 3

Quick guide for Baha® sound processor users
Cochlear™ Wireless Mini Microphone 2 / 2+
Additional features of the Mini Microphone 2+
The Mini Microphone 2+ also offers extended audio source connectivity options.
Telecoil (TC)
From the built-in Telecoil, receiving audio from a induction loop
system (available at some theatres, schools, churches, etc.).
Line-in
From an external audio source (smartphone, tablet, laptop, TV,
etc.) attached via the Line-in connector.
To use this mode, insert the included jack cable into the Line-in
connector and plug the other end of the jack cable into the
AUDIO OUT on the external audio device.
Stream audio to your sound processor
How to:
Insert one end of the supplied
jack cable into the socket of
the microphone and the other
end into the AUDIO OUT of
your audio device, such as a
computer, MP3 player or hi-fi.
Cochlear Wireless Accessories are compatible with select Cochlear sound processors. See www.cochlear.com for full compatibility details.
Not all products are available in all markets. Product availability is subject to regulatory approval in respective markets.
Support
For full details about the Cochlear Wireless Mini Microphones,
please refer to the User Manual.
For full details about the Cochlear Baha sound processor, please
refer to the User Manual part A.
Cochlear Bone Anchored Solutions AB Konstruktionsvägen 14, 435 33 Mölnlycke, Sweden
Tel: +46 31 792 44 00 Fax: +46 31 792 46 95
www.cochlear.com
Ardium, Baha, Baha SoftWear, BCDrive, DermaLock, EveryWear, Vistafix and Windshield are either trademarks or registered trademarks of Cochlear Bone Anchored Solutions AB. Cochlear, SmartSound,
True Wireless, Hear now. And always and the elliptical logo are either trademarks or registered trademarks of Cochlear Limited. © Cochlear Bone Anchored Solutions AB 2016. All rights reserved. MAR16.
D814670-1
FM
From an external FM receiver attached via the FM connector. To
use this mode, insert a Europin DAI or FM receiver into the FM
connector.
Change mode
To view the current mode of operation
press the mode button once. The
corresponding mode LED on the backside
of the microphone will light up.
To change the mode of operation press
the mode button again and repeat until
the desired mode is obtained.
Note:
• Line-in and FM Modes can only be selected if a cable or FM
receivers are inserted into the microphone.
• The microphone will automatically switch into Line-in Mode
when inserting a mini-jack plug.
• The microphone will automatically switch into FM Mode when
inserting an FM or DAI receiver.
To audio
device
Visit www.cochlear.com to learn about our
full range of apps and wireless accessories.
