RTI WK2 Quick Reference Manual

WK2
Water Resistant In-Wall Keypad

Product Contents

Contents within the box include the following items:
• One (1) WK2 glass keypad assembly
• One (1) Rear housing assembly
• Two (2) Mounting wings with screws
• One (1) MAC address card
• One (1) Drywall cutout template
• One (1) Quick reference guide

Safety Suggestions

Read and Follow Instructions. Read all safety and operating instructions before
operating the unit.
Retain Instructions. Keep the safety and operating instructions for future
reference.
Heed Warnings. Adhere to all warnings on the unit and in the operating
instructions.
Heat. Keep the unit away from heat sources such as direct sunlight, radiators,
heat registers, stoves, etc.
Power Sources. Connect the unit only to a Power over Ethernet (PoE) router/
switch of the type described in this reference guide.
Water and Moisture. If the unit will be installed near water—for example, near
a sink, in a bathroom, near a swimming pool etc.,—follow the instructions in this
reference guide to ensure moisture does not damage the unit.
Object and Liquid Entry. Do not allow objects to fall or liquids to be spilled into
the enclosure through openings.
Servicing. Do not attempt any service beyond that described in the operating
instructions. Refer all other service needs to qualified service personnel.
Damage Requiring Service. The unit should be serviced by qualified service
personnel when:
• The internal components have been exposed to fallen objects, spilled liquids or
moisture.
• The unit does not appear to operate normally or exhibits a marked change in
performance.
• The unit has been dropped or the enclosure has been damaged.

Limited Warranty

RTI warrants its products for a period of one (1) year (90 days only for included
battery packs); or for a period of time compliant with local laws when applicable
from the date of purchase from RTI or an authorized RTI distributor.
This warranty may be enforced by the original purchaser and subsequent owners
during the warranty period, so long as the original dated sales receipt or other
proof of warranty coverage is presented when warranty service is required.
Except as specified below, this warranty covers all defects in material and
workmanship in this product. The following are not covered by the warranty:
Damage resulting from:
1. Accident, misuse, abuse, or neglect.
2. Failure to follow instructions contained in this Guide.
3. Repair or attempted repair by anyone other than Remote Technologies
Incorporated.
4. Failure to perform recommended periodic maintenance.
5. Causes other than product defects, including lack of skill, competence or
experience of user.
6. Shipment of this product (claims must be made to the carrier).
7. Being altered or which the serial number has been defaced, modified or
removed.
Copyright © 2015 • Remote Technologies Incorporated • All rights reserved.
It's Under Control
Contacting RTI
For news about the latest updates, new product information, and new
accessories, please visit our web site at: www.rticorp.com
For general information, you can contact RTI at:
Remote Technologies Incorporated
5775 12th Avenue East, Suite 180
Shakopee, MN 55379
Tel. (952) 253-3100
Fax (952) 253-3131
Service & Support
If you are encountering any problems or have a question about your RTI
product, please contact RTI Technical Support for assistance (see the Contacting
RTI section of this guide for contact details).
RTI provides technical support by telephone or e-mail. For the highest quality
service, please have the following information ready, or provide it in your fax or
e-mail.
• Your Name
• Company Name
• Telephone Number
• E-mail Address
• Product model and serial number (if applicable)
If you are having a problem with hardware, please note the equipment in your
system, a description of the problem, and any troubleshooting you have already
tried.
If you are having a problem with software, please note what version you have
installed, the operating system on your PC, a description of the problem, and
any troubleshooting you have already tried. If you are calling about a software
or programming question or problem, please be at your computer when you
place your call. This will considerably speed up the troubleshooting process.
*Please do not return products to RTI without return authorization.*

Federal Communications Commission Notice

This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the device.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC rules and Industry Canada license-
exempt RSS standard(s) Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference
that may cause undesired operation.
DECLARATION OF CONFORMITY (DOC)
The Declaration of Conformity for this product can be found on the RTI website
at: www.rticorp.com/declaration
®
Water Resistant In-Wall Keypad
Quick Reference Guide
The WK2 Water Resistant In-Wall Controller has a clean, sleek design
with an all glass exterior that is perfect in locations such as bathrooms.
The solid state glass keypad utilizes capacitive touch for the fourteen
programmable buttons. A bright OLED display provides two-way
feedback for fast, intuitive control when used with an RTI XP series
control processor.
Features
• Solid state glass keypad with capacitive touch is water resistant.
• OLED display provides intuitive two-way feedback.
• Sleek, low-profile, glass exterior design.
• Integrated 10/100Base-T Ethernet port with Power-over-Ethernet.
• Integrated mounting wings for easy installation in retrofit installs.
• A metal conduit box is also available (separately) for new construction.
• RTI control processors and accessories provide voltage sensing, relays
and advanced two-way control.
N27917
WK2
70-210142-17 V1.0
