QUIcK
InSTAllATIOn
GUIde
Grandstream HT-502 ATA
Basic Installation Instructions:
Connecting the ATA to the Internet via
Cable or DSL modem
Your Start-up Kit should include:
HT-502 Device Unit
12V Universal Power Adapter
RJ-45 Ethernet Cable
HT502 Stand
Installation Guide: Setting Up Your Grandstream HT-502
OpTIOn 1. Using ATA Router as primary router
Internet
HT-502 ATA
DSL or
C
a
b
M
o
d
e
m
Display LED
(green)
Reset
Back
LAN RJ-45
2
Ethernet
4
WAN RJ-45 Ethernet
Step 1:
Connect an analog telephone (or fax machine) to the PHONE port.
Step 2:
Connect the WAN port of the HT-502 to a router, switch or modem using an Ethernet cable.
Step 3:
Plug the power adapter into the HT-502.
Step 4:
Connect a computer or switch to the LAN port of the HT-502 (Optional).
For a complete users guide:
le
HT-502 ATA
RJ-11 FXS Ports
(Phone)
1
3
Power Supply
(12V)
3
http://www.grandstream.com/user_manuals/
Computer
Fax (optional)
T
e
e l
p
h
o
n
1
4
Continued on page 2
e
2
1.
